| Ref | Part Number | Description |
|---|
| 1 |
110-4445 |
SUPPORT-PULLEY, RH Price: $578.38 |
| 1 |
545125301 |
ASSY-CABLE WIRE HARNESS Price: $19.99 |
| 2 |
110-4527 |
SHAFT-PULLEY, SPLINED Price: $280.50 |
| 2 |
545062001 |
HOUSING-THROTTLE RH Price: $8.99 |
| 3 |
106-8871 |
BEARING-BALL Price: $25.32 |
| 3 |
530016448 |
SCREW Price: $2.99 |
| 4 |
110-4460 |
SPACER-BEARING Price: $12.01 |
| 4 |
530016449 |
SCREW M4 X 1.75 PT 16MM Price: $3.99 |
| 5 |
110-4498 |
WASHER-SHIM Price: $6.58 |
| 5 |
530016454 |
SPRING TRIGGER Price: $4.99 |
| 6 |
110-4419 |
PULLEY Price: $400.50 |
| 6 |
545066001 |
TRIGGER THROTTLE Price: $5.99 |
| 7 |
105-1016 |
WASHER-FLAT Price: $17.48 |
| 7 |
530059804 |
THROTTLE LOCKOUT Price: $4.99 |
| 8 |
110-4614 |
SCREW-HH Price: $3.44 |
| 8 |
545045601 |
SPRING LOCKOUT Price: $4.99 |
| 9 |
110-4631 |
TUBE-SPACER Price: $9.91 |
| 9 |
545067001 |
HSG THROTTLE LH Price: $9.99 |
| 10 |
115-2815 |
IDLER ARM ASM This part replaces 110-4669. Price: $106.17 |
| 10 |
545049301 |
KIT SWITCH Price: $8.99 |
| 11 |
530015820 |
BOLT, TYPE 2 Price: $3.99 |
| 11 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 12 |
323-10 |
SCREW-HH Price: $0.89 |
| 12 |
545139701 |
ASSY HANDLE JBAR Price: $22.99 |
| 13 |
126-1963 |
BUSHING-PIVOT This part replaces 99-3631. Price: $6.69 |
| 13 |
545113301 |
CLAMP HARNESS UPPER Price: $4.99 |
| 14 |
105-0945 |
SLEEVE-PIVOT Price: $34.22 |
| 14 |
545056601 |
CLAMP HARNESS LOWER Price: $3.99 |
| 15 |
110-4624-03 |
ARM-IDLER, RH Price: $125.27 |
| 15 |
530015940 |
SCREW Price: $2.99 |
| 16 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 16 |
530059185 |
CLAMP ASSIST HANDLE Price: $2.99 |
| 17 |
325-14 |
SCREW-HH Price: $2.64 |
| 17 |
530091373 |
NUT-"D" HANDLE This part replaces 530016152. Price: $3.99 |
| 18 |
328-5 |
SCREW-HH Price: $3.60 |
| 18 |
545006068 |
DRIVE SHAFT ASSY This part replaces 545081889. Price: $99.99 |
| 19 |
100-7631 |
PULLEY-IDLER Price: $146.29 |
| 20 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 20 |
537216202 |
Harness - Diagonal with sign This part replaces 537216201. Price: $8.99 |
| 21 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 21 |
545030901 |
KIT COBI SHIELD Price: $27.99 |
| 22 |
110-4632 |
SPRING-COMPRESSION Price: $19.67 |
| 22 |
530052286 |
Limiter - Line Price: $0.68 |
| 23 |
110-4676 |
NUT-IDLER Price: $43.09 |
| 23 |
530015814 |
SCREW Price: $0.17 |
| 25 |
110-4327 |
BELT-BANDED, 4 GROOVE Price: $153.97 |
| 25 |
503890101 |
SUPPORTING CUP Price: $14.99 |
| 26 |
323-17 |
SCREW-HH Price: $2.05 |
| 26 |
537285601 |
SUPPORT FLANGE Price: $9.99 |
| 27 |
105-4886 |
NUT-TINNERMAN Price: $2.37 |
| 27 |
503856301 |
GEARHEAD NUT - BRUSHCUTTER Price: $5.99 |
| 28 |
110-4476-03 |
SUPPORT-GUARD, BELT Price: $45.53 |
| 28 |
530016014 |
SCREW - CARB. ADAPTOR Price: $2.99 |
| 29 |
114-1463-03 |
SHIELD-DIRT, RH Price: $29.37 |
| 29 |
545003902 |
SCREW Price: $2.99 |
| 30 |
110-4474 |
GUARD-BELT, RH Price: $147.78 |
| 31 |
530015771 |
SCREW 1/4-20 X 7/8 (TAP Price: $3.99 |
| 31 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 32 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 32 |
530057554 |
BRACKET SHIELD STRAIGHT SHAFT Price: $4.99 |
| 33 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 33 |
502285901 |
LOCKING PIN Price: $4.99 |
| 34 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 34 |
530096295 |
ASSY GEARBOX Price: $34.99 |
