| Ref | Part Number | Description |
|---|
| 1 |
110-4130 |
CYLINDER-STEER, HYD This part replaces 75-1230. Price: $823.03 |
| 1 |
532421705 |
TUBE.LOWER.HANDLE.SNOW.GRAY Price: $159.99 |
| 2 |
532422117 |
SUPPORT.WELDMENT.ROTATOR. Price: $6.99 |
| 2 |
710-0573 |
Screw, Hex Cap Lock, 5/16-18 x 1.25 GR5 Price: $5.53 |
| 3 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 Price: $4.99 |
| 3 |
710-3006 |
SCREW .375 x 5/16-18 Not Available Price: |
| 3 |
75-1210 |
DISCONTINUED Price: Call Us |
| 4 |
711-1339 |
MOTOR SHAFT Not Available Price: |
| 4 |
75-1220 |
PISTON Price: $252.80 |
| 5 |
75-1260 |
HEAD Price: $225.87 |
| 5 |
911-04345 |
PINION SHAFT 16T Not Available This part replaces 711-1344. Price: |
| 6 |
75-1250 |
SEAL KIT Price: $147.65 |
| 7 |
711-1397 |
SHAFT-2 SPD ACTUAT Not Available Price: |
| 8 |
715-0159 |
SPRING PIN Not Available Price: |
| 9 |
716-0185 |
Ring, Retaining Price: $3.22 |
| 10 |
716-0384 |
Ring, Retaining Price: $3.74 |
| 11 |
716-0387 |
RETAINING RING Not Available Price: |
| 12 |
716-0393 |
RETAINING RING Not Available Price: |
| 13 |
716-0396 |
ROTOR CLIP Not Available Price: |
| 14 |
717-3472 |
DRIVE GEAR 24T/17T Not Available Price: |
| 15 |
717-3473 |
DRIVE GEAR 33T/17T Not Available Price: |
| 16 |
717-3480 |
DRIVE GEAR 59T/50T Not Available Price: |
| 17 |
717-3484 |
OVERRUNNING CLUTCH Not Available Price: |
| 18 |
718-0674 |
FRONT COVER Not Available Price: |
| 19 |
718-0678 |
DRIVE SPACER Not Available Price: |
| 20 |
718-3116 |
Collar, 2 Speed Price: $77.88 |
| 21 |
721-0496 |
Seal, Oil Price: $9.52 |
| 22 |
721-0501 |
O-RING 2.987 x .103 Not Available Price: |
| 23 |
721-0507 |
OIL SEAL Not Available Price: |
| 24 |
932-05125 |
DETENT SHAFT SPRING This part replaces 732-0863. Price: $3.66 |
| 25 |
736-0715 |
THRUST WASHER Not Available Price: |
| 26 |
741-0862 |
DETENT BALL .250 Price: $3.90 |
| 27 |
741-1106 |
BALL BEARING Not Available Price: |
| 28 |
741-1107 |
BALL BEARING Not Available Price: |
| 29 |
741-1109 |
ANGULAR CONTACT BEARING Not Available Price: |
| 30 |
741-1112 |
THRUST BEARING Not Available Price: |
| 31 |
941-3037 |
Bearing, Ball This part replaces 741-3037. Price: $38.73 |
| 32 |
941-3057 |
Bearing, Ball, 20x47x14, 6204 This part replaces 741-3057. Price: $35.46 |
| 33 |
741-3118 |
Bearing, Sleeve Price: $23.07 |
