| Ref | Part Number | Description |
|---|
| 1 |
112-1687 |
CROSS AND BEARING KIT Price: $130.01 |
| 1 |
532439699 |
SEAT.XH130.MS498.G.HUSQ.NONTEX This part replaces 532190120. Price: $179.99 |
| 2 |
532140551 |
Bracket, Pivot Seat Price: $3.99 |
| 3 |
532140675 |
Strap Asm Fender Price: $3.99 |
| 3 |
54-9040 |
YOKE-END Price: $246.14 |
| 4 |
532127018 |
Bolt Shoulder 5/16-18 x .62 Price: $3.99 |
| 4 |
54-9090 |
YOKE-END Price: $202.33 |
| 5 |
532145006 |
Clip, Push In Hinged Price: $2.99 |
| 6 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 7 |
539110300 |
SRPING.SEAT This part replaces 532124181. Price: $2.99 |
| 8 |
532171877 |
Bolt 5/16-18 Unc x 3/4 Price: $3.99 |
| 10 |
532195530 |
PAN, SEAT This part replaces 532182493. Price: $14.99 |
| 12 |
532174648 |
Bracket, Mounting Switch Price: $4.99 |
| 13 |
532121248 |
Bushing, Snap Price: $3.99 |
| 14 |
872050412 |
Bolt, Carriage 1/4-20 x 1-1/2 Price: $3.99 |
| 15 |
532134300 |
Spacer, Split Price: $3.99 |
| 16 |
532121250 |
Spring, Cprsn Price: $3.99 |
| 17 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 532123976. Price: $2.69 |
| 18 |
819171912 |
Washer 17/32 x 1-3/16 x 12 Ga. Price: $3.99 |
| 19 |
532166369 |
Knob Seat Price: $4.99 |
| 20 |
532124238 |
Cap, Spring Seat Price: $3.99 |
| 21 |
532171852 |
Bolt, Shoulder 5/16-18 Price: $3.99 |
| 22 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
