| Ref | Part Number | Description |
|---|
| 1 |
323-12 |
SCREW-HH Price: $1.14 |
| 1 |
532186094 |
STEERING WHEEL.PREM.2.BLK This part replaces 532193651. Price: $169.99 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 2 |
83-1040 |
WASHER-FLAT Price: $2.31 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 3 |
83-1050 |
SPACER Price: $3.26 |
| 4 |
121-9076 |
MOUNT-ENGINE This part replaces 83-1030. Price: $37.76 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
108-6539 |
MANIFOLD-EXHAUST This part replaces 83-1080. Price: $249.13 |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
3274-7 |
SCREW-HSH Price: $0.91 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 10 |
83-1060-0P |
PUMP MOUNT - MACH. *B This part replaces 83-1060. Price: $249.55 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
2112-11 |
CLAMP-MUFFLER Price: $7.37 |
| 15 |
106-4619 |
ENGINE KIT 18HP VANGUARD GAS This part replaces 83-0010. Price: $3,846.49 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
112-0220 |
GRILLE-MUFFLER This part replaces 83-1400. Price: $18.94 |
| 17 |
12-3270 |
SCREW Price: $3.09 |
| 17 |
532177883 |
SHAFT ASM STRG Price: $104.99 |
| 18 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 19 |
493963 |
Muffler Price: Call Us |
| 20 |
83-2220 |
DISCONTINUED- BRIGGS 222902 Price: Call Us |
| 21 |
322-8 |
SCREW-HH Price: $1.26 |
| 22 |
83-2230 |
DISCONTINUED- BRIGGS 93705 Price: Call Us |
| 23 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 24 |
83-1630-03 |
BRACKET-SUPPORT, MUFFLER This part replaces 83-1630. Price: $129.03 |
| 25 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 26 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 27 |
321-4 |
SCREW-HH Price: $0.99 |
| 28 |
85-8120-0P |
ENGINE MOUNT PLATE *B This part replaces 85-8120. Price: $114.20 |
| 29 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
324-7 |
SCREW-HH Price: $1.79 |
| 31 |
32128-20 |
NUT-HF Price: $0.99 |
| 32 |
322-3 |
SCREW-HH Price: $0.79 |
| 32 |
532180580 |
ROD TIE BALL J WSL Price: $109.99 |
| 33 |
43-2830 |
NUT-HEX Price: $0.39 |
| 35 |
83-2310 |
SHIELD-REGULATOR Price: $14.57 |
| 36 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 39 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK This part replaces 532195602. Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 94 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
