CHASSIS & ENCLOSURES
Parts (53)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 127-3011 | STUD Price: $8.87 |
| 1 | 532121232 | CAP.SPINDLE.BLACK Price: $3.99 |
| 2 | 125-7120 | ALTERNATOR-12V Price: $755.08 |
| 2 | 812000029 | RING CLIP Price: $3.99 |
| 3 | 127-3190 | NUT Price: $4.86 |
| 3 | 532121748 | WASHER Price: $3.99 |
| 4 | 127-2951 | ROTOR ASM Price: $326.08 |
| 4 | 532121922 | NYLINER Price: $5.99 |
| 5 | 127-2983 | BEARING-BALL Price: $23.48 |
| 5 | 532128543 | AXLE FRT Price: $33.66 |
| 6 | 127-2962 | COVER Price: Call Us |
| 6 | 532006266 | WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 | 127-2952 | FRAME ASM Price: Call Us |
| 7 | 532121919 | SPINDLE RH Price: $20.99 |
| 8 | 127-2958 | BEARING-BALL Price: $25.78 |
| 8 | 532059192 | VALVE CAP Price: $4.99 |
| 9 | 127-2959 | PLATE-RETAINER Price: Call Us |
| 9 | 532065139 | VALVE STEM LT Price: $5.99 |
| 10 | 127-2960 | SCREW Price: Call Us |
| 10 | 532137237 | FRONT RIM 6" WHITE This part replaces 532124972. Price: $80.99 |
| 11 | 127-2961 | STUD Price: Call Us |
| 11 | 532009040 | BEARING.FLANGE Price: $6.99 |
| 12 | 127-2953 | FRAME ASM Price: $57.52 |
| 12 | 532059904 | TUBE.5.3/4.5/6 Price: $19.99 |
| 13 | 127-2954 | PULLEY Price: $69.59 |
| 13 | 532123410 | TIRE.13X5-6.TURF.SAVER.FRONT Price: $44.99 |
| 14 | 127-2955 | NUT Price: Call Us |
| 14 | 532121749 | WASHER Price: $2.99 |
| 15 | 127-2957 | COLLAR Price: $16.32 |
| 15 | 532104757 | CAP.HUB.FRONT.LT.BLACK Price: $3.99 |
| 16 | 127-3002 | REGULATOR ASM Price: $643.65 |
| 16 | 532000278 | FITTING LT. Price: $5.99 |
| 17 | 127-2963 | HOLDER Price: $253.39 |
| 17 | 596029601 | Pins This part replaces 876020416. Price: $1.99 |
| 18 | 127-2993 | HOLDER Price: $95.21 |
| 18 | 596565301 | WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 19 | 127-2956 | BRUSH ASM Price: $8.83 |
| 20 | 127-2964 | SPRING Price: $3.16 |
| 20 | 532121924 | ROD TIE Price: $66.99 |
| 21 | 127-2965 | SCREW Price: Call Us |
| 21 | 532121916 | SPINDLE LH Price: $29.99 |
| 22 | 127-2966 | SCREW Price: Call Us |
| 23 | 127-2999 | COVER Price: $22.03 |
| 24 | 127-2967 | BOLT Price: $9.43 |
| 25 | 127-2968 | SCREW Price: $4.72 |
| 26 | 127-2969 | BOLT Price: Call Us |
| 27 | 127-2970 | BUSHING-INSULATION Price: Call Us |
| 28 | 127-2971 | NUT Price: Call Us |
| 29 | 127-2972 | WASHER Price: Call Us |
| 30 | 125-7230 | NUT Price: $2.81 |
| 31 | 125-6947 | SPACER Price: $21.65 |
| 32 | 127-2977 | ADJUSTER Price: $113.82 |
| 33 | 125-7134 | BOLT Price: $25.74 |
