| Ref | Part Number | Description |
|---|
| 1 |
31834 |
SHAFT & LEV Price: $6.54 |
| 1 |
530057991 |
Assy-Throttle Cable Price: $8.99 |
| 1 |
93-9939 |
TIRE Price: $34.55 |
| 2 |
530058000 |
Trigger Price: $2.99 |
| 2 |
631767 |
SPRING This part replaces 632016. Price: $1.25 |
| 2 |
68-8950 |
TUBE-INNER (W/VALVE) Price: $26.99 |
| 3 |
530057582 |
Throttle Hsg. (Right) Price: $7.99 |
| 3 |
631036 |
SHUTTER Price: $1.20 |
| 3 |
93-4241 |
SPACER-BEARING, INNER Price: $26.72 |
| 4 |
120-3366 |
BEARING Price: $28.29 |
| 4 |
530015880 |
Screw-Throttle Hsg. Price: $1.99 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
530015821 |
Bolt-Handle/Shield Price: $1.99 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 6 |
32128-16 |
NUT-HHF Price: $0.54 |
| 6 |
530071875 |
Kit-Drive Shaft Hsg. Price: $17.99 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 7 |
530096276 |
Shaft- Flex Price: $19.99 |
| 7 |
93-4242 |
PLATE Price: $11.21 |
| 7B |
31842 |
SHAFT & LEV Price: $5.21 |
| 8 |
530057581 |
Throttle Hsg. (Left) Price: $7.99 |
| 8 |
630757A |
RET SPRING Price: $1.25 |
| 8 |
93-4239 |
RIM-WHEEL, HALF Price: $29.68 |
| 9 |
31837 |
SHUTTER Price: $1.18 |
| 9 |
530057587 |
Handle-Assist Price: $6.99 |
| 9 |
93-5980 |
HUB Price: $67.14 |
| 10 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 10 |
630748 |
WELCH PLUG Price: $1.17 |
| 11 |
530052286 |
Line Limiter Price: $1.54 |
| 11 |
631027 |
WELCH PLUG Price: $1.17 |
| 12 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 12 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 13 |
530095563 |
Dust Cup Price: $9.99 |
| 13 |
631022 |
CLIP Price: $1.25 |
| 14 |
530015820 |
Bolt Price: $1.99 |
| 14 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 16 |
631867 |
FLOAT BOWL Price: $2.34 |
| 18 |
530071306 |
Kit-Hub Ass'y This part replaces 530095776. Price: $8.99 |
| 19 |
530053241 |
Spring-Compression Price: $1.99 |
| 20 |
530401957 |
Clip-Retainer-Head Price: $1.99 |
| 21 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 21 |
952701719 |
TNG 6 RH .080X25' PLN This part replaces 952711616. Price: $7.95 |
| 22 |
31839 |
POWER SCREW Price: $10.89 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
631838 |
ADJ SCREW This part replaces 631078. Price: $2.71 |
| 25 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 26 |
632164 |
FUEL FITTING This part replaces 631803. Price: $5.95 |
| 27 |
631183 |
WASHER This part replaces 631971. Price: $1.25 |
| 27A |
631183 |
WASHER Price: $1.25 |
| 28 |
631184 |
WASHER Price: $1.25 |
| 29 |
631972 |
WASHER Price: $1.25 |
| 30 |
630738 |
SPRING Price: $1.25 |
| 32 |
630739 |
WASHER Price: $1.25 |
