| Ref | Part Number | Description |
|---|
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532188715. Price: $219.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
112-7026 |
WHEEL BEARING CASE ASM Price: $196.85 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
115-4121 |
METAL-CRANKSHAFT (STD) This part replaces 112-7045. Price: $86.06 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 20 |
98-9484 |
BOLT-CASE, BEARING Price: $6.05 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 30 |
131-6554 |
GASKET-CASE, BEARING This part replaces 98-9634. Price: $7.12 |
| 40 |
112-7046 |
COVER-CASE, BEARING Price: $66.00 |
| 50 |
112-0180 |
SEAL-OIL Price: $58.48 |
| 60 |
112-7037 |
GASKET-COVER, CASE Price: $14.14 |
| 70 |
98-9352 |
BOLT Price: $0.80 |
| 80 |
98-7568 |
BOLT Price: $0.84 |
| 90 |
115-4106 |
MAIN BEARING CASE ASM Price: $189.84 |
| 95 |
98-9524 |
METAL-CRANKSHAFT (STD SET) Price: $62.26 |
| 100 |
98-9484 |
BOLT-CASE, BEARING Price: $6.05 |
| 110 |
98-9485 |
BOLT-CASE, BEARING Price: $22.80 |
| 120 |
115-4107 |
MAIN BEARING CASE ASM Price: $152.88 |
| 125 |
115-4106 |
MAIN BEARING CASE ASM Price: $189.84 |
| 130 |
98-9484 |
BOLT-CASE, BEARING Price: $6.05 |
| 140 |
130-1265 |
MAIN BEARING CASE ASM Price: $181.07 |
| 145 |
115-4106 |
MAIN BEARING CASE ASM Price: $189.84 |
