| Ref | Part Number | Description |
|---|
| 1 |
353-426 |
FITTING-90 DEG Price: $29.88 |
| 1 |
532190196 |
THROTTLE CONTROL This part replaces 532190454. Price: $32.99 |
| 2 |
237-80 |
O-RING Price: $6.10 |
| 3 |
44-7612 |
BOLT-HWH Price: $24.50 |
| 4 |
353-721 |
PLUG Price: $44.12 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
237-79 |
O-RING Price: $5.46 |
| 5 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 6 |
38-5540 |
FITTING-HYD Price: $80.14 |
| 6 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 7 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 8 |
52-5860 |
COLLAR-SPOOL Price: $13.37 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
68-4240 |
BONNET ASSEMBLY Price: $42.76 |
| 10 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532162797. Price: $11.99 |
| 11 |
353-976 |
SCREW Price: $1.49 |
| 12 |
353-417 |
COLLAR-STOP Price: $10.31 |
| 13 |
44-7650 |
SPRING Price: $31.84 |
| 13 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 14 |
353-959 |
PLATE-RETAINER, SEAL Price: $7.40 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
353-958 |
WASHER Price: $13.57 |
| 17 |
3219-3 |
NUT-HEX Price: $0.34 |
| 17 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 18 |
353-799 |
CONVERSION PLUG ASM Price: $87.60 |
| 19 |
237-177 |
O-RING This part replaces 353-800. Price: $2.73 |
| 20 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 21 |
353-798 |
PLATE-COVER, RIGHT Price: $451.34 |
| 22 |
322-13 |
SCREW-HH Price: $2.73 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 25 |
532132781 |
CHOKE CONTROL This part replaces 532132782. Price: $22.99 |
| 26 |
353-318 |
WIPER Price: $32.73 |
| 28 |
353-321 |
PIN-COTTER Price: $3.15 |
| 29 |
353-324 |
HANDLE BRACKET Price: $107.74 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
63-8760 |
LINK PIN KIT Price: $62.78 |
| 31 |
3272-1 |
PIN-COTTER Price: $0.25 |
| 32 |
52-5900 |
SCREW Price: $26.40 |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 33 |
52-5670 |
DISCONTINUED X-REF Price: Call Us |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 35 |
63-8760 |
LINK PIN KIT Price: $62.78 |
| 36 |
353-322 |
PIN-CLEVIS Price: $5.09 |
| 37 |
44-7660 |
DISCONTINUED Price: Call Us |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 38 |
353-306 |
WASHER-BACKUP Price: $9.12 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 39 |
353-305 |
O-RING Price: $10.91 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 72 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 112 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
