| Ref | Part Number | Description |
|---|
| 2 |
779-3348 |
LABEL-FLAG Not Available Price: |
| 3 |
710-3038 |
Screw, Hex Cap, 5/16-18 X .88 Lg GR5 Price: $4.17 |
| 4 |
736-0159 |
Washer, Flat, .344 X .875 X .06 Thk Price: $3.71 |
| 5 |
932-3069 |
COMPRESSION SPRING1.28 OD x 2.18 Not Available This part replaces 732-3069. Price: |
| 6 |
722-0160 |
RUBBER BUSHING .318IDX.930OD Not Available Price: |
| 7 |
712-3009 |
Nut, Hex Center Lock, 5/16-18 GR5 Price: $5.99 |
| 8 |
703-1813 |
SEAT CHANNEL Not Available Price: |
| 9 |
738-0145 |
Screw, Shoulder, .500 Dia X .840 Price: $6.01 |
| 10 |
732-3060 |
COMPRESSION SPRING Not Available Price: |
| 11 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 12 |
712-3017 |
HEX NUT 3/8-16 GR5 Price: $3.90 |
| 13 |
710-3215 |
BOLT-SHT NK CARR 5/16-18X Not Available Price: |
| 14 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 15 |
712-3010 |
HEX NUT 5/16-18 This part replaces 7123010. Price: $3.89 |
| 16 |
703-1844 |
SLIDE-SEAT Not Available Price: |
| 18 |
710-3216 |
SCREW-SOCKET HD 5/16-18X1.0 LG Not Available Price: |
| 19 |
703-1811 |
BRACKET, SEAT PIVOT SUPPORT Not Available Price: |
| 20 |
703-1812 |
BRACKET, SEAT PIVOT Not Available Price: |
| 21 |
738-0140 |
Screw, Shoulder, .437 Dia X .180 Price: $4.93 |
| 22 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 23 |
736-0242 |
Washer, Bell, .345 X .88 X .060 Thk Price: $3.75 |
| 24 |
779-3524 |
LABEL, SEAT ADJUSTMENT Not Available Price: |
| 25 |
759-3603 |
HANDLE COVER Not Available Price: |
| 501691701 |
531222001 |
COMBINATION WRENCH COMBI TOOL This part replaces 501691701. Price: $5.99 |
| 501911401 |
501911402 |
GREASES This part replaces 501911401. Price: $7.99 |
| 503217016 |
503217016 |
SCREW Price: $2.99 |
| 503558501 |
531222001 |
COMBINATION WRENCH COMBI TOOL This part replaces 503558501. Price: $5.99 |
| 503558601 |
503558601 |
L-SPANNER Price: $2.99 |
| 503558602 |
503558602 |
L-SPANNER Price: $2.99 |
| 503621201 |
503551601 |
OIL CAP This part replaces 503621201. Price: $6.99 |
| 503978801 |
503978801 |
PROTECTOR Price: $22.99 |
