| Ref | Part Number | Description |
|---|
| 1 |
85-5900 |
IDLER ARM ASM Price: $92.86 |
| 2 |
33104-016 |
SCREW-HHF Price: $0.97 |
| 3 |
93-4971-01 |
SUPPORT-IDLER Price: $78.50 |
| 4 |
32128-32 |
NUT-HHF Price: $2.69 |
| 5 |
283-82 |
PIN-CLEVIS Price: $3.94 |
| 6 |
85-5920-01 |
BRACKET-SPRING Price: $10.48 |
| 7 |
32128-49 |
NUT-HHF Price: $1.04 |
| 8 |
69-6960 |
SPACER-IDLER Price: $22.57 |
| 9 |
140-5848 |
PULLEY-IDLER This part replaces 63-1540-03. Price: $62.48 |
| 10 |
321-8 |
SCREW-HH Price: $0.34 |
| 11 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 12 |
325-8 |
SCREW-HH Price: $3.52 |
| 15 |
33116-030 |
SCREW-HH Price: $1.56 |
| 19 |
93-4945-01 |
SKID-LH ASM Price: $265.53 |
| 20 |
93-4942-01 |
RH SKID ASM Price: $245.09 |
| 21 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 22 |
33125-025 |
SCREW-CARR Price: $1.28 |
| 29 |
93-4539 |
DECK ASM Price: $5,588.85 |
| 31 |
85-5940 |
ROD-SPRING Price: $17.77 |
| 32 |
33105-020 |
SCREW-HHF Price: $0.54 |
| 33 |
93-4970 |
SHAFT-IDLER Price: $103.46 |
| 34 |
85-5930 |
TUBE-BRACKET, SPRING Price: $13.30 |
| 36 |
302-33 |
FITTING-GREASE Price: $2.31 |
