Crankcase & Oil Tank
Parts (24)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 72-3410 | YOKE-FLANGE Price: $259.46 |
| 2 | 54-9180 | U-JOINT KIT Price: $58.18 |
| 3 | 72-3420 | YOKE AND SHAFT ASM Price: $278.13 |
| 4 | 302-58 | FITTING-STRAIGHT Price: $0.81 |
| 5 | 72-3431 | YOKE AND TUBE ASM Price: $413.85 |
| 6 | 62-3820 | FITTING-GREASE Price: $9.52 |
| 11 | 545033501 | OIL TUBE Price: $5.99 |
| 12 | 530055322 | CLIP-U Price: $2.99 |
| 13 | 530055174 | HEATSHIELD, LOWER Price: $2.99 |
| 15 | 530015917 | BAR NUT Price: $2.99 |
| 16 | 530047855 | BAR PLATE Price: $5.99 |
| 17 | 530019228 | OIL TANK GASKET Price: $4.99 |
| 18 | 530036043 | PLATE,BAR MOUNT Price: $4.99 |
| 19 | 530015877 | BAR BOLT 36/41 Price: $4.99 |
| 20 | 530015878 | SCREW Price: $2.99 |
| 21 | 530029850 | CHAIN CATCHER 36/41 Price: $3.99 |
| 22 | 530015893 | SCREW Price: $4.99 |
| 23 | 530052428 | LIMITER COVER Price: $1.99 |
| 24 | 530015922 | CLIP Price: $2.99 |
| 25 | 530029830 | CHOKE GUIDE 36/41 Price: $3.99 |
| 26 | 530029831 | CHOKE 36/41 Price: $3.99 |
| 27 | 530071991 | KIT ASSY CHASSIS Price: $44.99 |
| 28 | 530015922 | CLIP Price: $2.99 |
| 29 | 530016037 | SCREW M5-0.8X35M TAP Price: $2.99 |
