| Ref | Part Number | Description |
|---|
| 1 |
85-6190-01 |
LINK-DECK, TILT This part replaces 77-4870. Price: $45.41 |
| 2 |
3290-495 |
PIN-KLIK This part replaces 32-0140. Price: $5.47 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 3 |
340-126 |
NUT-BULKHEAD Price: $4.61 |
| 4 |
340-70 |
NUT-LOCK Price: $2.10 |
| 5 |
69-8940 |
WASHER Price: $1.76 |
| 6 |
240-4 |
GROMMET-RUBBER Price: $9.91 |
| 7 |
69-5690 |
HYDRAULIC TUBE Price: $79.82 |
| 8 |
237-30 |
O-RING Price: $2.50 |
| 9 |
596501502 |
Keepers This part replaces 584908001. Price: $9.99 |
| 9 |
71-3970 |
DISCONTINUED Price: Call Us |
| 10 |
3234-28 |
SCREW-HHF Price: $1.59 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 11 |
69-5660 |
DIAGNOSTIC HOSE Price: $131.21 |
| 12 |
353-375 |
FITTING-ELBOW, 90 Price: $42.42 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
237-78 |
O-RING Price: $3.85 |
| 14 |
237-58 |
O-RING Price: $2.18 |
| 15 |
322-10 |
SCREW-HH Price: $0.70 |
| 15 |
583507201 |
TANK.ASSY.XTERNAL.FILL.GT2.TEX This part replaces 532435816. Price: $129.99 |
| 16 |
69-5470 |
HOSE ASSEMBLY Price: $247.74 |
| 17 |
69-5480 |
HOSE ASSEMBLY Price: $276.13 |
| 18 |
237-65 |
O-RING Price: $2.50 |
| 18 |
532441462 |
CAP.ASM.FUEL.2.25"TOP.TURN Price: $11.99 |
| 19 |
69-5760 |
HOSE ASSEMBLY Price: $352.70 |
| 20 |
586219601 |
CONTROL.THROTTLE/CHOKE.PRO.45 This part replaces 532424340. Price: $54.99 |
| 20 |
69-5400 |
DISCONTINUED X-REF Price: Call Us |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
69-5770 |
DISCONTINUED Price: Call Us |
| 22 |
106-0067 |
LH TRACTION TUBE ASM This part replaces 69-6200. Price: $210.48 |
| 23 |
106-0066 |
RH TRACTION TUBE ASM This part replaces 69-6190. Price: $210.48 |
| 24 |
71-2450-01 |
COVER-ACCESS This part replaces 71-2450. Price: $84.32 |
| 25 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 26 |
69-8930 |
WASHER Price: $0.81 |
| 27 |
69-8960 |
SPACER Price: $5.29 |
| 28 |
240-5 |
GROMMET Price: $13.66 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
85-6150 |
TUBE-HYD This part replaces 76-4460. Price: $105.19 |
| 31 |
69-8970 |
SPACER Price: $9.57 |
| 32 |
237-22 |
O-RING Price: $2.43 |
| 33 |
69-6050 |
TUBE-HYD Price: $125.05 |
| 34 |
69-6040 |
TUBE-HYD Price: $150.53 |
| 35 |
69-6030 |
TUBE-HYD Price: $144.98 |
| 36 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
69-5790 |
TUBE-HYD Price: $156.00 |
| 38 |
69-6060 |
TUBE-HYD Price: $131.82 |
| 39 |
69-5880 |
DISCONTINUED Price: Call Us |
| 40 |
32108-103 |
SCREW-FH Price: $0.68 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 41 |
69-9300 |
PAD-BUMPER Price: $8.68 |
| 42 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
321-9 |
SCREW-HH Price: $0.27 |
| 44 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 45 |
32152-4 |
NUT-LOCK, CONE Price: $1.29 |
| 46 |
256-247 |
BUSHING-FLANGE Price: $2.17 |
| 47 |
240-7 |
GROMMET-RUBBER Price: $16.51 |
| 48 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 49 |
69-0100-01 |
FRAME ASM This part replaces 69-0100. Price: $4,443.63 |
| 50 |
69-6100 |
TUBE-HYD Price: $257.08 |
| 51 |
69-8910 |
WASHER Price: $1.70 |
| 52 |
69-8900 |
SPACER Price: $14.26 |
| 53 |
3220-3 |
NUT-HJ Price: $0.28 |
| 54 |
71-2660 |
DISCONTINUED X-REF Price: Call Us |
| 55 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 56 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 57 |
69-5950 |
TUBE-HYD Price: $91.94 |
| 58 |
237-21 |
O-RING Price: $0.70 |
| 59 |
340-125 |
FITTING-TEE Price: $64.10 |
| 61 |
93-9988 |
ADAPTER This part replaces 340-123. Price: $131.12 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 62 |
71-2640 |
DISCONTINUED X-REF Price: Call Us |
| 63 |
69-9470-01 |
COVER-ACCESS This part replaces 69-9470. Price: $45.44 |
| 64 |
71-0430 |
ABRASIVE-FLOOR Price: $7.36 |
| 65 |
321-11 |
SCREW-HH Price: $0.36 |
| 66 |
71-0420 |
ABRASIVE-FLOOR Price: $76.07 |
| 67 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 68 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 69 |
69-5663 |
DISCONTINUED Price: Call Us |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN Price: $27.99 |
| 70 |
69-5664 |
DIAGNOSTIC HOSE Price: $121.94 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK Price: $22.99 |
| 71 |
72-4080 |
DECAL-DANGER Price: $26.01 |
| 72 |
2410-10 |
BUTTON-PLUG Price: $6.16 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 108 |
583400501 |
COVER.PULLEY.ENGINE.SRD.FRENCH This part replaces 532423041. Price: $89.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 137 |
532441461 |
SPILL.CUP Price: $7.99 |
