| Ref | Part Number | Description |
|---|
| 1 |
106-8059 |
KIT-ENGINE KUBOTA This part replaces 104-3448. Price: $9,147.51 |
| 1 |
138026 |
SUB= 145775 Price: Call Us |
| 2 |
106-8069 |
MUFFLER-EXHAUST This part replaces 104-3426. Price: $620.16 |
| 2 |
73680500 |
SUB= 73690500 Price: Call Us |
| 3 |
68-9400 |
NUT-FLANGE Price: $2.29 |
| 3 |
72140506 |
BOLT Price: Call Us |
| 4 |
105-2523-03 |
BRACKET-MUFFLER Price: $34.40 |
| 4 |
7631J |
RUNNER-LH M Price: Call Us |
| 5 |
138017 |
BRKT ASM SWAY BAR Price: Call Us |
| 5 |
33114-016 |
SCREW-HH Price: $0.27 |
| 6 |
32128-37 |
NUT-HF Price: $3.63 |
| 6 |
4939M |
SUB= 85902 Price: Call Us |
| 7 |
130832 |
SUB= 130833 Price: Call Us |
| 7 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 8 |
131-1821 |
MOUNT-ENGINE This part replaces 53-9680. Price: $105.39 |
| 8 |
138440 |
BRKT DECK SW BAR Price: Call Us |
| 8A |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 9 |
53-9480 |
WASHER-SNUBBER Price: $3.87 |
| 9 |
73800500 |
NUT Price: Call Us |
| 10 |
324-11 |
SCREW-HH Price: $3.05 |
| 10 |
72140506 |
BOLT Price: Call Us |
| 11 |
136929 |
SUB= 140329 Price: Call Us |
| 11 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 12 |
110485X |
BEARING Price: Call Us |
| 12 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 13 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 13 |
48-9590 |
WASHER-LOCK This part replaces 42-9600. Price: $0.25 |
| 14 |
137645 |
SUB= 137646 Price: Call Us |
| 14 |
3274-106 |
SCREW-HSH Price: $5.77 |
| 15 |
105-2519-03 |
CLAMP-CRADDLE Price: $58.64 |
| 15 |
129895 |
BEARING.BALL Price: Call Us |
| 16 |
323-44 |
SCREW-HH Price: $3.69 |
| 17 |
110-9679-03 |
GUARD-ALTERNATOR This part replaces 105-2557-03. Price: $63.13 |
| 17 |
129962 |
WASHER BLADE Price: Call Us |
| 18 |
10030600 |
SUB= 10040600 Price: Call Us |
| 18 |
105-2556-03 |
BRACE-ALTERNATOR, UPPER Price: $60.30 |
| 19 |
105-4276 |
GUIDE-BELT, PTO Price: $18.17 |
| 19 |
850857 |
BLADE BOLT Price: Call Us |
| 20 |
105-0052-03 |
BRACKET-GUIDE, BELT Price: $21.03 |
| 20 |
131290 |
BELT-V.88.12.MW Price: Call Us |
| 21 |
128772 |
RUNNER RH Price: Call Us |
| 21 |
99-8363 |
BOLT-FLANGE Price: $1.66 |
| 22 |
19111216 |
WASHER M Price: Call Us |
| 22 |
98-9584 |
PULLEY-FAN Price: $89.56 |
| 23 |
106736X |
DEFLECTOR-SHLD T Price: Call Us |
| 23 |
98-9346 |
SENDER-TEMPERATURE Price: $74.58 |
| 24 |
104-4246 |
FAN-ENGINE Price: $154.04 |
| 24 |
106735X |
ROD-HINGE T Price: Call Us |
| 25 |
137607 |
BRKT DEFLECTOR Price: Call Us |
| 25 |
99-8343 |
GASKET-MUFFLER This part replaces 98-9611. Price: $14.99 |
| 26 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 27 |
123713X |
SPRING TORSION Price: Call Us |
| 27 |
3257-30 |
KEY-WOODRUFF Price: $5.35 |
| 28 |
19111016 |
WASHER Price: Call Us |
| 29 |
110452X |
NUT PUSH M Price: Call Us |
| 29 |
3272-16 |
PIN-COTTER Price: $0.31 |
| 30 |
38-7820 |
BEARING-BALL Price: $13.99 |
| 30 |
78158 |
SUB= 17580520 Price: Call Us |
| 31 |
104-3408-03 |
HUB-FAN Price: $165.47 |
| 31 |
129963 |
WASHER Price: Call Us |
| 32 |
106932X |
KNOB T(3/8 HOLE) Price: Call Us |
| 32 |
129206 |
SUB= 153532 Price: Call Us |
| 32 |
32136-3 |
NUT-SHH Price: $1.22 |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 33 |
3234-33 |
SCREW-HHF Price: $0.79 |
| 34 |
133840 |
IDLER ARM ASSY Price: Call Us |
| 35 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 36 |
104-3463-03 |
FRONT MOUNT ASM Price: $103.56 |
| 36 |
122052X |
SPACER RETAINER Price: Call Us |
| 37 |
104-3464-03 |
MOUNT-FRAME, FRONT (LH) Price: $44.16 |
| 37 |
19131612 |
WASHER GT Price: Call Us |
| 38 |
43-0090 |
SCREW-HH Price: $8.05 |
| 38 |
73680600 |
SUB= 73690600 Price: Call Us |
| 39 |
324-6 |
SCREW-HH Price: $0.81 |
| 39 |
74600636 |
BOLT Price: Call Us |
| 40 |
19131612 |
WASHER GT Price: Call Us |
| 40 |
75-9900-01 |
SUPPORT-ENGINE, FRONT Price: $226.52 |
| 41 |
105-0057 |
STUD-RETAINER, BELT Price: $10.04 |
| 41 |
131289 |
BRAKE ROD LH Price: Call Us |
| 42 |
104-3406 |
PULLEY-ENGINE, MACHINING V This part replaces 104-3406-03. Price: $319.58 |
| 42 |
130840 |
BRAKE ASM Price: Call Us |
| 43 |
17490512 |
SCREW Price: Call Us |
| 43 |
3257-33 |
KEY-WOODRUFF Price: $1.76 |
| 44 |
131288 |
BRAKE ROD RH Price: Call Us |
| 44 |
302-10 |
FITTING-GREASE Price: $2.64 |
| 45 |
3241-5 |
SCREW-SET Price: $0.61 |
| 45 |
72110614 |
BOLT Price: Call Us |
| 46 |
110-5236 |
HUB-ENGINE This part replaces 27-1960. Price: $30.97 |
| 46 |
76020312 |
SUB= 3145 Price: Call Us |
| 47 |
13351 |
ROD PIVOT W/NIBS Price: Call Us |
| 47 |
32120-69 |
RING-SNAP Price: $2.78 |
| 48 |
133504 |
CLUTCH ROD SECOND Price: Call Us |
| 48 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 49 |
43-3720 |
COLLAR-BEARING Price: $249.41 |
| 50 |
251-252 |
BEARING Price: $98.35 |
| 50 |
4497H |
RETAINER M Price: Call Us |
| 51 |
131870 |
RETURN SPRING Price: Call Us |
| 51 |
3234-18 |
SCREW-HHF Price: $0.87 |
| 52 |
127498 |
BUSHING Price: Call Us |
| 52 |
3290-224 |
LOCKWASHER-PYRAMID Price: $33.25 |
| 53 |
133573 |
CLUTCH ARM PRI AS Price: Call Us |
| 53 |
63-1400 |
ROD-BELT Price: $17.83 |
| 54 |
127847 |
CLUTCH ARM SECOND Price: Call Us |
| 54 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 55 |
104-3465-03 |
MOUNT-FRAME, FRONT (RH) Price: $44.16 |
| 55 |
121748X |
WASHER Price: Call Us |
| 56 |
12000029 |
RING Price: Call Us |
| 56 |
321-4 |
SCREW-HH Price: $0.99 |
| 57 |
104-3421-03 |
BRACKET-THROTTLE Price: $42.29 |
| 57 |
128903 |
SHOULDER BOLT Price: Call Us |
| 58 |
127845 |
SPRING KEEPER Price: Call Us |
| 58 |
2412-31 |
CLAMP-BODEN Price: $1.56 |
| 59 |
128759 |
SUB= 918128759 Price: Call Us |
| 59 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 60 |
133502 |
RETAINER SPACER Price: Call Us |
| 60 |
3217-5 |
NUT-HEX Price: $0.25 |
| 61 |
133503 |
IDLER ARM STIFF Price: Call Us |
| 61 |
33113-050 |
SCREW-HH This part replaces 60-6650. Price: $0.62 |
| 62 |
48-8020 |
WASHER-SPRING Price: $1.19 |
| 63 |
33113-020 |
SCREW-HH This part replaces 48-7630. Price: $0.26 |
| 65 |
98-9676 |
V-BELT Price: $31.01 |
| 67 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 69 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 70 |
115-4513-03 |
BRACKET-MUFFLER This part replaces 105-2598-03. Price: $35.52 |
| 71 |
3-6803 |
WASHER-ADJUSTING Price: $0.75 |
| 72 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 73 |
3256-75 |
WASHER-FLAT Price: $0.79 |
| 74 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
