| Ref | Part Number | Description |
|---|
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 1 |
532184233 |
DECK.SVC.4.GA.WHLS.48".BLK This part replaces 532183389. Price: $349.99 |
| 2 |
76-9790 |
FOAM-TANK, FUEL Price: $10.89 |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 3 |
87-7540 |
CAP - FUEL, DIESEL Price: $58.99 |
| 4 |
76-6600 |
PIPE-STAND Price: $70.58 |
| 5 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532178024. Price: $9.99 |
| 7 |
108-3280 |
HOSE-FUEL This part replaces 63-7626. Price: $5.28 |
| 8 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 532174365. Price: $6.99 |
| 9 |
46-6560 |
BUSHING Price: $2.94 |
| 10 |
68-6150 |
BREATHER Price: $27.22 |
| 11 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 12 |
76-8780 |
DECAL-CAUTION, FUEL Price: $7.93 |
| 13 |
532175147 |
SHAFT, ASM. MANDEREL SEALED Price: $24.99 |
| 14 |
354-95 |
FITTING-STRAIGHT Price: $6.75 |
| 14 |
532174358 |
HOUSING, MANDREL 48" Price: $49.99 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
354-94 |
FITTING-FEMALE, BARBED Price: $9.70 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 17 |
596987501 |
Bolts This part replaces 872110610. Price: $3.99 |
| 17 |
74-9122 |
HOSE-OVERFLOW, RADIATOR Price: $20.47 |
| 18 |
240-6 |
GROMMET-RUBBER Price: $15.80 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
323-7 |
SCREW-HH Price: $0.65 |
| 20 |
531167501 |
SERVICE KIT BAFFLE BAFFLE This part replaces 532174378. Price: $12.99 |
| 21 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
110-4107 |
HOSE-FUEL This part replaces 63-7622. Price: $7.77 |
| 23 |
76-5200 |
DISCONTINUED Price: Call Us |
| 24 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
14-0859 |
FUEL TANK PLATE Price: $72.11 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 26 |
2812-1 |
BUSHING-PIPE Price: $4.28 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
285-22 |
PLUG-PIPE Price: $0.87 |
| 27 |
532180655 |
DEFLECTOR.ASM.BLACK.48" This part replaces 532181707. Price: $39.99 |
| 28 |
62-7650 |
GASKET Price: $4.28 |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 29 |
106-1014 |
SENDER-FUEL This part replaces 74-5860. Price: $246.39 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
32140-40 |
SCREW-HH Price: $1.11 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 32 |
74-5580 |
DISCONTINUED Price: Call Us |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 34 |
321-2 |
SCREW-HH Price: $2.79 |
| 35 |
70-1480 |
RELAY Price: $105.19 |
| 36 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 36 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 37 |
77-4200 |
DISCONTINUED Price: Call Us |
| 38 |
32148-10 |
NUT-CLINCH Price: $1.29 |
| 39 |
106-1018 |
BRACKET-COVER This part replaces 82-3660. Price: $12.55 |
| 39 |
532174375 |
PULLEY.DRIVEN.DECK.48' Price: $34.99 |
| 42 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 43 |
532174373 |
ARM, IDLER SECONDARY Price: $9.99 |
| 45 |
532180806 |
COVER.MANDREL.DECK.48" Price: $12.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
532180808 |
V-BELT, 48"SECONDARY Price: $49.99 |
| 48 |
532174368 |
V-BELT PRIMARY 48" Price: $49.99 |
| 49 |
839000600 |
Nut, Lock 3/8-16 unc Price: Call Us |
| 50 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 52 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 54 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 55 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 56 |
532155986 |
BAR.ADJUST.WHEEL.ANTI.SCALP.BL Price: $17.99 |
| 57 |
532156941 |
RIVET.PIN.HEAD.YELLOW. Price: $4.99 |
| 72 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 91 |
529846201 |
SERVICE KIT BRKT.NOSEROLLER.RH This part replaces 532180535. Price: $5.99 |
| 92 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 94 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 95 |
529846101 |
SERVICE KIT BRKT.NOSEROLLER.LH This part replaces 532180534. Price: $5.99 |
| 97 |
532178515 |
WASHER Price: $5.99 |
| 98 |
532179479 |
SPRING PRIMARY DRIVE Price: $3.99 |
| 99 |
532193195 |
PULLEY.V.IDLER This part replaces 532184058. Price: $49.99 |
| 100 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 110 |
532175016 |
ARM, SPRING SECONDARY Price: $4.99 |
| 111 |
532174610 |
ARM SPRING FIXED TENSION Price: $6.99 |
| 113 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 116 |
596434404 |
Bolts This part replaces 532184219. Price: $4.99 |
| 117 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 121 |
532174371 |
SPRING.DRIVE.SECONDARY.48".DEC Price: $5.99 |
| 126 |
532174372 |
ARM, IDLER PRIMARY DECK Price: $9.99 |
| 130 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 131 |
819131606 |
Washer 13/32 x 1 x 6 Ga. Price: $4.99 |
| 132 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 182 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 183 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 184 |
532173979 |
KEEPER BELT IDLER PLATED Price: $4.99 |
