| Ref | Part Number | Description |
|---|
| 1 |
106-1100 |
CASE-AXLE Price: $406.39 |
| 1 |
532408007 |
BELT.V.IMPELLER Price: $29.99 |
| 2 |
532419744 |
V-BELT TRACTION 34.25 Price: $22.99 |
| 2 |
99-7594 |
SEAL-OIL Price: $5.99 |
| 3 |
584232402 |
ARM.IDLER BRAKE.CLEAR.ZINC This part replaces 532429271. Price: $11.99 |
| 3 |
99-7535 |
PLUG Price: $8.15 |
| 4 |
532180523 |
PULLEY.W/SPACER.2.75 Price: $17.99 |
| 4 |
99-7536 |
WASHER-SEAL Price: $2.58 |
| 5 |
532426589 |
NUT.FLANGE.HEX.5/16X18.BLACK Price: $2.99 |
| 5 |
95-7528 |
GEAR-BEVEL, 27 TOOTH Price: $333.09 |
| 6 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874780524. Price: $1.99 |
| 6 |
99-7532 |
BEARING-ROLLER, TAPER Price: $45.81 |
| 7 |
532423990 |
RP.BRACKET.IDLER.PIVOT.BLACK This part replaces 532429270. Price: $3.99 |
| 7 |
95-7526 |
COVER-AXLE Price: $87.93 |
| 8 |
106-1072 |
O-RING Price: $21.08 |
| 8 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 9 |
532424297 |
BOLT.SHOULDER.1/2X12 Price: $2.99 |
| 9 |
99-7589 |
PLUG Price: $3.73 |
| 10 |
532751153 |
NUT.LOCK.5/16-18 Price: $1.99 |
| 10 |
99-7590 |
WASHER-SEAL Price: $2.94 |
| 11 |
104-2374 |
BOLT This part replaces 99-7596. Price: $6.33 |
| 11 |
532187786 |
ARM, IDLER Price: $7.99 |
| 12 |
106-1102 |
BOLT-STOP Price: $22.71 |
| 12 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $17.99 |
| 13 |
874520520 |
BOLT.5/16-18X1-1/4 FULL THD This part replaces 874780520. Price: $2.99 |
| 14 |
532059289 |
STEEL WASHER Price: $2.99 |
| 15 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 16 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.99 |
| 17 |
532400026 |
WASHER, FLAT 3/8 Price: $2.99 |
| 18 |
532426491 |
PULLEY.IMPELER. Price: $14.99 |
| 19 |
532426490 |
PULLEY.ENG.TRACTION Price: $11.99 |
| 20 |
874610516 |
SCREW Price: $2.99 |
| 21 |
810040500 |
LOCKWASHER Price: $2.99 |
| 22 |
532155452 |
BELT.GUIDE.RH Price: $3.99 |
| 23 |
810040500 |
LOCKWASHER This part replaces 811050500. Price: $2.99 |
