| Ref | Part Number | Description |
|---|
| 1 |
120-3809 |
FRAME ASM Price: $6,114.03 |
| 2 |
110-9041 |
STEP-ALUMINUM Price: $158.64 |
| 3 |
127-2697-01 |
BRACKET-STEP Price: $21.97 |
| 3 |
594018001 |
Levers This part replaces 532195231. Price: $17.99 |
| 4 |
323-36 |
SCREW-HH Price: $3.05 |
| 5 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 6 |
322-17 |
SCREW-HH Price: $2.62 |
| 7 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK Price: $7.99 |
| 8 |
95-9495 |
CAP Price: $5.02 |
| 9 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 10 |
110-8972 |
HOOK-LATCH Price: $8.25 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 11 |
110-9012 |
CAPLUG Price: $3.94 |
| 12 |
110-9013 |
CAPLUG Price: $3.94 |
| 13 |
32104-17 |
SCREW-HWH Price: $0.99 |
| 14 |
147-3550 |
BUMPER ASM This part replaces 110-8951-03. Price: $230.25 |
| 15 |
120-6274 |
MOUNT-ENGINE Price: $30.17 |
| 16 |
2410-42 |
CAP-END Price: $11.62 |
| 17 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 18 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 19 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 20 |
108-7584-01 |
PLATE-GUIDE, ROD Price: $12.35 |
| 21 |
117-0155 |
BRACKET-4WD, LH Price: $15.11 |
| 22 |
117-0154 |
BRACKET-4WD, RH Price: $13.87 |
| 23 |
32128-21 |
NUT-HF Price: $0.39 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 |
532410710 |
SPRING.LIFT.ASSIST This part replaces 532195303. Price: $9.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464807 |
Links This part replaces 532195181. Price: $14.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 98 |
581506902 |
Links This part replaces 532195264. Price: $9.99 |
