| Ref | Part Number | Description |
|---|
| 1 |
82-5510 |
DECAL-WARNING Price: $7.09 |
| 2 |
56-4780-03 |
IMPELLER ASM This part replaces 56-4780. Price: $926.99 |
| 3 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 4 |
77-5820-03 |
MOUNTING PLATE ASM This part replaces 77-5820. Price: $255.76 |
| 5 |
80-2820-03 |
BRACKET-PIVOT, REAR This part replaces 80-2820. Price: $51.76 |
| 6 |
77-5440-03 |
DISCONTINUED This part replaces 77-5440. Price: Call Us |
| 7 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 8 |
62-6520 |
KNOB Price: $7.79 |
| 9 |
3257-40 |
KEY Price: $7.99 |
| 10 |
53-4530-03 |
GEAR BOX ASM This part replaces 53-4530. Price: $1,650.99 |
| 11 |
77-5630-03 |
GEARBOX PULLEY COVER This part replaces 77-5630. Price: $26.25 |
| 12 |
3255-17 |
WASHER-LOCK, EXT Price: $0.29 |
| 13 |
3290-134 |
SCREW Price: $0.27 |
| 14 |
323-7 |
SCREW-HH Price: $0.65 |
| 15 |
80-2810-03 |
BRACKET-PIVOT, FRONT This part replaces 80-2810. Price: $56.56 |
| 16 |
3218-3 |
NUT-JAM Price: $0.25 |
| 17 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 18 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 19 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 20 |
63-9710 |
SPACER-BEARING Price: $10.24 |
| 21 |
321-3 |
SCREW-HH Price: $0.28 |
| 22 |
13-0269 |
BLOWER HOUSING ASM Price: $579.99 |
| 23 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 24 |
37-6730 |
CUP-BEARING Price: $15.84 |
| 25 |
38-7820 |
BEARING-BALL Price: $13.99 |
| 26 |
63-9700-03 |
PLATE-COVER This part replaces 63-9700. Price: $18.43 |
| 27 |
43-0940 |
SPACER Price: $1.25 |
| 28 |
3235-22 |
SCREW-HH, LOCK Price: $2.59 |
| 29 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 30 |
43-0960-03 |
BRACKET-CHUTE This part replaces 43-0960. Price: $18.26 |
| 32 |
3290-409 |
RIVET Price: $0.34 |
| 33 |
107-2926 |
DECAL-PLATE, WARNING This part replaces 80-4670. Price: $23.04 |
| 34 |
3290-271 |
RIVET-POP Price: $0.25 |
| 35 |
80-3720 |
CHUTE ASM Price: $470.17 |
| 539101331 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 539102612 |
539102612 |
SCREW 3/8C X 2 3/4 HEX CAP Price: $4.99 |
| 539103230 |
539103230 |
IDLER ARM Price: $159.99 |
| 539103257 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 539103258 |
539103258 |
IDLER PULLEY (TALL) Price: $44.99 |
| 539103295 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 539103299 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 539103303 |
596770301 |
Washers This part replaces 539103303. Price: $4.99 |
| 539103427 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 539103433 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 539105192 |
539105192 |
DECK SPRING Price: $13.99 |
| 539105476 |
539105476 |
BLADE OEM - 25" Price: $34.99 |
| 539106504 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 539107279 |
539112126 |
PULLEY, 72 This part replaces 539107279. Price: $44.99 |
| 539108073 |
596438501 |
Bolts This part replaces 539108073. Price: $2.99 |
| 539108449 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 539108450 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 539108754 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 539109246 |
539109246 |
PIN COTTER 1/8 X 1 ZD Price: $4.99 |
| 539109660 |
539109660 |
DRAW LATCH Price: $13.99 |
| 539109693 |
594722001 |
Chains This part replaces 539109693. Price: $3.99 |
| 539110737 |
539110737 |
SPRING - TORSION Price: $12.99 |
| 539110739 |
539110739 |
PIN - CLEVIS 5/16 DIA X4.69 ZD Price: $5.99 |
| 539111379 |
539111379 |
DECK W/DECALS 72" HUS Price: $6,799.99 |
| 539111561 |
539111561 |
DECAL, TUNNEL RAM 8" Price: $6.99 |
| 539111897 |
596917301 |
Washers This part replaces 539111897. Price: $4.99 |
| 539112120 |
539112120 |
HCS 7/16-20 GD 8 SPEC Price: $24.99 |
| 539112123 |
539112123 |
SPINDLE 72 NLA-ORDER HOUSING Price: $26.18 |
| 539112484 |
539112484 |
SPRING WASHER - .50 Price: $7.99 |
| 539114404 |
539114404 |
SPACER Price: $6.99 |
| 539114405 |
539114405 |
SWIVEL Price: $14.99 |
| 539114820 |
966956101 |
KIT HSG ASM 52/61 This part replaces 539114820. Price: $129.99 |
| 539119227 |
539119227 |
BOLT, EYE Price: $14.99 |
| 539976979 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 539976998 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 539977326 |
539977326 |
PLUG-VENTED Price: $8.99 |
| 539990247 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 539990333 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 539990365 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 539990550 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 539990582 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 539990627 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 539990717 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
