| Ref | Part Number | Description |
|---|
| 1 |
27-3710 |
DIPSTICK Price: $24.62 |
| 1 |
428699 |
Logo, Scag Tiger Cat II (LH) Price: Call Us |
| 2 |
3219-2 |
NUT-HEX Price: $0.37 |
| 2 |
48136-17 |
Clamp, 3-1/2" Max. Dia. Price: Call Us |
| 3 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 3 |
484287 |
Carbon Canister - SVR-36A / SVR-48V Price: Call Us |
| 4 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 4 |
48059-05 |
Clamp, Vapor Recovery Hose 3/16" Price: Call Us |
| 5 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 5 |
484345 |
Hose, Vapor Recovery 3/16" Price: Call Us |
| 6 |
21-7670 |
CASE-DIFFERENTIAL Price: $687.90 |
| 6 |
483617 |
Fuel Hose, 1/4" I.D. Non-Perm (791DFI Fuel Return) Price: Call Us |
| 7 |
21-7700 |
SHAFT-MATE, PINION Price: $54.05 |
| 7 |
48059-01 |
Clamp, Fuel Hose 1/4" Hose I.D. Price: Call Us |
| 8 |
21-7720 |
WASHER-THRUST Price: $3.39 |
| 9 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 24-8790. Price: $702.98 |
| 9 |
48935-02 |
Tee, 3/16 x 3/16 x 3/16 Union, Hose Barb Price: Call Us |
| 10 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 21-7690. Price: $702.98 |
| 10 |
484286 |
Fuel Cap w/ Tether (E.P.A.) Price: Call Us |
| 11 |
21-7730 |
WASHER-THRUST, PINION Price: $2.65 |
| 11 |
484279-01 |
Tube, Fuel Tank Insert - 4" Price: Call Us |
| 12 |
484323 |
Fuel Gauge Assembly Price: Call Us |
| 13 |
43-6760 |
BEARING-ROLLER, CONE TAPER Price: $113.20 |
| 13 |
484242 |
Grommet, Fuel Gauge Price: Call Us |
| 14 |
484333 |
Remote Vent, No Valve Price: Call Us |
| 14 |
92-1773 |
SCREW-HHF This part replaces 324-23. Price: $3.05 |
| 15 |
12-5450 |
SCREW Price: $7.99 |
| 15 |
484285 |
Grommet, Viton, Price: Call Us |
| 16 |
21-7830 |
COVER-GEAR Price: $26.87 |
| 16 |
48059-02 |
CLAMP, FUEL HOSE(KAWASAKI ONLY) Price: Call Us |
| 17 |
484347 |
Hose, 1/4" Vapor Recovery (order by inch) Price: Call Us |
| 17 |
86-7230 |
GEAR-INPUT, TRANSMISSION This part replaces 21-8150. Price: $610.12 |
| 18 |
43-6710 |
SHIM-PINION (.003) Price: $2.17 |
| 18 |
484343-01 |
Mender, 1/4 x 3/16 w/0.02 Hole Price: Call Us |
| 19 |
43-6711 |
SHIM-PINION (.005) Price: $3.80 |
| 19 |
485637 |
Fuel Tube Assembly, Includes Valve Price: Call Us |
| 20 |
43-6712 |
SHIM-PINION (.010) Price: $3.19 |
| 20 |
482571 |
Bushing, 0.56" Dia. Viton Price: Call Us |
| 21 |
43-6713 |
SHIM-PINION (.030) Price: $6.99 |
| 21 |
484552 |
Fuel Tube Assembly, LH Price: Call Us |
| 22 |
43-6860 |
DISCONTINUED Price: Call Us |
| 22 |
463461 |
FUEL TANK ASSY, LH STCII Price: Call Us |
| 23 |
3210-7 |
SCREW-HH Price: $0.61 |
| 23 |
427063-B |
Mounting Bracket, Fuel Tank Rear (Black) Price: Call Us |
| 24 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 24 |
254-90 |
BEARING-CUP Price: $11.29 |
| 25 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 25 |
254-91 |
CONE-BEARING Price: $18.65 |
| 26 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 26 |
43-6550 |
RING-SNAP Price: $0.94 |
| 27 |
21-7850 |
PLUG-CUP Price: $23.35 |
| 27 |
425862 |
Mounting Bracket, Fuel Tank Front Price: Call Us |
| 28 |
46-2210 |
SHIM-BEARING, FRONT Price: $6.91 |
| 28 |
463463 |
FUEL TANK ASSY, RH STCII Price: Call Us |
| 29 |
04001-44 |
Bolt, Hex Head 1/4-20 x 1/2” Price: Call Us |
| 29 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 30 |
04030-02 |
Lockwasher, 1/4†Spring Price: Call Us |
| 31 |
04041-22 |
Flatwasher, 1/4 (.258 x .500 x .0598) Price: Call Us |
| 31 |
43-6750 |
BEARING-TAPER, CUP Price: $69.64 |
| 32 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 33 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 34 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 35 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 36 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 37 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 38 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 40 |
72-9420 |
VENT This part replaces 21-8230. Price: $6.85 |
| 41 |
2811-9 |
FITTING-ELBOW-90 Price: $15.86 |
| 42 |
289-38 |
PIPE NIPPLE Price: $21.73 |
| 43 |
43-6850 |
LOWER HSG , TUBE AND MTG. PAD WA. Price: $1,457.56 |
| 484297 |
Fuel |
Cap w/Tethered - California Models Only Price: Call Us 484297 |
| 484366 |
Dust |
Filter, Carbon Canister Price: Call Us 484366 |
| 488244 |
Dust |
Filter, Carbon Canister - Anfan Price: Call Us 488244 |
