| Ref | Part Number | Description |
|---|
| 1 |
120-2072 |
HYD MOTOR ASM This part replaces 112-9200. Price: $646.57 |
| 1 |
592618801 |
SERVICE KIT KIT.SVC.WELDMENT.5 This part replaces 588549002. Price: $1,199.99 |
| 2 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 3 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 4 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 6 |
117-0174-03 |
BRACKET-BULKHEAD Price: $43.53 |
| 6 |
590304203 |
COVER 54 CLEARCUT RH MANDREL G Price: $22.99 |
| 7 |
32144-57 |
SCREW Price: $1.04 |
| 7 |
590304303 |
COVER 54 CLEARCUT, LH MANDREL, Price: $9.99 |
| 8 |
105-3048 |
WASHER-FLAT Price: $0.89 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 9 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 10 |
99-8611 |
SPACER Price: $5.71 |
| 11 |
114-8887 |
TUBE ASM Price: $100.66 |
| 11 |
582760502 |
BLADE CC54 PZ STYLE HI LIFT BL Price: $34.99 |
| 12 |
2412-113 |
CLAMP-R Price: $0.75 |
| 13 |
117-0142 |
TUBE ASM Price: $136.47 |
| 14 |
340-78 |
NUT-LOCK Price: $1.63 |
| 14 |
539131898 |
MANDREL ASM, CAST IRON Price: $69.99 |
| 15 |
117-0140 |
TUBE ASM Price: $100.52 |
| 16 |
56-7971 |
CLAMP-TUBE Price: $17.90 |
| 17 |
117-0141 |
TUBE ASM Price: $127.80 |
| 18 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 19 |
94-5780 |
SCREW-HWH Price: $7.49 |
| 20 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 20 |
532197236 |
SPACER.IDLER.PULLY.HUB Price: $7.99 |
| 21 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 22 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 22 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
| 23 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 23 |
588438301 |
SCREW.7/16-14 X 2.125.WASHER Price: $5.99 |
| 24 |
114-0633 |
HOSE-HYD Price: $149.34 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
117-5190 |
HOSE-HYD Price: $171.44 |
| 25 |
587354701 |
SPRING.42.FCS.DEFLECTOR Price: $5.99 |
| 26 |
106-3671 |
HOSE-HYD Price: $112.38 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
117-5188 |
HOSE-HYD Price: $192.82 |
| 27 |
590632201 |
DEFLECTOR ASSY 54 CLEARCUT RES Price: $64.99 |
| 28 |
106-3680 |
HOSE-HYD Price: $73.67 |
| 28 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 29 |
114-0633 |
HOSE-HYD Price: $149.34 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
98-4590 |
HOSE-HYD Price: $76.24 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173435 |
MANDREL.PULLEY.38.BRIGHT.ZINC This part replaces 532153532. Price: $19.99 |
| 33 |
139-5996 |
HOSE GUIDE ASM-LH This part replaces 119-3921. Price: $32.43 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
139-5995 |
GUIDE-HOSE, RH This part replaces 119-3920. Price: $32.43 |
| 35 |
117-0177 |
TUBE ASM Price: $127.80 |
| 36 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 37 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 43 |
582219602 |
ARM IDLER ARM, CLEARCUT 54 BLA Price: $4.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
582236301 |
BELT CLEARCUT 54, TRACTOR DECK Price: $59.99 |
| 48 |
574196502 |
Tubes This part replaces 574196501. Price: $17.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
574169601 |
ROLLER, GAUGE .635 BORN Price: $14.99 |
| 52 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 53 |
594944501 |
Bolts This part replaces 872140864. Price: $7.99 |
| 54 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 61 |
596274401 |
Rods This part replaces 532400337. Price: $9.99 |
| 62 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 63 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 66 |
590732501 |
BUMPER ASSY 54 CLEARCUT TRIM S Price: $8.99 |
| 97 |
532178515 |
WASHER Price: $5.99 |
| 98 |
587358401 |
SPRING.EXTN.42.FCS.TR.DECK.DRV Price: $6.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY Price: $8.99 |
| 184 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 187 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 190 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 192 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $7.99 |
| 196 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
