| Ref | Part Number | Description |
|---|
| 1 |
120-3841 |
HOSE-CLEANER, AIR Price: $92.41 |
| 2 |
130-7177 |
SHROUD-UNDERCARRIAGE Price: $591.88 |
| 4 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 5 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 6 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 6 |
532140051 |
BRACKET ASSY HOOD Price: $3.68 |
| 7 |
532140050 |
BRACKET ASSY Price: $3.99 |
| 8 |
33-5790 |
BOLT-CARR Price: $3.69 |
| 9 |
322-13 |
SCREW-HH Price: $2.73 |
| 10 |
322-6 |
SCREW-HH Price: $0.45 |
| 10 |
532130850 |
BRACE HOOD Price: $2.99 |
| 11 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 11 |
532140142 |
HOOD - LR This part replaces 532165791. Price: $339.99 |
| 12 |
532130986 |
LENS.LR.LH.HUSQV. This part replaces 532165794. Price: $12.99 |
| 13 |
532404673 |
GRILLE.KIT.SERVICE.HUSQ.LR This part replaces 532165792. Price: $449.99 |
| 14 |
133-2790 |
ENGINE-KUBOTA, WG1605 Price: $10,816.43 |
| 15 |
132-7629-03 |
MOUNT-BOX, FUSE Price: $25.99 |
| 16 |
130-7174 |
MOUNT-ISOLATION Price: $3.75 |
| 17 |
125-2921 |
FITTING-FUEL Price: $13.96 |
| 17 |
596582501 |
Bolts This part replaces 874780410. Price: $2.99 |
| 18 |
104-7201 |
NUT-HF Price: $0.69 |
| 19 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 20 |
33114-020 |
SCREW-HH Price: $0.28 |
| 20 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 21 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 21 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 22 |
532130985 |
LENS RH This part replaces 532165793. Price: $13.22 |
| 24 |
532142873 |
BRACKET PIVOT Price: $2.99 |
| 26 |
532052921 |
CLIP TINNERMAN Price: $2.68 |
| 28 |
811050400 |
Washer, Lock, External Tooth 1/4 Price: $5.99 |
| 34 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 35 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 36 |
532128445 |
BRACKET HOOD Price: $2.99 |
