| Ref | Part Number | Description |
|---|
| 0010 |
84008475 |
BAFFLE, Front LH Price: $58.73 |
| 0020 |
84008476 |
BAFFLE, Front RH Price: $35.29 |
| 0040 |
703185 |
BOLT, Round Head, Short Square Neck Price: $2.87 |
| 0050 |
703115 |
NUT Price: $3.06 |
| 0060 |
84008477 |
COVER, Pulley, 36 Fab, Black Price: $199.26 |
| 0070 |
1760095AYP |
SUPPORT, Pulley Cover, 42” Mower Deck,Black Price: $23.31 |
| 0080 |
84008242 |
GUARD, Frame, RH 36CC Black Price: Call Us |
| 0090 |
84008243 |
GUARD, Frame, LH 36CC Black Price: $51.17 |
| 0100 |
703228 |
SCREW, 5/16-18 X .75 Price: $3.94 |
| 0110 |
5022308SM |
BODY CLIP, 5/16-18 X Price: $5.00 |
| 0120 |
703350 |
WASHER Price: $3.72 |
| 0130 |
5025011X6SM |
BOLT, 5/16-18 X 3/4" Price: $3.19 |
| 0140 |
7046780SM |
PLUG, Hole, .44” OD Price: $4.19 |
| 0150 |
7073293YP |
PLUG, Hole, .30 OD Price: $2.53 |
| 0160 |
7091579SM |
SCREW, Hex Flange Lock, 1/4-20 x 1/2 GR 5 This part replaces 1931646SM. Price: $3.50 |
