| Ref | Part Number | Description |
|---|
| 1 |
710-0528 |
Screw, 5/16-18, 1.25, Gr5 Price: $3.90 |
| 2 |
710-0599 |
Screw, 1/4-20, 0.500 Price: $3.86 |
| 3 |
710-0895 |
Screw, 1/4-15, 0.750 Price: $5.82 |
| 4 |
710-0924 |
Screw, Machine, 1/4-20, 0.750 Price: $4.02 |
| 5 |
710-1017 |
Screw, 1/4-14, 0.625 Price: $7.26 |
| 6 |
712-0185 |
SPEED NUT 1/4-20 Not Available Price: |
| 7 |
712-0292 |
Nut, Tinn Clip, 1/4-20 Price: $8.97 |
| 8 |
712-04063 |
Nut, Flange Lock, 5/16-18, Gr F, Nylon Price: $3.56 |
| 9 |
925-0963 |
Lamp This part replaces 725-0963. Price: $6.73 |
| 10 |
925-1649A |
HEADLIGHT SOCKET (1/4 TURN) This part replaces 725-1649. Price: $10.30 |
| 11 |
726-0201 |
Nut, Speed, .3125 ID Price: $6.01 |
| 12 |
753-0895 |
TRACTOR GRILLE 9-STYLE Not Available This part replaces 731-04960. Price: |
| 13 |
731-05078C |
Dash Collar Assembly This part replaces 731-05078. Price: $15.85 |
| 14 |
731-05224 |
PLUG:0.285 DIA. Not Available Price: |
| 16 |
936-0119 |
LOCK WASHER 5/16 This part replaces 736-0119. Price: $4.29 |
| 17 |
736-3078 |
Washer, Flat, .344 x 1.0 x .063 Price: $3.95 |
| 18 |
747-2138 |
HINGE ROD Not Available Price: |
| 19 |
783-0783A |
HOOD:3 STYLE Not Available This part replaces 783-0783. Price: |
| 20 |
783-0784A |
Side Panel, RH Price: $70.28 |
| 21 |
783-0785 |
SIDE PANEL (LH) 9 STYLE Not Available Price: |
| 23 |
731-2269A |
HOOD BELLOW Not Available Price: |
| 23 |
731-2270A |
HOOD BELLOW Not Available Price: |
| 24 |
726-0230 |
Cable Tie, 34.75 Price: $23.95 |
| 25 |
751-0555D |
FUEL TANK 1.36 GAL This part replaces 751-0555B. Price: $78.46 |
| 26 |
751-0603B |
TANK CAP This part replaces 751-0603. Price: $20.42 |
| 27 |
710-3217 |
Screw, Machine, #8-32, 0.375 Price: $5.94 |
| 28 |
712-0142 |
Nut, Hex, #8-32, Gr A Price: $3.90 |
| 29 |
710-1017 |
Screw, 1/4-14, .625 Price: $7.26 |
| 30 |
946-1084 |
Throttle Cable This part replaces 746-1084. Price: $29.76 |
| 30 |
946-1086 |
THROTTLE CABLE This part replaces 746-1086. Price: $31.31 |
| 31 |
946-1085A |
Choke Cable This part replaces 746-1085A. Price: $28.73 |
| 32 |
731-1857 |
Knob, Control Price: $12.90 |
| 33 |
731-1999 |
Plug Price: $8.98 |
| 34 |
925-06119C |
IGNITION MODULE SWITCH RMC (MAN PTO BLK) This part replaces 725-04227. Price: $102.50 |
| 35 |
925-1745A |
IGNITION KEYS This part replaces 725-1744. Price: $15.91 |
| 36 |
710-0607 |
Screw, 5/16-18, 0.500 Price: $6.06 |
| 37 |
753-05614 |
REPLACEMENT DASH KIT Not Available This part replaces 683-04189. Price: |
