| Ref | Part Number | Description |
|---|
| 1 |
137-6105 |
SHORT REAR ROLLER ASM (2.5IN DIA)(22IN) This part replaces 114-5406. Price: $478.13 |
| 1 |
532124162 |
Transaxle 6sp Hvy Dana (AYP part number) Price: $570.54 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
532146682 |
SPRING,BRAKE RETURN This part replaces 532110422. Price: $4.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
532123666 |
Pulley Transaxle Alum (AYP part number) Price: $22.99 |
| 4 |
812000028 |
Ring Retainer # 5100-62 (AYP part number) Price: $4.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
532121520 |
Strap Pnt Torque 30 Deg Blk (AYP part number) Price: $3.99 |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 6 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 7 |
114-5400 |
PLASTIC WIEHLE ROLLER ASM Price: $477.85 |
| 8 |
532141002 |
Rod Shifter (AYP part number) This part replaces 532127288. Price: $16.58 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
876020416 |
Pin Cotter 1/8 X 1 Cad (AYP part number) Price: $3.99 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
532105701 |
Washer Plate Shf 388 Sq Hole (AYP part number) Price: $3.99 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 12 |
819151216 |
Washer 15/32 X 3/4 X 16Ga (AYP part number) Price: Call Us |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
871040412 |
Bolt Fin Hex 1/4-28unfx3/4 Gr8 (AYP part number) Price: $3.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
810040400 |
Washer Lock Hvy Helical 1/4 (AYP part number) Price: $3.99 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
532121520 |
Strap Pnt Torque 30 DEG BLK (AYP part number) Price: $3.99 |
| 18 |
874760612 |
Bolt Fin Hex 3/8-16unc X 3/4 (AYP part number) Price: $1.99 |
| 19 |
873680600 |
Nut Crownlock 3/8-16 Unc Price: $1.99 |
| 20 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 21 |
532121466 |
Knob Duckhead 3/8 - 16 (AYP part number) Price: $3.99 |
| 22 |
532130804 |
Rod Brake Lt (AYP part number) Price: $17.99 |
| 23 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 24 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 25 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $2.99 |
| 26 |
819131316 |
Washer 13/32 X 13/16 X 16 Ga (AYP part number) Price: $2.99 |
| 27 |
876020412 |
Pin Cotter 1/8 X 3/4 Cad (AYP part number) Price: $3.99 |
| 28 |
532133261 |
Rod Brake Parking (AYP part number) Price: $3.99 |
| 29 |
532071673 |
Cap Parking Brake Black (AYP part number) Price: $3.99 |
| 30 |
532130807 |
Bracket Transmission (AYP part number) Price: $3.99 |
| 31 |
532127275 |
Keeper Belt Lh Lt 14 Ga (AYP part number) Price: $3.99 |
| 32 |
539976934 |
HCS 5/16C X 3/4 This part replaces 874760512. Price: $1.99 |
| 33 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 34 |
532122424 |
Shaft Asm Pedal Foot 1 930 (AYP part number) Price: $21.56 |
| 35 |
532120183 |
Bearing Nylon Blk 629 ld (AYP part number) Price: $2.99 |
| 36 |
819211616 |
Washer 21/32 X 1 X 16 Ga (AYP part number) Price: $3.99 |
| 37 |
532001572 |
Pin, Roll, 3/16 x 1 (AYP part number) This part replaces 532124963. Price: $3.99 |
| 38 |
532123674 |
Pulley Idler Flat (AYP part number) Price: $17.99 |
| 39 |
874760644 |
Bolt Fin Hex 3/8-16unc X 2-3/4 (AYP part number) Price: $3.99 |
| 40 |
532124965 |
Spacer Split 395 X 59 Bzp (AYP part number) Price: $3.99 |
| 41 |
532109070 |
Keeper Belt Retainer (AYP part number) Price: $3.99 |
| 42 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 43 |
873680600 |
Nut Crownlock 3/8-16 Unc Price: $1.99 |
| 44 |
532105706 |
Bearing Nyl 503 X 628 X 1 25 (AYP part number) Price: $3.99 |
| 45 |
532110812 |
Washer Hardened (AYP part number) Price: $3.10 |
| 46 |
812000039 |
Ring Klip #t5304-50 (AYP part number) Price: $3.99 |
| 47 |
532139245 |
Pulley, Idler V Groove (AYP part number) This part replaces 532127783. Price: $22.99 |
| 48 |
532123789 |
Bellcrank Asm (AYP part number) Price: $13.07 |
| 49 |
532123205 |
Retainer Belt Style Spring (AYP part number) Price: $3.99 |
| 50 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 (AYP part number) This part replaces 874760624. Price: $3.99 |
| 51 |
873680600 |
Nut Crownlock 3/8-16 Unc Price: $1.99 |
| 52 |
819131316 |
Washer 13/32 X 13/16 X 16 Ga (AYP part number) Price: $2.99 |
| 53 |
532199652 |
LINK.CLUTCH.7.66.2005 This part replaces 532105710. Price: $8.99 |
| 54 |
876020412 |
Pin Cotter 1/8 X 3/4 Cad (AYP part number) Price: $3.99 |
| 55 |
532105709 |
Spring Return Clutch 6 75 (AYP part number) Price: $7.99 |
| 56 |
876020412 |
Pin Cotter 1/8 X 3/4 Cad (AYP part number) Price: $3.99 |
| 57 |
532138255 |
BELT, V GROUND DRIVE 95 25 This part replaces 532130801. Price: $27.99 |
| 58 |
532127274 |
Keeper Belt Rh Lt Pnt/zinc 16g (AYP part number) Price: $2.99 |
| 59 |
532136715 |
Keeper Belt Chassis Span Ctr (AYP part number) This part replaces 532104777. Price: $6.79 |
| 60 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 61 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 62 |
532008883 |
PEDAL COVER This part replaces 532124872. Price: $3.99 |
| 63 |
532140189 |
Pulley, Engine (AYP part number) This part replaces 532109841. Price: $29.99 |
| 64 |
747810110 |
This part replaces 532125120. Price: Call Us |
| 65 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 66 |
532129921 |
Keeper Belt Engine Lh Lt (AYP part number) Price: $3.99 |
| 67 |
874780616 |
BOLT This part replaces 874760616. Price: $3.99 |
| 68 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 69 |
873680600 |
Nut Crownlock 3/8-16 Unc Price: $1.99 |
| 74 |
532109502 |
Spacer Split 80x 94 Cad/zinc (AYP part number) Price: $3.99 |
| 75 |
532121749 |
Washer 25/32 X 1 1/4 X 16 Ga (AYP part number) Price: $1.99 |
| 76 |
812000001 |
Ring E (AYP part number) Price: $2.99 |
| 77 |
532123583 |
Key Square 2 0 X 1845/ 1865 (AYP part number) Price: $2.99 |
| 78 |
532121748 |
Washer 25/32 X 1 5/8 X 16ga (AYP part number) Price: $1.99 |
| 80 |
532131488 |
Arm Pnt Shift T/a (AYP part number) Price: $2.99 |
| 81 |
532131489 |
Shaft Asm Pnt Shifter (AYP part number) Price: $3.33 |
| 82 |
532123782 |
Spring Torsion T/a (AYP part number) Price: $2.99 |
| 83 |
734117771 |
BUSHING This part replaces 819171216. Price: $2.99 |
| 84 |
532132182 |
Rod Link Shift Adj 3 710 (AYP part number) Price: $41.60 |
| 85 |
873610400 |
NUT.FIN HEX 1/4-28 UNF This part replaces 873530400. Price: $2.99 |
| 86 |
532127272 |
Bushing Pivot W/ 180 Step Pm (AYP part number) Price: $3.33 |
| 87 |
532126591 |
Washer Shim 53 X 1 25 X 0598 (AYP part number) Price: $2.99 |
| 88 |
812000003 |
E Ring Price: $3.99 |
| 89 |
532127287 |
Console Shift 5sp W/ign Lt Srs Price: $12.22 |
| 91 |
874760540 |
Bolt Fin Hex 5/16-18uncx 2-1/2 (AYP part number) Price: $2.99 |
| 93 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 94 |
532126197 |
Washer 1 - 1/2 OD x 15/32 ID x .250 (AYP part number) Price: $4.99 |
| 98 |
532142600 |
KIT CLUTCH ELECT REPL This part replaces 532108218. Price: $329.99 |
| 99 |
532109169 |
Retainer Asm. (AYP part number) Price: $17.99 |
| 100 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 101 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 102 |
810100800 |
Washer, Lock #8 (AYP part number) Price: $1.99 |
| 103 |
819060718 |
Washer 3/16 x 7/16 x 18 Ga. (AYP part number) Price: $2.99 |
| 104 |
532002751 |
Clip, Insulated (AYP part number) This part replaces 532124996. Price: $2.42 |
| 105 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
