| Ref | Part Number | Description |
|---|
| 1 |
112-8417 |
GEARCASE ASM This part replaces 98-7545. Price: $1,717.33 |
| 1 |
590486802 |
WHEEL.CARLSTAR.11X4-5".MS417 This part replaces 516001901. Price: $74.99 |
| 2 |
107-0108 |
PLUG This part replaces 98-7546. Price: $2.84 |
| 2 |
539115638 |
ZERK, 3/16, DRIVE IN Price: $4.99 |
| 3 |
596388901 |
Casters This part replaces 539115747. Price: $2.99 |
| 3 |
98-7547 |
O-RING Price: $0.92 |
| 4 |
539117901 |
BUSHING, CASTER Price: $8.99 |
| 4 |
98-7548 |
O-RING Price: $1.09 |
| 5 |
596319801 |
Washers This part replaces 539115675. Price: $2.99 |
| 5 |
98-7549 |
O-RING Price: $1.50 |
| 6 |
595281301 |
Caps This part replaces 539102535. Price: $4.99 |
| 6 |
98-7550 |
PIN-SPRING, START Price: $7.65 |
| 7 |
596301001 |
Casters This part replaces 539115749. Price: $2.99 |
| 7 |
98-7504 |
PIN-STRAIGHT Price: $0.72 |
| 8 |
596319901 |
Screws This part replaces 539115566. Price: $2.99 |
| 8 |
98-7552 |
PACKING-CASE, GEAR Price: $44.07 |
| 9 |
539112660 |
BEARING FLANGED Price: $19.99 |
| 9 |
98-7553 |
BOLT Price: $0.73 |
| 10 |
539105543 |
SPACER Price: $8.99 |
| 10 |
99-8336 |
BOLT This part replaces 98-7554. Price: $3.41 |
| 11 |
539121159 |
RHSNB 1/2-13 X 6.50 GR2 ZD Price: $14.99 |
| 11 |
98-7555 |
BOLT Price: $4.93 |
| 12 |
539200100 |
NUT 1/2-13 HEX CNTRLK GR 5 ZD Price: $3.99 |
| 12 |
98-7556 |
BOLT Price: $2.07 |
| 13 |
595316401 |
Washers This part replaces 539109554. Price: $2.99 |
| 13 |
98-7557 |
BOLT Price: $3.62 |
| 14 |
510186502 |
YOKE.CASTER.BLACK Price: $49.99 |
| 14 |
98-7558 |
BOLT Price: $1.60 |
| 15 |
539114805 |
SPACER, 5/16" Price: $9.99 |
| 15 |
98-7535 |
WASHER-SPRING Price: $0.32 |
| 16 |
539106994 |
RIM Price: $44.99 |
| 16 |
98-7536 |
WASHER-PLAIN Price: $0.28 |
| 17 |
539114697 |
TIRE.11"X4"-5.4PLY.SMOOTH.KEND Price: $32.99 |
| 17 |
98-7561 |
JOINT-PIPE Price: $23.49 |
| 18 |
576617801 |
BUSHING, WHEEL, 3/4" Price: $4.99 |
| 18 |
98-7562 |
WASHER-PLAIN Price: $0.36 |
| 19 |
539103300 |
ZERK Price: $2.99 |
| 19 |
98-7563 |
SPRING Price: $2.74 |
| 20 |
539912234 |
VALVE STEM TR-412 Price: $3.99 |
| 20 |
98-7564 |
SEAT-VALVE Price: $9.15 |
| 21 |
581197601 |
WHEEL.18X8.50-8.4P.K358.8X7.4H This part replaces 539112212. Price: $129.99 |
| 21 |
98-7565 |
BALL Price: $0.33 |
| 22 |
539112214 |
RIM.8X7.SILVER.ZTR Price: $64.99 |
| 22 |
98-7566 |
FLANGE-RETURN, WATER Price: $59.56 |
| 23 |
115-8521 |
GASKET-FLANGE, RETURN This part replaces 98-7567. Price: $2.63 |
| 24 |
98-7568 |
BOLT Price: $0.84 |
| 25 |
98-7569 |
COVER Price: $6.40 |
| 26 |
98-7570 |
GASKET-METER, HOUR Price: $12.56 |
| 27 |
98-7571 |
STUD Price: $2.00 |
| 28 |
98-7572 |
NUT Price: $0.32 |
| 29 |
98-7699 |
WASHER-SPRING This part replaces 98-7515. Price: $0.44 |
