| Ref | Part Number | Description |
|---|
| 1 |
93-0032-03 |
HOUSING-SCREEN, FRONT Price: $455.35 |
| 2 |
75-3390-03 |
BRACKET-BACKLAP Price: $11.98 |
| 3 |
66-8800 |
RELAY Price: $87.56 |
| 4 |
532427071 |
PULLEY.IMPELLER.SNOW This part replaces 532191079. Price: $27.99 |
| 4 |
99-8352 |
SWITCH-BACKLAP, MASTER Price: $91.81 |
| 5 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 5 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 6 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 6 |
93-6684 |
DECAL-BACKLAP Price: $7.84 |
| 7 |
322-2 |
SCREW-HH Price: $0.69 |
| 7 |
532180355 |
BOLT.CARRIAGE.5/16-18X Price: $3.99 |
| 8 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872270505. Price: $2.99 |
| 8 |
93-3623 |
STRIP-SEALING, RADIATOR Price: $12.44 |
| 9 |
596031601 |
Screws This part replaces 532163183. Price: $2.99 |
| 9 |
93-0077 |
HOSE ASM Price: $130.09 |
| 10 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 10 |
581708379 |
KIT.AUGER.HOUSING.404928X668 This part replaces 532407880. Price: $237.99 |
| 11 |
531064001 |
SERVICE KIT SCRAPER BAR.SCRAPE This part replaces 532407825. Price: $9.99 |
| 11 |
93-0078 |
HOSE ASM Price: $189.33 |
| 12 |
597433002 |
Brackets This part replaces 532184095. Price: $3.99 |
| 12 |
92-4999 |
FITTING Price: $67.92 |
| 13 |
585056901 |
CHUTE.DISCHARGE.BASE This part replaces 532175322. Price: $9.99 |
| 13 |
75-1040 |
COOLER-OIL Price: $761.60 |
| 14 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 14 |
93-3624-03 |
PLATE-RETAINING Price: $8.64 |
| 15 |
321-4 |
SCREW-HH Price: $0.99 |
| 15 |
819111507 |
WASHER, FLAT Price: $4.99 |
| 16 |
874940516 |
CAPSCREW.HX.HD.5/16-18X1.00.NY Price: $3.99 |
| 16 |
98-3928 |
CLAMP-HOSE Price: $13.58 |
| 17 |
532405637 |
GREASE FITTING Price: $3.99 |
| 18 |
24-0760 |
DISCONTINUED Price: Call Us |
| 18 |
532179582 |
SCREW, HEX HD 5/16X1 Price: $3.99 |
| 19 |
340-124 |
ADAPTER Price: $23.18 |
| 19 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 20 |
3269-13 |
RIVET-POP Price: $0.25 |
| 20 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 21 |
100-3815 |
GROMMET-RUBBER Price: $8.15 |
| 22 |
532407834 |
SKID PLATE Price: $17.99 |
| 22 |
93-1374 |
LATCH-SWELL Price: $27.60 |
| 23 |
3269-10 |
WASHER-BACK Price: $0.61 |
| 25 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 This part replaces 872270506. Price: $3.99 |
| 26 |
104-9257-03 |
DISCONTINUED Price: Call Us |
| 26 |
532187925 |
BEARING.BALL.AUGER.SHAFT Price: $54.99 |
| 27 |
532007396 |
WASHER RACE BEARING THRUST This part replaces 532174697. Price: $3.99 |
| 28 |
588077502 |
BOLT SHEAR HX HD 1/4-20 CLEAR This part replaces 532198636. Price: $1.00 |
| 29 |
532188170 |
BEARING RETAINER, PLASTIC Price: $7.99 |
| 30 |
532435541 |
KIT.AUGER.24.RH.BB This part replaces 532407827. Price: $129.99 |
| 30 |
70-1480 |
RELAY Price: $105.19 |
| 31 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 31 |
532435540 |
KIT.AUGER.24.LH.BB This part replaces 532407826. Price: $139.99 |
| 32 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 32 |
532407768 |
O-RING Price: $3.99 |
| 33 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 33 |
532407769 |
BUSHING, FLANGE 3/4 Price: $7.99 |
| 34 |
532174681 |
WASHER, THRUST 3/4 Price: $11.99 |
| 35 |
532174684 |
BEARING TRUST 3/4 NTA-1220 Price: $6.99 |
| 36 |
532407757 |
SHAFT, IMPELLER Price: $89.99 |
| 37 |
532174683 |
WASHER, THRUST 5/8 Price: $6.99 |
| 38 |
532174686 |
BUSHING.FLANGE.(.625X.75) This part replaces 532407758. Price: $22.99 |
| 39 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532407767. Price: $4.99 |
| 40 |
532086447 |
PLUG.AUGER.GEAR.BOX.SNOW This part replaces 532407760. Price: $3.99 |
| 41 |
532174688 |
HOUSING.GEARBOX.RH.SNOW This part replaces 532407761. Price: $22.99 |
| 42 |
532174698 |
SEAL, OIL This part replaces 532407770. Price: $4.99 |
| 43 |
532174701 |
BUSHING FLANGE 1" This part replaces 532407762. Price: $29.99 |
| 44 |
532189282 |
KEY, SQUARE 1/4 X .875 Price: $4.99 |
| 45 |
598831601 |
Service Kit This part replaces 532407763. Price: $199.99 |
| 46 |
532174657 |
SHAFT, AUGER This part replaces 532407764. Price: $59.99 |
| 47 |
532407765 |
HOUSING.GEARBOX.LH(SERVICE) Price: $22.99 |
| 48 |
531167901 |
SERVICE KIT IMPELLER WELDMENT This part replaces 532184105. Price: $44.99 |
| 49 |
596322101 |
BOLT HEXAGON BOLT 1/4-20 X 1-5 This part replaces 874780426. Price: $2.99 |
| 50 |
532175311 |
GASKET.AUGER.GEARBOX This part replaces 532407766. Price: $7.99 |
| 51 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532184205. Price: $3.99 |
| 55 |
532198638 |
SPACER.3943.SLEEVE.250X.47 Price: $5.99 |
| 56 |
532429112 |
WRENCH.SNOWTHROWER.ZINC.YZ This part replaces 532180684. Price: $3.99 |
