| Ref | Part Number | Description |
|---|
| 1 |
120-6272 |
HYD MOTOR ASM This part replaces 98-9999. Price: $846.73 |
| 1 |
603001228 |
BOLT, D722, CAM END Price: $1.99 |
| 1 |
MA-19612632000 |
GRILLE Not Available Price: |
| 2 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 2 |
MA-10372635AG0 |
SCREEN-GRILL UPPER Not Available Price: |
| 3 |
MA-10372636AG0 |
SCREEN-GRILL LOWER Not Available Price: |
| 4 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 4 |
MA-10212626000 |
SCREW TAPPING Not Available Price: |
| 5 |
105-7902 |
HYD HOSE ASM This part replaces 99-5629. Price: $77.63 |
| 5 |
603001235 |
SHAFT, IDLE GEAR Price: $159.99 |
| 5 |
MA-11802482001 |
WASHER Not Available Price: |
| 6 |
603001236 |
BOLT, M6 X 1 X 14 Price: $1.99 |
| 6 |
92-7560 |
HYD HOSE ASM Price: $99.17 |
| 6 |
MA-10352636AG0 |
BRACKET-GRILLE RET Not Available Price: |
| 7 |
105-7901 |
HYD HOSE ASM This part replaces 99-5630. Price: $185.30 |
| 7 |
603001237 |
RING, SNAP Price: $14.99 |
| 7 |
MA-F3000105000 |
NUT-FLANGE HEX Not Available Price: |
| 8 |
105-7901 |
HYD HOSE ASM This part replaces 92-7555. Price: $185.30 |
| 8 |
603001238 |
PUSH ROD Price: $27.99 |
| 8 |
92-7559 |
HYD HOSE ASM Price: $121.91 |
| 8 |
MA-10352637000 |
PLATE (LH) GRILLE HO Not Available Price: |
| 9 |
603001239 |
TAPPET Price: $37.99 |
| 9 |
MA-11740217001 |
GROMMET Not Available Price: |
| 10 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 10 |
MA-H1440106016 |
Bolt, w/Washer Price: $2.83 |
| 11 |
603001240 |
KEY, FEATHER, LONG CAMSHAFT Price: $4.99 |
| 11 |
MA-10352638000 |
BRACKET-GRILLE HOO Not Available Price: |
| 12 |
603001243 |
GEAR, CAM Price: $329.99 |
| 12 |
MA-F3000106000 |
NUT Not Available Price: |
| 13 |
603001244 |
STOPPER, CAMSHAFT Price: $17.99 |
| 13 |
MA-10352639000 |
HOOK-GRILLE LATCH Not Available Price: |
| 14 |
93-4219 |
TUBE ASM Price: $116.65 |
| 14 |
MA-H1440106016 |
Bolt Price: $2.83 |
| 15 |
603001814 |
BALL-CHECK Price: $2.99 |
| 15 |
93-4223 |
FRONT DRAIN TUBE ASM Price: $94.84 |
| 15 |
MA-10352641000 |
PLATE (RH) GRILLE HO Not Available Price: |
| 16 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 16 |
MA-10372654000 |
CUSHION-GRILL LOWE Not Available Price: |
| 17 |
340-70 |
NUT-LOCK Price: $2.10 |
| 17 |
MA-19042635000 |
CUSHION-HEADLAMP Not Available Price: |
| 18 |
240-5 |
GROMMET Price: $13.66 |
| 19 |
69-8960 |
SPACER Price: $5.29 |
| 20 |
69-8930 |
WASHER Price: $0.81 |
| 21 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 22 |
93-9151 |
FITTING-HYD Price: $40.90 |
| 25 |
56-7972 |
CLAMP-TUBE Price: $13.55 |
| 26 |
322-7 |
SCREW-HH Price: $0.89 |
| 27 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 28 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 29 |
99-5617 |
SLEEVE-PROTECTIVE Price: $33.82 |
| 30 |
3290-379 |
TIE-CABLE Price: $0.31 |
