| Ref | Part Number | Description |
|---|
| 1 |
114-5422 |
ROLLER-SHOULDER, PLASTIC Price: $525.86 |
| 1 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
530016226 |
Retainer-Can Price: $1.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
530015880 |
Screw Price: $1.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
530027569 |
Starter Handle Price: $1.99 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
530019243 |
Gasket-Cylind./Carb. Price: $1.99 |
| 8 |
503235112 |
Spark Plug This part replaces 952030201. Price: $5.99 |
| 9 |
530019194 |
Gasket-Carb. Price: $1.99 |
| 10 |
530015941 |
Retainer Ring-C'shaft Price: $1.99 |
| 11 |
530049390 |
Lead Wire Ass'y. Price: $0.28 |
| 12 |
530049389 |
Ground Wire Ass'y. Price: $1.99 |
| 13 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 14 |
530055160 |
Ignition Module Price: $34.99 |
| 15 |
530036145 |
Spacer-Module Price: $1.99 |
| 16 |
530015954 |
Screw Price: $1.99 |
| 17 |
530015828 |
Washer-Flat Price: $1.99 |
| 18 |
530027953 |
Drive Coupling Price: $1.99 |
| 19 |
530054083 |
Assy-Crankshaft Price: $5.99 |
| 20 |
530069615 |
Connecting Rod Ass'y. Price: $14.99 |
| 21 |
545154001 |
RING PISTON This part replaces 530049903. Price: $1.99 |
| 23 |
530032125 |
Inner Bearing Price: $11.99 |
| 24 |
530032124 |
Outer Bearing Price: $4.99 |
| 25 |
530019179 |
C'case Seal Price: $2.99 |
| 26 |
530015945 |
Retain. Ring-C'case Price: $1.99 |
| 27 |
530036578 |
Muffler Body Price: $2.99 |
| 28 |
530036577 |
Muffler Cover Price: $2.99 |
| 29 |
530053500 |
Muffler Baffle-Exit Price: $0.99 |
| 30 |
530053499 |
Muffler Baffle-First Price: $1.99 |
| 31 |
530016197 |
Muffler Spring Old Style Price: $1.99 |
| 31 |
530042088 |
Muffler Spring New Style Price: $1.99 |
| 32 |
530049233 |
Rear Shroud Price: $3.33 |
| 34 |
530012416 |
Cylinder This part replaces 530069757. Price: $17.99 |
| 35 |
530069758 |
Carb. Adaptor Kit Price: $8.99 |
| 36 |
530016014 |
Screw Price: $1.99 |
| 37 |
530019223 |
Gasket-Cylinder Price: $1.99 |
| 39 |
530047908 |
Air Box Price: $3.99 |
| 40 |
530047914 |
Choke Plate Mounting Price: $3.99 |
| 41 |
530047915 |
Choke Lever Ultra Trim & XT55 Price: $2.99 |
| 41 |
530047916 |
Choke Lever Twist'N Edge, XT35 & TE400 Price: $1.99 |
| 42 |
530015852 |
Spacer-Choke Price: $1.99 |
| 43 |
530015254 |
Washer Price: $1.99 |
| 44 |
530036792 |
Isolator-C'Case Price: $4.99 |
| 45 |
530036793 |
Isolator-Shroud Price: $5.99 |
| 46 |
530047932 |
Air Filter Foam Price: $1.99 |
| 47 |
530047927 |
Air Filter Cover Ultratrim & XT55 Price: $1.99 |
| 47 |
530049095 |
Air Filter Cover Twist-N-Edge, XT35 & TE400 Price: $3.33 |
| 48 |
530015849 |
Screw Price: $1.99 |
| 49 |
530015557 |
Screw Price: $1.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
| 51 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 52 |
530069216 |
Fuel Line (Large) Price: $3.99 |
| 53 |
530069247 |
Fuel Line (Small) Price: $3.99 |
| 54 |
530069989 |
Muffler Kit Old Style Price: $3.99 |
| 54 |
530071390 |
Muffler Kit New Style Price: $11.99 |
| 55 |
530014347 |
Fuel Cap Ass'y. Price: $4.99 |
| 56 |
530095646 |
Fuel Pickup Ass'y. Price: $2.99 |
| 59 |
530071356 |
Switch-Momentary This part replaces 530038114. Price: $4.99 |
| 60 |
530049468 |
Assy-Fan Housing Price: $17.99 |
| 61 |
530069232 |
Rope Kit Price: $3.99 |
| 62 |
530016080 |
Screw Price: $1.99 |
| 64 |
530069380 |
Spark Arrestor Kit Old Style Price: $3.99 |
| 64 |
530071391 |
Spark Arrestor Kit New Style Price: $7.99 |
| 65 |
530015162 |
Piston Pin Retainer Price: $1.99 |
| 67 |
530015780 |
Screw-Choke Knob Price: $1.99 |
| 68 |
530047917 |
Choke Knob Price: $0.99 |
| 69 |
530023817 |
Starter Dog Spring Price: $1.99 |
