| Ref | Part Number | Description |
|---|
| 1 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 1 |
586341502 |
Cylinder Price: $179.99 |
| 2 |
32128-20 |
NUT-HF Price: $0.99 |
| 2 |
586446204 |
Pistons Price: $59.99 |
| 3 |
737441000 |
LOCKING RING Price: $2.99 |
| 3 |
82-8970 |
DECAL-COOLANT, ENGINE Price: $16.00 |
| 4 |
66-3240 |
CAP-RADIATOR Price: $25.30 |
| 5 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 5 |
503255501 |
NEEDLE BEARING Price: $9.99 |
| 6 |
105-2919 |
HOOD ASM This part replaces 14-8459. Price: $791.02 |
| 6 |
505457001 |
GASKET Price: $4.99 |
| 7 |
505408301 |
GASKET Price: $4.99 |
| 7 |
66-6140 |
DECAL Price: $25.48 |
| 8 |
93-3188 |
DECAL - GM 325D Price: $60.98 |
| 9 |
3290-271 |
RIVET-POP Price: $0.25 |
| 9 |
576355902 |
SUPPORT Price: $5.99 |
| 10 |
249-40 |
KEEPER Price: $9.77 |
| 10 |
531008615 |
CMR6H NGK SPARK PLUG This part replaces 574519601. Price: $8.99 |
| 11 |
77-3100 |
DECAL-WARNING Price: $7.89 |
| 12 |
43-3350 |
UPPER RADIATOR HOSE Price: $77.00 |
| 13 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 14 |
43-3330-03 |
RADIATOR SHROUD This part replaces 43-3330. Price: $162.11 |
| 15 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 16 |
33-2570 |
DISCONTINUED Price: Call Us |
| 17 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 18 |
59-9740 |
FLEX DRAW LATCH ASM This part replaces 249-39. Price: $36.89 |
| 19 |
43-7020 |
LOWER RADIATOR HOSE Price: $86.36 |
| 20 |
43-3320 |
FOAM-RADIATOR Price: $24.27 |
| 21 |
304-46 |
DRAINCOCK Price: $7.55 |
| 22 |
38-4600 |
LH FRAME BAR Price: $29.16 |
| 23 |
323-14 |
SCREW-HH Price: $1.34 |
| 24 |
63-9010 |
HOSE-COOLANT, TRANSMISSION Price: $83.18 |
| 25 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 26 |
340-70 |
NUT-LOCK Price: $2.10 |
| 27 |
68-9160 |
BRACKET Price: $16.82 |
| 28 |
32128-21 |
NUT-HF Price: $0.39 |
| 29 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 30 |
63-8960 |
HOSE Price: $111.27 |
| 31 |
2412-39 |
CLAMP-R Price: $1.70 |
| 32 |
43-3340-03 |
PLATE-GRILLE, SEALING This part replaces 43-3340. Price: $64.16 |
| 33 |
322-6 |
SCREW-HH Price: $0.45 |
| 34 |
32144-102 |
SCREW-HWH This part replaces 11-0590. Price: $3.19 |
| 35 |
105-2918 |
RADIATOR SUPPORT ASM This part replaces 88-1820. Price: $504.61 |
| 36 |
67-9030-03 |
GRILLE ASM This part replaces 67-9030. Price: $254.81 |
| 37 |
32103-2 |
NUT-WING Price: $0.68 |
| 38 |
5-0838 |
WASHER Price: $1.09 |
| 39 |
283-76 |
PIN-LYNCH Price: $6.67 |
| 40 |
84-5330 |
BRACKET-PROP, HOOD Price: $14.29 |
| 41 |
84-5380 |
STRAP-PROP, HOOD Price: $46.67 |
| 42 |
321-6 |
SCREW-HH Price: $0.25 |
| 43 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 44 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 45 |
86-9410-01 |
SEAT SUPT BRKT WA This part replaces 86-9410. Price: $153.46 |
| 46 |
38-3400 |
GUARD-RUBBER Price: $8.02 |
