| Ref | Part Number | Description |
|---|
| 1 |
753-04083 |
ENGINE COVER Not Available Price: |
| 2 |
791-181930 |
Engine Cover Screws Price: $5.95 |
| 3 |
791-181025 |
Valve Cover Screw Price: $2.44 |
| 4 |
791-182098 |
COVER, VALVE W/O BRE Not Available Price: |
| 5 |
791-182099 |
Valve Cover Gasket Price: $8.64 |
| 6 |
791-182340 |
NUT, ROCKER ADJUST Not Available Price: |
| 7 |
791-182101 |
PIVOT, ROCKER ARM Not Available Price: |
| 8 |
791-182100 |
ARM, ROCKER Not Available Price: |
| 9 |
791-182341 |
STUD, ROCKER ARM Not Available Price: |
| 10 |
791-182103 |
RET, VALVE SPRING Not Available Price: |
| 11 |
791-181038 |
SPRING, VALVE Not Available Price: |
| 12 |
791-182102 |
GUIDE, PUSH ROD Not Available Price: |
| 13 |
791-181033 |
ROD, PUSH Not Available Price: |
| 14 |
753-04816 |
CYLINDER ASSEMBLY Not Available Price: |
| 15 |
9052-1 |
SCREW, M5 X18 This part replaces 791-181003. Price: $3.78 |
| 16 |
791-182345 |
BAFFLE, INTAKE GAS Not Available Price: |
| 17 |
791-182749 |
Carburetor Mount Gasket Price: $8.48 |
| 18 |
791-181034 |
NUT-DEE HANDLE Not Available Price: |
| 19 |
791-182347 |
Carburetor Mount (includes 18) Price: $17.03 |
| 20 |
791-182348 |
SCR, CARBU Not Available Price: |
| 21 |
791-182732 |
CARBURETOR GASKET Not Available Price: |
| 22 |
753-1225 |
Carburetor w/Primer Price: $63.06 |
| 23 |
791-181751 |
O-Ring, Carburetor Price: $3.92 |
| 24 |
753-04223 |
Air Filter Cover Assembly (includes 25 & 27) Not Available Price: |
| 25 |
791-182097 |
Breather Tube Price: $10.13 |
| 26 |
791-181750 |
SCREW 5M X 0.8-7 NLAUD Not Available Price: |
| 27 |
791-181757 |
Air Filter Price: $3.59 |
| 28 |
753-1229 |
Fuel Cap Price: $19.90 |
| 29 |
791-182352 |
Fuel Return Line Price: $6.66 |
| 30 |
791-182353 |
Fuel Pick-Up Line with Filter Price: $8.80 |
| 31 |
710-04185 |
SCREW M5-19 Not Available This part replaces 753-04510. Price: |
| 32 |
791-182409 |
Washer Price: $4.04 |
| 33 |
753-1230 |
FUEL TANK ASSEMBLY Not Available Price: |
| 34 |
791-182356 |
BAFFLE, FU Not Available Price: |
| 35 |
753-1231 |
Throttle Cable Price: $15.30 |
| 36 |
791-182358 |
BAFFLE, MUFFLER Not Available Price: |
| 37 |
9094-1 |
MUFFLER GASKET This part replaces 791-181048. Price: $4.01 |
| 38 |
791-182359 |
MUFFLER & GASKET Not Available Price: |
| 39 |
791-182361 |
SCREW, MUFFLER Not Available Price: |
| 40 |
753-04092 |
CVR:MFLR Not Available Price: |
| 41 |
791-182804 |
ASSEMBLY, SWIT Not Available Price: |
| 42 |
753-04288 |
Palnut Price: $9.62 |
| 43 |
1755 |
Screw This part replaces 753-1202. Price: $3.37 |
| 44 |
753-05074 |
PLATE:PRESS:4 CY:AST Not Available Price: |
| 45 |
753-05072 |
Recoil Pulley Assembly (includes 42 & 50) Not Available Price: |
| 46 |
753-04286 |
Recoil Spring Price: $24.35 |
| 47 |
791-182366 |
Nut Clip Price: $4.90 |
| 48 |
631-04164B |
Pull Handle This part replaces 753-05011. Price: $3.38 |
| 49 |
791-611061 |
Rope Guide Price: $9.62 |
| 50 |
791-182661 |
ROPE, STARTER .112 Not Available Price: |
| 51 |
9054 |
Screw This part replaces 791-181020. Price: $3.82 |
| 52 |
753-05158 |
Starter Housing Assembly (includes 42-51) Price: $77.42 |
| 53 |
791-182537 |
GROMMET, WIRE (AC- Not Available Price: |
| 54 |
753-05159 |
CLUTCH HOUSING Not Available Price: |
| 55 |
791-181345 |
Cover Screw Price: $3.75 |
| 56 |
791-182519 |
Anti-Rotation Screw Price: $4.37 |
| 57 |
792-10662 |
SCREW:10-24X1.375:BK Not Available This part replaces 753-05077. Price: |
| 58 |
712-0161 |
Nut-Hex Ins L-#10- This part replaces 791-180217. Price: $4.02 |
| 59 |
791-182725 |
IGNITION MODULE WITH SCREWS Not Available Price: |
| 60 |
791-610303 |
NUT, SQUARE DRIVE Not Available Price: |
| 61 |
753-05240 |
Flywheel Assembly This part replaces 791-182736. Price: $67.61 |
| 62 |
791-181861 |
SCREW, 1/4-20X.562 F Not Available Price: |
| 63 |
791-182743 |
ASSEMBLY, SHROUD (AC-2. Not Available Price: |
| 64 |
753-05160 |
CRANKCASE ASSEMBLY Not Available Price: |
| 65 |
791-182375 |
FITTING, BREATHER Not Available Price: |
| 66 |
791-182379 |
Breather Hose Price: $4.10 |
| 67 |
753-04919 |
Cam Bracket Assembly Price: $32.20 |
| 68 |
791-181012 |
SCR, CAM BRACKET Not Available Price: |
| 69 |
791-181040 |
VALVE Not Available Price: |
| 70 |
791-182374 |
GASKET, CYLINDER B Not Available Price: |
| 71 |
791-181018 |
GASKET, OIL PAN Not Available Price: |
| 72 |
791-182377 |
PAN, OIL W/ GASKET Not Available Price: |
| 73 |
9054 |
Screw This part replaces 791-181020. Price: $3.82 |
| 74 |
791-182378 |
Oil Cap Dipstick (includes 74) This part replaces 753-04041. Price: $9.37 |
| 75 |
791-182290 |
O-Ring Price: $4.29 |
| 76 |
791-181009 |
ROD, CONNECTING Not Available Price: |
| 77 |
791-181008 |
BUTTON, WRIST PIN Not Available Price: |
| 78 |
753-04878 |
PISTON ASSEMBLY:PSTN&RING Not Available Price: |
| 79 |
753-05176 |
WRIST PIN Not Available Price: |
| 80 |
753-04801 |
RING SET:PISTON Not Available Price: |
| 81 |
791-182360 |
SHIELD, RADIANT HE Not Available Price: |
| 82 |
753-04098 |
WIRE COVER:12" Not Available Price: |
| 83 |
791-160428 |
CLAMP, CABLE NATUR Not Available Price: |
