| Ref | Part Number | Description |
|---|
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 12 |
586478501 |
ENGINE.PULLEY Price: $27.99 |
| 15 |
529999102 |
TANK ASSY W/CAP 3 GAL CARB This part replaces 589900501. Price: $329.99 |
| 18 |
585124801 |
CAP ASSY FUEL 3" GRAY Price: $17.99 |
| 20 |
117-5542 |
BRACKET Price: $47.03 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
108-7088 |
BOLT Price: $1.22 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 40 |
98-9360 |
BOLT Price: $2.35 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 50 |
99-7526 |
NUT This part replaces 98-7737. Price: $1.29 |
| 60 |
98-9366 |
WASHER-PLAIN This part replaces 98-7696. Price: $0.28 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 Price: $17.99 |
| 70 |
98-7738 |
WASHER-SPRING Price: $0.24 |
| 71 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 Price: $19.99 |
| 80 |
98-7692 |
BOLT Price: $0.92 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE Price: $2.99 |
| 86 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 90 |
105-3745 |
PULLEY-DRIVE, FAN Price: $293.55 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
