| Ref | Part Number | Description |
|---|
| 1 |
112-9916 |
HYD CYLINDER ASM Price: $752.66 |
| 1 |
532170805 |
CONTROL.THROTTLE.LT/YT Price: $27.99 |
| 2 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
95-8990 |
SHAFT-PIVOT, REAR Price: $75.06 |
| 4 |
3220-9 |
NUT-JAM Price: $11.71 |
| 4 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 5 |
86-1480 |
WASHER Price: $4.82 |
| 6 |
136-3415 |
REAR LIFTARM ASM This part replaces 115-3473. Price: $685.84 |
| 7 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
75-7730 |
WASHER-THRUST Price: $2.88 |
| 10 |
100-4944 |
SHAFT-PIVOT, CUTTING UNIT Price: $87.73 |
| 11 |
323-6 |
SCREW-HH Price: $0.66 |
| 12 |
323-4 |
SCREW-HH Price: $1.02 |
| 13 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 13 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 14 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 16 |
121-3616-03 |
GUARD This part replaces 104-0453-03. Price: $35.32 |
| 17 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 19 |
32128-20 |
NUT-HF Price: $0.99 |
| 20 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 21 |
95-8575 |
PIN-CLEVIS Price: $15.31 |
| 22 |
104-4229 |
REAR CARRIER FRAME ASM Price: $470.75 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 23 |
95-8936 |
STRIP-WEAR Price: $93.56 |
| 24 |
3269-18 |
RIVET-BLIND Price: $1.15 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532185534. Price: $44.99 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 116 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 117 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
