| Ref | Part Number | Description |
|---|
| 1 |
32144-26 |
SCREW-FLOW, TAPTITE Price: $5.75 |
| 1 |
531167901 |
SERVICE KIT IMPELLER WELDMENT This part replaces 532184105. Price: $44.99 |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
598831601 |
Service Kit This part replaces 532196710. Price: $199.99 |
| 3 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 3 |
75-2810 |
BRACKET-COLUMN, STEERING Price: $11.01 |
| 4 |
532427071 |
PULLEY.IMPELLER.SNOW This part replaces 532191079. Price: $27.99 |
| 4 |
75-0560 |
STEERING WHEEL ASM Price: $204.13 |
| 5 |
585056901 |
CHUTE.DISCHARGE.BASE This part replaces 532175322. Price: $9.99 |
| 5 |
68-5370 |
DECAL Price: $6.21 |
| 6 |
32144-21 |
SCREW Price: $0.20 |
| 6 |
597433002 |
Brackets This part replaces 532184095. Price: $3.99 |
| 7 |
532192199 |
CLEAN OUT TOOL Price: $14.99 |
| 7 |
68-5140 |
CAP-WHEEL, STEERING Price: $15.13 |
| 8 |
3220-6 |
NUT-JAM Price: $1.25 |
| 8 |
532405400 |
CLIP.CLEANOUT.TOOL Price: $2.99 |
| 9 |
233-17 |
KNOB Price: $10.58 |
| 9 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 10 |
596322101 |
BOLT HEXAGON BOLT 1/4-20 X 1-5 This part replaces 874780426. Price: $2.99 |
| 10 |
75-0580 |
DISCONTINUE Price: Call Us |
| 11 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 11 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 12 |
596031601 |
Screws This part replaces 532163183. Price: $2.99 |
| 12 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 13 |
75-1490 |
ROD-BRAKE, PARKING Price: $50.23 |
| 13 |
819111507 |
WASHER, FLAT Price: $4.99 |
| 14 |
237-22 |
O-RING Price: $2.43 |
| 14 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 15 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
874940516 |
CAPSCREW.HX.HD.5/16-18X1.00.NY Price: $3.99 |
| 16 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 16 |
532180355 |
BOLT.CARRIAGE.5/16-18X Price: $3.99 |
| 17 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 17 |
532194189 |
SCREW.HWH.13-16-5.8.BZP Price: $4.99 |
| 18 |
532086447 |
PLUG.AUGER.GEAR.BOX.SNOW This part replaces 532407760. Price: $3.99 |
| 18 |
75-6230 |
HOSE Price: $133.10 |
| 19 |
532174688 |
HOUSING.GEARBOX.RH.SNOW This part replaces 532407761. Price: $22.99 |
| 19 |
75-6240 |
HOSE Price: $137.49 |
| 20 |
532175311 |
GASKET.AUGER.GEARBOX This part replaces 532407766. Price: $7.99 |
| 20 |
63-7900-03 |
RACK This part replaces 63-7900. Price: $144.55 |
| 21 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 21 |
532174698 |
SEAL, OIL This part replaces 532407770. Price: $4.99 |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 22 |
532174701 |
BUSHING FLANGE 1" This part replaces 532407762. Price: $29.99 |
| 23 |
532007396 |
WASHER RACE BEARING THRUST This part replaces 532174697. Price: $3.99 |
| 23 |
75-5940 |
HOSE Price: $94.45 |
| 24 |
598831601 |
Service Kit This part replaces 532407763. Price: $199.99 |
| 24 |
75-6230 |
HOSE This part replaces 75-6220. Price: $133.10 |
| 25 |
532174657 |
SHAFT, AUGER This part replaces 532407764. Price: $59.99 |
| 25 |
75-6250 |
HOSE Price: $175.77 |
| 26 |
532189282 |
KEY, SQUARE 1/4 X .875 Price: $4.99 |
| 26 |
75-0600 |
UNIT-STEERING, POWER Price: $1,809.64 |
| 27 |
21-9260 |
COVER-DUST Price: $8.19 |
| 27 |
532174686 |
BUSHING.FLANGE.(.625X.75) This part replaces 532407758. Price: $22.99 |
| 28 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 28 |
532174683 |
WASHER, THRUST 5/8 Price: $6.99 |
| 29 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 29 |
532407757 |
SHAFT, IMPELLER Price: $89.99 |
| 30 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 30 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532184205. Price: $3.99 |
| 31 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 31 |
532174681 |
WASHER, THRUST 3/4 Price: $11.99 |
| 32 |
532174684 |
BEARING TRUST 3/4 NTA-1220 Price: $6.99 |
| 33 |
532407769 |
BUSHING, FLANGE 3/4 Price: $7.99 |
| 34 |
532407768 |
O-RING Price: $3.99 |
| 35 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532407767. Price: $4.99 |
