| Ref | Part Number | Description |
|---|
| 2 |
712-0237 |
Hex L-Nut 5/16-24 Thd. Price: $4.37 |
| 3 |
736-0242 |
Belleville Wash..345" I.D. Price: $3.75 |
| 4 |
731-0806A |
STEERING WHEEL Not Available Price: |
| 5 |
931-0954 |
STEERING BELLOW 9" Not Available This part replaces 731-0954. Price: |
| 6 |
611-0007 |
Steering Shaft Ass'y. Price: Call Us |
| 7 |
737-0280 |
GREASE FITTING (SLOTTED) Price: $6.84 |
| 9 |
783P08577A |
STABILIZER PLATE This part replaces 17198A. Price: $6.48 |
| 10 |
938-0141 |
SHOULDER SCREW .437 DIA x .350 Not Available This part replaces 738-0141. Price: |
| 11 |
710-1039 |
Hex Bolt 3/8-24 x 1" Lg. This part replaces 710-0152. Price: $4.02 |
| 13 |
950-0535 |
Spacer.380" I.D. x .625" O.D. x .227 This part replaces 750-0535. Price: $3.90 |
| 15 |
710-0726 |
Hex Wash. Hd. Self-Tap Scr. Price: $3.82 |
| 16 |
711-0788 |
STEERING DRAG LINK Not Available Price: |
| 17 |
783-0041C |
PIVOT BAR BRACKET Not Available This part replaces 17621. Price: |
| 18 |
738-0527 |
Shoulder Bolt .498" Dia. x 2.04" Lg. 3/8-16 Thd. Price: $7.90 |
| 21 |
712-0237 |
Hex Cent. L-Nut 5/16-24 Thd. Price: $4.37 |
| 22 |
983-0055-0637 |
Steering Arm Front Axle This part replaces 16481. Price: $41.85 |
| 23 |
710-0772 |
Hex Bolt 5/16-24 x 2.00" Lg. (Grade 5) Price: $3.93 |
| 24 |
741-0487C |
Flange Bearing .632 ID This part replaces 741-0487A. Price: $6.87 |
| 26 |
17585 |
Front Axle Ass'y.- L.H. Price: $61.80 |
| 28 |
912-0446 |
Hex Jam Nut 3/8-24 Thd. This part replaces 712-0446. Price: $5.94 |
| 29 |
923-3018 |
Ball Joint, 3/8-24 This part replaces 723-3018. Price: $15.50 |
| 30 |
747-0753 |
Tie Rod Price: $29.86 |
| 32 |
97584A-0637 |
AXLE ASSEMBLY (RH) This part replaces 17584. Price: $67.14 |
| 33 |
634-0056B-0911 |
Wheel Ass'y. Comp. This part replaces 634-0056. Price: $218.84 |
| 34 |
753-0838-0662 |
WHEEL RIM GREY Not Available This part replaces 634-0024. Price: |
| 35 |
741-0487C |
Flange Bearing .632 ID This part replaces 741-0487A. Price: $6.87 |
| 36 |
736-0285 |
Fl-Wash..635" I.D. x 1.59" O.D. Price: $3.89 |
| 37 |
931-0484A |
Hub Cap This part replaces 731-0484A. Price: $5.98 |
| 39 |
736-0187 |
Fl-Wash..640" I.D. x .24" O.D. Price: $4.02 |
| 40 |
726-0214 |
Push Cap Price: $9.11 |
| 45 |
736-0343 |
Fl-Wash..33" I.D. x 1.25" O.D. Price: $3.90 |
| 46 |
950-0532 |
SPACER Not Available This part replaces 750-0532. Price: |
| 51 |
717-1701 |
STEERING GEAR SEGMENT Not Available Price: |
| 52 |
941-0225 |
FLANGE BEARING This part replaces 741-0225. Price: $6.55 |
| 54 |
618-0030 |
Steering Ass'y. Comp. Price: Call Us |
| 58 |
936-0271 |
SPRING WASHER .317 X .625 X .020 This part replaces 736-0271. Price: $3.93 |
| 61 |
736-0607 |
Ext. L-Wash. 5/16" I.D. Price: $3.66 |
| 66 |
17777 |
BRACKET-VE Not Available Price: |
| 67 |
710-0412 |
Hex Bolt 1/4-28 x .75" Lg. Price: $4.95 |
| 68 |
912-3057 |
Hex Nut 5/16-24 Thd. This part replaces 712-0123. Price: $5.94 |
| 70 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 72 |
710-0157 |
Hex Bolt 5/16-24 x .75" Lg. Price: $3.90 |
| 73 |
717-1700 |
SHAFT-PINION Not Available Price: |
| 74 |
717-1705 |
COUPLER-SPLINED Not Available Price: |
| 75 |
712-0262 |
Hex L-Nut 3/8-24 Thd. Price: $3.90 |
| 76 |
723-0420 |
ROD END (RH) Not Available Price: |
| 77 |
923-0421 |
ROD END (LH)-3/8-24 Not Available This part replaces 723-0421. Price: |
| 78 |
710-0459A |
Hex Cap Screw 3/8-24 x 1.5 This part replaces 710-0459. Price: $6.50 |
| 79 |
950-0535 |
Spacer.380" I.D. x .625" O.D. x .227 This part replaces 750-0535. Price: $3.90 |
| 80 |
750-0809 |
SHOULDER SPACER Not Available Price: |
| 81 |
736-0105 |
Bell-Wash..38" I.D. x .88" Price: $3.96 |
| 82 |
747-0761 |
TIE ROD Not Available Price: |
| 84 |
912-0296 |
HEX LOCK NUT 3/8-2 Not Available This part replaces 712-0296. Price: |
| 85 |
736-3027 |
FLAT WASHER Not Available Price: |
| 86 |
736-0253 |
Bell-Wash..505" I.D. x 1.0" Price: $3.58 |
| 87 |
17764 |
BOOM-STEERING Not Available Price: |
| 88 |
738-0838 |
LINK-STEERING Not Available Price: |
| 89 |
710-3181 |
Hex Bolt 1/2-13 x 1.5" Lg. (Gr. 5) Price: $6.01 |
| 90 |
934-0255 |
TUBELESS VALVE This part replaces 734-0255. Price: $3.83 |
| 91 |
734-1607 |
WHEEL RIM Not Available Price: |
| 92 |
N/A |
UNKNOWN |
| 93 |
710-1142 |
BOLT-LOCK 1/2 x 20 x 1.75 Not Available Price: |
| 95 |
736-0343 |
Fl-Wash..33" I.D. x 1.25" Price: $3.90 |
| 96 |
717-1298 |
WHEEL FLANGE ASS'Y. Not Available Price: |
| 97 |
936-0420 |
FLAT WASHER 1.006X1.56X.040 Not Available This part replaces 736-0420. Price: |
| 98 |
710-0191 |
Hex Bolt 3/8-24 x 1.25" Lg. Price: $4.02 |
| 99 |
17646 |
STEERING BRKT. - R H. Not Available Price: |
| 100 |
741-04488 |
Bearing This part replaces 741-0558. Price: $8.17 |
| 101 |
736-0445 |
Fl-Wash..76" I.D. x 1.5" Price: $3.95 |
| 102 |
741-0547 |
Flange Brg. 3/4" I.D. Price: $13.48 |
| 103 |
737-3001 |
Grease Fitting Price: $10.74 |
| 104 |
717-1291 |
WHEEL BRG. HOUSING Not Available Price: |
| 106 |
717-1271 |
SLEEVE-PIVOT Not Available Price: |
| 107 |
717-1270 |
U-JOINT Not Available Price: |
| 109 |
715-0208 |
PIN CYLINDER MTG Not Available Price: |
| 110 |
717-1285 |
AXLE HORN ASS'Y. Not Available Price: |
| 111 |
736-0105 |
Bell-Wash..38" I.D. x .88" Price: $3.96 |
| 112 |
936-0356 |
BELL WASHER Not Available This part replaces 736-0356. Price: |
