| Ref | Part Number | Description |
|---|
| 1 |
325-20 |
SCREW-HH Price: $6.29 |
| 1 |
532142103 |
DRIVE CONTROL Price: $64.99 |
| 2 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 3 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $4.99 |
| 4 |
532700875 |
BOLT Price: $3.99 |
| 5 |
532850845 |
HUB CAP Price: $3.99 |
| 6 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 6 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 7 |
596040101 |
Washers This part replaces 532052160. Price: $2.99 |
| 7 |
92-7594 |
HOSE ASM Price: $94.90 |
| 8 |
532193144 |
KIT.WHEEL.8X2.RADIAL.BLACK This part replaces 532700953. Price: $27.99 |
| 8 |
92-7595 |
HOSE-HYD Price: $102.70 |
| 9 |
32136-14 |
NUT-HST Price: $3.38 |
| 9 |
812000058 |
E-RING 7/16 RE Price: $2.99 |
| 10 |
532137054 |
PINION GEAR Price: $4.99 |
| 10 |
76-8350 |
STOP-AXLE Price: $10.92 |
| 11 |
3296-45 |
NUT-HEX Price: $3.79 |
| 11 |
581840401 |
COVER.DUST.WHEEL.INNER.WALK This part replaces 532088080. Price: $5.99 |
| 12 |
3256-29 |
WASHER-FLAT Price: $2.59 |
| 12 |
532701037 |
SELECTOR KNOB Price: $4.99 |
| 13 |
532151009 |
WHEEL ADJUSTER ASSY (LEFT) Price: $20.99 |
| 13 |
94-8000 |
NUT-HEX Price: $2.65 |
| 14 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 14 |
532151010 |
WHEEL ADJUSTER KIT RH Price: $30.99 |
| 15 |
532088118 |
WASHER Price: $3.99 |
| 15 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 16 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 16 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 17 |
62-2170 |
WASHER-THRUST Price: $4.48 |
| 18 |
532137090 |
SPRING.EXTENSION Price: $4.99 |
| 18 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 19 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 20 |
532075192 |
SPRING Price: $4.99 |
| 20 |
94-5607 |
AXLE ASM Price: $1,648.44 |
| 21 |
532067725 |
WASHER FLUT Price: $5.99 |
| 21 |
92-9725-03 |
LH SPINDLE ASM This part replaces 92-9725. Price: $553.13 |
| 22 |
532187211 |
TRANSMISSION 22RD This part replaces 532702511. Price: $89.99 |
| 22 |
69-2980 |
SEAL Price: $33.94 |
| 23 |
254-106 |
CONE-BEARING, TAPERED Price: $19.51 |
| 23 |
532194126 |
DRIVEN PULLEY This part replaces 532137052. Price: $9.99 |
| 24 |
254-107 |
CUP-BEARING, TAPERED Price: $9.93 |
| 24 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532132010. Price: $3.99 |
| 25 |
114-3908 |
HUB ASM This part replaces 92-9651. Price: $129.48 |
| 26 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 27 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 27 |
532700479 |
DRIVE COVER-GRAY Price: $5.83 |
| 28 |
532087866 |
SCREW PM Price: $3.90 |
| 28 |
86-5910 |
TIRE-6 PLY Price: $114.98 |
| 29 |
120-8909 |
RIM This part replaces 217-125. Price: $198.53 |
| 29 |
532149746 |
SCREW.SLOT.TORX. This part replaces 532136797. Price: $5.99 |
| 30 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 30 |
532131841 |
DECAL (DRIVE COVER) Price: $3.30 |
| 31 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 32 |
532157769 |
KIT.SERVICE.BELT/SPRING. This part replaces 532137078. Price: $14.99 |
| 32 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 33 |
95-7152 |
PROTECTOR - BEARING Price: $24.66 |
| 34 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 35 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 36 |
92-9652 |
STUD-BOLT Price: $4.89 |
| 37 |
3220-7 |
NUT-JAM Price: $4.09 |
| 38 |
532086012 |
DRV SHAFT TUBE PM Price: $5.46 |
| 38 |
92-5839 |
JOINT-BALL Price: $207.89 |
| 39 |
532086960 |
BUSHING.1.860 X .505. Price: $4.99 |
| 39 |
94-8142 |
HYD CYLINDER ASM Price: $802.19 |
| 40 |
94-9973 |
RING-RETAINING Price: $1.02 |
| 41 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 42 |
237-78 |
O-RING Price: $3.85 |
| 43 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 44 |
237-22 |
O-RING Price: $2.43 |
| 45 |
92-5833 |
SPACER-JOINT, BALL Price: $20.71 |
| 46 |
3210-5 |
SCREW-HH Price: $0.54 |
| 47 |
105-7815 |
TIE ROD ASM This part replaces 74-5940. Price: $573.88 |
| 48 |
2411-46-03 |
LH TIE ROD ASM This part replaces 2411-46. Price: $128.10 |
| 48 |
71-4740-03 |
RH TIE ROD END ASM This part replaces 2411-45. Price: $163.79 |
| 49 |
32152-5 |
NUT-HEX Price: $0.54 |
| 50 |
105-7815 |
TIE ROD ASM This part replaces 2412-122. Price: $573.88 |
| 51 |
94-5603 |
BUSHING-METRIC Price: $110.04 |
| 52 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 53 |
94-8115 |
DISCONTINUED Price: Call Us |
| 54 |
92-7604 |
DISCONTINUED Price: Call Us |
| 55 |
93-7247 |
WASHER-THRUST Price: $3.46 |
| 56 |
92-7495 |
STEERING TUBE ASM Price: $148.27 |
| 57 |
340-70 |
NUT-LOCK Price: $2.10 |
| 58 |
237-22 |
O-RING Price: $2.43 |
| 59 |
92-7494 |
REAR STEARING TUBE ASM Price: $150.03 |
| 60 |
106-6898 |
JOINT-BALL This part replaces 92-5837. Price: $210.81 |
| 61 |
3220-11 |
NUT-JAM Price: $0.81 |
| 62 |
94-2807 |
ADAPTOR-NUT, WHEEL Price: $17.80 |
| 63 |
100-3895-03 |
WEIGHT-WHEEL This part replaces 94-3052. Price: $841.13 |
| 64 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 65 |
3213-14 |
SCREW-HH Price: $8.01 |
| 532750320 |
DECAL |
HEIGHT ADJUST RH NLA Price: $5.53 532750320 |
