| Ref | Part Number | Description |
|---|
| 1 |
233-39 |
KNOB-CONTROL Price: $16.12 |
| 1 |
532414557 |
SPRING.TRACTION.IDLER This part replaces 532181044. Price: $4.99 |
| 2 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $22.99 |
| 2 |
74-3190 |
LEVER-LIFT Price: $102.52 |
| 4 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 5 |
60-5690 |
CLIP Price: $3.58 |
| 6 |
532059289 |
STEEL WASHER Price: $3.99 |
| 6 |
58-1520 |
PIN Price: $12.55 |
| 7 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 7 |
585802801 |
NUT.HEX.FL 5/16-18 TOP LCK BLK This part replaces 532166785. Price: $4.99 |
| 8 |
532175330 |
PIN, IDLER PIVOT Price: $4.99 |
| 9 |
532416954 |
V-BELT.TRACTION This part replaces 532179092. Price: $27.99 |
| 9 |
63-4800 |
MOTOR-SPOOL, VALVE Price: $2,291.65 |
| 10 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 10 |
532198552 |
WASHER, LOCK 5/16 Price: $6.99 |
| 11 |
237-21 |
O-RING Price: $0.70 |
| 11 |
532198584 |
SCREW, HEX HEAD 5/16-18 X 1/2 Price: $3.99 |
| 12 |
532422762 |
KIT.SERVCE.IDLER.PULLEY This part replaces 532179259. Price: $79.99 |
| 12 |
58-7190 |
SPRING Price: $19.74 |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 13 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 14 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 14 |
532178828 |
SPRING, BRAKE Price: $4.99 |
| 15 |
532408010 |
BELT.V.IMPELLER.DRIVE Price: $34.99 |
| 16 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 16 |
58-3830 |
PIN-CLEVIS Price: $1.84 |
| 17 |
33093-00 |
WASHER-FLAT This part replaces 48-8010. Price: $0.70 |
| 17 |
585238401 |
ARM.ASM.TRACTION.IDLER. This part replaces 532184804. Price: $27.99 |
| 18 |
58-4450 |
LEVER Price: $81.85 |
| 18 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 19 |
233-10 |
KNOB-LEVER Price: $47.39 |
| 19 |
532198559 |
BUSHING, IDLER PIVOT Price: $2.99 |
| 20 |
58-4460 |
CLEVIS Price: $112.62 |
| 20 |
594095301 |
Pulleys This part replaces 532180523. Price: $9.99 |
| 21 |
58-1570 |
LINK Price: $15.74 |
| 21 |
874610516 |
SCREW Price: $3.99 |
| 22 |
3272-1 |
PIN-COTTER This part replaces 58-1480. Price: $0.25 |
| 22 |
532179371 |
SPACER, ENGINE PULLEY Price: $7.99 |
| 23 |
595926601 |
PULLEY This part replaces 532180478. Price: $27.99 |
| 23 |
60-0550 |
BUSHING Price: $16.69 |
| 24 |
3217-6 |
NUT-HEX Price: $1.19 |
| 24 |
532426491 |
PULLEY.IMPELER. This part replaces 532179157. Price: $14.99 |
| 25 |
532400026 |
WASHER, FLAT 3/8 Price: $7.99 |
| 26 |
32121-118 |
PIN-ROLL Price: $0.36 |
| 26 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 27 |
237-78 |
O-RING Price: $3.85 |
| 28 |
532155452 |
BELT.GUIDE.RH Price: $4.99 |
| 28 |
58-5520 |
VALVE-RELIEF, ADJUSTABLE Price: $410.76 |
| 29 |
322-9 |
SCREW-HH Price: $3.09 |
| 30 |
237-22 |
O-RING Price: $2.43 |
| 30 |
532178830 |
COVER.STORAGE.SNOW Price: $2.99 |
| 31 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 31 |
532405024 |
SCREW, HEX HEAD 1/4-20 X 1/2 This part replaces 532400524. Price: $3.99 |
| 32 |
237-42 |
O-RING Price: $2.78 |
| 32 |
532179256 |
BOLT, SHOULDER 5/16-18 Price: $2.99 |
| 33 |
532187853 |
BELLCRANK SHIFTER Price: $12.99 |
| 33 |
59-7130 |
KNOB-CONTROL, SPEED Price: $25.40 |
| 34 |
532198580 |
CLEVIS PIN Price: $4.99 |
| 34 |
58-1510 |
SHAFT Price: $74.91 |
| 35 |
532405485 |
ARM, AUGER CONTROL Price: $6.99 |
| 35 |
59-7910 |
GROMMET Price: $2.07 |
| 36 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 36 |
60-2110 |
PIN Price: $1.42 |
| 37 |
340-64 |
O-RING Price: $4.22 |
| 37 |
532184086 |
BRACKET, PIVOT Price: $3.99 |
| 38 |
340-80 |
FITTING-STR Price: $47.82 |
| 38 |
532187101 |
LINK, SPEED CONTROL Price: $64.99 |
| 39 |
237-101 |
O-RING This part replaces 237-123. Price: $2.80 |
| 39 |
532192110 |
TRUNNION, TRACTION Price: $7.99 |
| 40 |
58-2150 |
BLOCK-MANIFOLD Price: $325.81 |
| 41 |
532700279 |
RETAINER CLIP Price: $2.99 |
| 41 |
66-5410 |
ORIFICE (.109) Price: $24.26 |
| 42 |
532179065 |
PIN, PIVOT BRACKET Price: $8.99 |
| 43 |
237-80 |
O-RING Price: $6.10 |
| 43 |
532184085 |
BRACKET Price: $2.69 |
| 44 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 44 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 45 |
237-65 |
O-RING Price: $2.50 |
| 45 |
532422762 |
KIT.SERVCE.IDLER.PULLEY This part replaces 532184074. Price: $79.99 |
| 46 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 46 |
532178624 |
PAN, FRAME BOTTOM This part replaces 532184084. Price: $17.99 |
| 47 |
33113-016 |
SCREW-HH This part replaces 48-7620. Price: $0.34 |
| 47 |
871020512 |
Screw, Hex Head 5/16-18 x 3/4 Price: $2.99 |
| 48 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 48 |
532181156 |
NUT.SPEED.5/16-18 Price: $3.99 |
| 49 |
532404431 |
FRAME.WELDMENT.SNOW.ORANGE This part replaces 532407642. Price: $64.99 |
| 49 |
58-3810 |
PIN-CLEVIS Price: $6.22 |
| 50 |
58-1560 |
LINK Price: $7.20 |
| 50 |
583706301 |
END.PLATE.DS.SNOW.BLACK This part replaces 532188002. Price: $14.99 |
| 51 |
48-7890 |
NUT-HEX Price: $0.25 |
| 51 |
532429668 |
KIT.CONTROL.SHAFT.SNOW This part replaces 532406109. Price: $29.99 |
| 52 |
340-86 |
FITTING-TEE Price: $35.23 |
| 52 |
532057079 |
THRUST WASHER Price: $1.99 |
| 53 |
58-1530 |
COUPLING Price: $3.35 |
| 54 |
52-6430 |
WASHER Price: $0.25 |
| 55 |
66-5860 |
FITTING-ELBOW, 45 DEG Price: $92.86 |
| 55 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 56 |
58-5490 |
VALVE-CONTROL, FLOW Price: $1,092.55 |
| 57 |
340-3 |
FITTING-STRAIGHT Price: $10.42 |
| 57 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 811050500. Price: $2.99 |
| 58 |
237-79 |
O-RING Price: $5.46 |
| 59 |
58-1540 |
SPACER-NYLON Price: $11.85 |
| 60 |
33113-050 |
SCREW-HH This part replaces 60-6650. Price: $0.62 |
| 61 |
237-42 |
O-RING Price: $2.78 |
| 62 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 63 |
353-947 |
CAP-DUST, RUBBER Price: $7.73 |
| 64 |
321-3 |
SCREW-HH Price: $0.28 |
| 65 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 66 |
3217-5 |
NUT-HEX Price: $0.25 |
| 67 |
63-4690-03 |
BRACKET-VALVE This part replaces 63-4690. Price: $23.58 |
| 68 |
3296-8 |
NUT-HEX Price: $1.29 |
| 69 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 70 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 71 |
321-11 |
SCREW-HH Price: $0.36 |
| 72 |
63-4700 |
VALVE-FLOW, REGULATOR Price: $295.76 |
| 73 |
3245-44 |
SCREW-SET Price: $2.57 |
| 74 |
74-3170 |
LINK Price: $95.07 |
| 75 |
3245-45 |
SET SCREW 5/16-18 X 1 Price: $6.04 |
| 76 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 77 |
92-9258 |
ADAPTER-CHECK Price: $125.92 |
