| Ref | Part Number | Description |
|---|
| 1 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 1 |
683-04305B-0637 |
FRAME ASSEMBLY (POWDER BLACK) Not Available This part replaces 683-04305B. Price: |
| 2 |
710-04379A |
Screw, Hex Cap Lock, 7/16-20 x 3.5 Gr5 Price: $5.35 |
| 2 |
93-6847-03 |
PANEL-FRONT, RIGHT This part replaces 93-6847. Price: $103.08 |
| 3 |
32148-7 |
NUT-CLINCH Price: $0.98 |
| 3 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 4 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 4 |
710-04666 |
Screw, Hex Flange Hd. , 1/4-20 x .75 Gr5 Price: $6.04 |
| 5 |
710-0599 |
Screw, Hex Wash. Hd. Tapp, 1/4-20 x .5 Price: $3.86 |
| 5 |
93-6846 |
DISCONTINUED Price: Call Us |
| 6 |
710-0642 |
Screw, Hex Wash. Hd. Tapp, 1/4-20 x .75 Price: $4.05 |
| 6 |
83-8120 |
DISCONTINUED Price: Call Us |
| 7 |
710-3005 |
Screw, Hex Cap, 3/8-16 x 1.25 Gr5 Price: $3.61 |
| 7 |
85-5340 |
TUBE-PIVOT, SEAT Price: $5.84 |
| 8 |
321-11 |
SCREW-HH Price: $0.36 |
| 8 |
712-0271 |
Nut, Hex Sems, 1/4-20 Price: $3.78 |
| 9 |
712-04064 |
Nut, Hex Flange Insert Lock, 1/4-20 GrF Price: $3.64 |
| 9 |
85-5230 |
BRACKET-PIVOT, SEAT Price: $9.78 |
| 10 |
3229-11 |
SCREW-CARR Price: $0.99 |
| 10 |
712-04065 |
Nut, Hex Flange Insert Lock, 3/8-16 GrF Price: $3.68 |
| 11 |
712-3087 |
WING NUT 1/4-20 Price: $3.53 |
| 11 |
85-5330-01 |
PLATE-SEAT ASM This part replaces 85-5330. Price: $88.55 |
| 12 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 12 |
917-04174A |
P.T.O. Clutch This part replaces 717-04174A. Price: $596.44 |
| 13 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 13 |
725-0157 |
Cable Tie Price: $3.46 |
| 15 |
2412-133 |
CLAMP-R Price: $3.19 |
| 15 |
925-1707D |
BATTERY Not Available Price: |
| 16 |
2412-39 |
CLAMP-R Price: $1.70 |
| 16 |
731-05659 |
Bushing, Steering Shaft Price: $9.09 |
| 17 |
32128-44 |
NUT Price: $2.69 |
| 17 |
736-0171 |
Washer, Lock, 7/16 Price: $3.86 |
| 18 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 18 |
738-04058 |
Screw, Shoulder, .38 x 1.0 x .7 Price: $3.86 |
| 19 |
738-1132 |
Screw, Shoulder, .25 x .15:1/4-20 Price: $4.47 |
| 19 |
94-3632 |
DISCONTINUED Price: Call Us |
| 20 |
747-04215A |
BATTERY STRAP This part replaces 747-04215. Price: $14.73 |
| 20 |
93-7270 |
DECAL-CONTROL Price: $7.93 |
| 21 |
750-04763 |
Spacer, 1.37 x 1.00 x .25 Price: $9.86 |
| 21 |
93-6761 |
DECAL-REELMASTER 2300D Price: $76.05 |
| 22 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 22 |
756-0978B |
Pulley, Engine Price: $58.13 |
| 23 |
37-9590 |
DISCONTINUED Price: Call Us |
| 23 |
783-04419B-0637 |
Clutch Bracket This part replaces 783-04419B. Price: $12.80 |
| 24 |
28-6180 |
PIN-PEDAL Price: $5.05 |
| 24 |
783-04467 |
DECK UP STOP BRACKET Not Available Price: |
| 25 |
27-9870 |
PIN-SWITCH, SEAT Price: $31.55 |
| 25 |
783-04806 |
PIVOT BAR BRACKET Not Available Price: |
| 26 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 26 |
783-04844 |
PIVOT SUPPORT BRACKET (RH) Not Available Price: |
| 27 |
70-1480 |
RELAY Price: $105.19 |
| 27 |
783-04845 |
PIVOT SUPPORT BRACKET (LH) Not Available Price: |
| 28 |
32128-33 |
NUT-HF Price: $0.25 |
| 28 |
783-04868-0637 |
STEERING SUPPORT BRACKET Not Available This part replaces 783-04868. Price: |
| 29 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 29 |
783-04910A-0637 |
SUPPORT BRACKET Not Available This part replaces 783-04910A. Price: |
| 30 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 30 |
783-05469 |
BATTERY BRACKET TRAY Not Available Price: |
| 31 |
321-8 |
SCREW-HH Price: $0.34 |
| 31 |
783-05617-0637 |
SUPPORT BRACKET Not Available This part replaces 783-05617. Price: |
| 32 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 32 |
783-05760-0637 |
BRACKET SUPPORT Not Available This part replaces 783-05760. Price: |
| 33 |
783-05850A-0637 |
FRAME SEAT PLATE Not Available This part replaces 783-05850. Price: |
| 34 |
710-0726 |
Screw, Hex Wash. Hd. Tapp, 5/16-12 x .75 Price: $3.82 |
| 34 |
93-6868-03 |
STEP-FOOT This part replaces 93-6868. Price: $438.49 |
| 35 |
218-461 |
NUT-HH Price: $2.50 |
| 36 |
92-3188 |
DIODE-BOARD, CIRCUIT Price: $53.82 |
| 37 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 38 |
256-321 |
BUSHING Price: $2.75 |
| 39 |
93-6903 |
DECAL - QUICK REF Price: $26.25 |
| 39 |
94-2598 |
DECAL-SERVICE,PORTUGUESE Price: $115.19 |
| 40 |
83-9550 |
DECAL-WARNING Price: $12.60 |
| 41 |
76-6471 |
STRIP-SEAL, FIREWALL Price: $14.64 |
| 42 |
62-7170 |
SPACER-RUBBER Price: $28.36 |
| 43 |
94-3694 |
DISCONTINUED Price: Call Us |
| 44 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 47 |
93-6938-01 |
SHIELD-FOOTREST This part replaces 93-6938. Price: $41.89 |
| 51 |
2412-106 |
CLAMP-R Price: $2.04 |
| 52 |
93-6732-03 |
PANEL-REAR, LEFT This part replaces 93-6732. Price: $99.92 |
| 55 |
237-37 |
BUMPER-RUBBER Price: $4.33 |
| 56 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 57 |
93-6924 |
TRIM-LOK Price: $4.13 |
| 58 |
93-6908 |
SPACER-SPLIT Price: $5.37 |
| 59 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 60 |
321-9 |
SCREW-HH This part replaces 322-23. Price: $0.27 |
| 61 |
94-3633 |
U-BRACKET ASM Price: $73.76 |
| 62 |
94-3691-03 |
PANEL-INSTRUMENT ASM This part replaces 94-3691. Price: $124.28 |
| 64 |
321-3 |
SCREW-HH Price: $0.28 |
| 65 |
87-8640 |
WASHER-FLAT Price: $0.68 |
| 66 |
322-9 |
SCREW-HH Price: $3.09 |
| 67 |
2412-104 |
CLAMP-R Price: $2.37 |
| 68 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 69 |
56-7976 |
CLAMP-TUBE Price: $2.44 |
| 70 |
237-30 |
O-RING Price: $2.50 |
| 71 |
43-8610 |
GUIDE Price: $23.35 |
| 72 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 73 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 74 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 75 |
237-7 |
O-RING Price: $8.82 |
| 76 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 77 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 501485402 |
501485402 |
SPARK PLUG CONN. KIT Price: $6.99 |
| 502195901 |
502195901 |
FLYWHEEL Price: $95.99 |
| 503221011 |
503221011 |
NUT M8X1 Price: $3.99 |
| 503230101 |
503230101 |
WASHER 8.4X16 Price: $3.99 |
| 530015226 |
530015226 |
STARTER PAWL PIN Price: $2.99 |
| 530039145 |
537380901 |
MODULE FLYWHEEL KIT This part replaces 530039145. Price: $98.99 |
| 530042058 |
530042058 |
STARTER DOG Price: $2.99 |
| 530042059 |
530023817 |
SPRING STR DOG This part replaces 530042059. Price: $3.99 |
