| Ref | Part Number | Description |
|---|
| 1 |
482624 |
Main Frame Assembly w/Decals Price: Call Us |
| 2 |
04020-28 |
Bolt, Hex Hd. 5/16-18 x 3-3/4" Price: Call Us |
| 3 |
481766 |
Back Cover Price: Call Us |
| 4 |
04050-10 |
Nut, Serr. Flng. 3/8-16 Price: Call Us |
| 5 |
483062 |
Plate, Seat Mounting Price: Call Us |
| 6 |
43487 |
Cushion Cover Price: Call Us |
| 7 |
423463 |
Pin Retainer, Spring Price: Call Us |
| 8 |
04001-22 |
Spring Price: Call Us |
| 10 |
04021-09 |
Battery Cover Price: Call Us |
| 11 |
461874 |
Battery Hold Down Pad Price: Call Us |
| 12 |
422346 |
Bolt, Carr. 5/16-18 x 3/4" Price: Call Us |
| 13 |
04014-03 |
Battery Box Price: Call Us |
| 14 |
422381 |
Roll Pin, Spring 5/32 x 3/4" Price: Call Us |
| 15 |
04003-04 |
Nut, Serr. Flng. 5/16-18 Price: Call Us |
| 16 |
422380 |
Bolt, Hex Hd. 3/8-16 x 1" Price: Call Us |
| 17 |
483177 |
Pad, Rubber Price: Call Us |
| 18 |
04021-05 |
Bolt, Hex Hd. 1/4-20 x 1-1/4" Price: Call Us |
| 19 |
04040-09 |
Nut, Serr. Flng. 1/4-20 Price: Call Us |
| 20 |
04019-04 |
Seat Base Support Price: Call Us |
| 21 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 22 |
43678 |
Seat Assembly w/Adj. Rails & Seat Belt Price: Call Us |
| 23 |
04061-07 |
Armrest Cover Price: Call Us |
| 24 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 25 |
04021-09 |
Seat Track Set Price: Call Us |
| 26 |
48540 |
Footplate Price: Call Us |
| 27 |
48114-04 |
Nut, Elastic Stop 3/8-16 Price: Call Us |
| 28 |
483181 |
Bolt, Hex Hd. 3/8-16 x 1" Price: Call Us |
| 29 |
461929 |
Cable, Seat Stop Price: Call Us |
| 30 |
04004-45 |
Weldment, Caster Support (61V) Price: Call Us |
| 31 |
481547 |
Cap, Grease Price: Call Us |
| 32 |
04020-09 |
Nut, Elastic Stop 1.0-14 Price: Call Us |
| 33 |
43679 |
Bearing Set Price: Call Us |
| 34 |
04001-155 |
Plug, 1/4-28 Price: Call Us |
| 35 |
481765 |
Seal, 2.0" OD x 1.625" ID Price: Call Us |
| 36 |
04001-77 |
Nut, Elastic Stop 1/2-13 Price: Call Us |
| 37 |
43572 |
Yoke, Front Caster Wheel Price: Call Us |
| 38 |
04021-02 |
Bolt, Hex Hd. 1/2-13 x 9-1/2" Price: Call Us |
| 39 |
43630 |
Sleeve Price: Call Us |
| 41 |
04021-10 |
Tire, 13 x 6.5-6 Smooth Price: Call Us |
| 42 |
45904 |
Seal Price: Call Us |
| 44 |
04041-14 |
Roller Bearing Price: Call Us |
| 45 |
04050-08 |
Fitting, Grease Price: Call Us |
| 46 |
04062-04 |
Mounting Bracket, Oil Tank Price: Call Us |
| 47 |
481477 |
Mounting Bracket, Fuel Tank Price: Call Us |
| 48 |
482633 |
Seat Pan Price: Call Us |
| 49 |
43584 |
Spacer, Caster Wheel Price: Call Us |
| 50 |
04001-28 |
Bolt, Hex Hd. 7/16-14 x 1-1/4" Price: Call Us |
| 51 |
04021-11 |
Nut, Elastic Stop 7/16-14 Price: Call Us |
| 52 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 53 |
04001-06 |
Bolt, Hex Hd. 1/4-20 x 5/8" Price: Call Us |
| 54 |
451580 |
Support Weldment, Oil Cooler Price: Call Us |
| 55 |
04003-04 |
Bolt, Carriage 5/16-18 x 1" Price: Call Us |
| 56 |
423912 |
Bracket, Fuel Valve Price: Call Us |
| 57 |
424112 |
Bracket, Hour Meter Price: Call Us |
| 58 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 59 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 60 |
04110-03 |
U-Nut, 3/8-16 Price: Call Us |
| 62 |
04021-05 |
Locknut, 3/8-16 Center Lock Price: Call Us |
| 63 |
483371 |
Spring, Seat Latch Price: Call Us |
| 64 |
451897 |
Seat Latch Weldment Price: Call Us |
| 65 |
04001-100 |
Bolt, Hex Hd. 3/8-16 x 6" Price: Call Us |
| 66 |
424584 |
Seat Stop Price: Call Us |
