| Ref | Part Number | Description |
|---|
| 1 |
190103GS |
SET, Decal, Unit & Air Cover Price: $29.65 |
| 2 |
M190341GS |
ASSY, Cradle Price: $229.99 |
| 3 |
67989GS |
NUT Price: $2.77 |
| 4 |
81917GS |
PIN, Roll Price: $2.79 |
| 5 |
70642GS |
MOUNT, Vibe Price: $27.27 |
| 6 |
66365GS |
HOUSING, Engine Adapter Price: $60.98 |
| 7 |
86307GS |
SCREW Price: $2.19 |
| 8 |
B2816JGS |
ASSY, Rotor (Includes Item 9) Price: $149.99 |
| 9 |
65791GS |
BEARING, Ball Price: $32.00 |
| 10 |
96796GS |
WASHER Price: $2.79 |
| 11 |
24823GS |
SCREW Price: $16.09 |
| 12 |
190488AGS |
ASSY, Stator Price: $234.99 |
| 13 |
SRV66825DGS |
CARRIER, Rear Bearing Price: $120.36 |
| 14 |
67022GS |
GROMMET, Rubber Price: $2.55 |
| 15 |
86308GS |
SCREW Price: $2.60 |
| 16 |
189645GS |
ASSY, Control Pan (see page 18) Price: $91.99 |
| 17 |
74908GS |
SCREW Price: $2.69 |
| 18 |
189999GS |
DECAL, Control Panel Price: $7.29 |
| 19 |
91825GS |
RECTIFIER, Brush & Bridge Price: $48.14 |
| 20 |
49815GS |
HHCS, M5-0.8 X 16 This part replaces 66849GS. Price: $2.96 |
| 21 |
86494GS |
SCREW, Wing Price: $2.51 |
| 22 |
26850GS |
WASHER, Ext. M6 - 1/4" Shakeproof Price: $2.60 |
| 23 |
195373GS |
WIRE, Ground This part replaces 14353621GS. Price: $1.85 |
| 24 |
B4986GS |
DECAL, Ground Price: $2.75 |
| 25 |
23762GS |
WASHER Price: $2.64 |
| 26 |
195398GS |
TPHMS, M8 - 1.25 x 35 This part replaces 84346GS. Price: $2.49 |
| 27 |
313085GS |
SCREW This part replaces 86292GS. Price: $3.35 |
| 28 |
84242GS |
GROMMET, Plastic RBC Price: $4.19 |
| 29 |
BB3061GS |
BOTTLE, Oil Price: $12.94 |
| 31 |
191775GS |
DECAL, Start Instructions Price: $4.89 |
| 33 |
77816GS |
DECAL, Caution Hot Muffler Price: $3.95 |
| 34 |
190675GS |
MANUAL, Owners Price: Call Us |
| 35 |
275092 |
MANUAL, Engine Price: Call Us |
| 36 |
93639GS |
DECAL, Danger Price: $9.89 |
| 37 |
70644GS |
SCREW Price: $3.79 |
| 38 |
23762GS |
WASHER Price: $2.64 |
| 39 |
55199JGS |
WIRE, Ground, Panel Price: Call Us |
