| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 2 |
62-7240 |
DISCONTINUED Price: Call Us |
| 5 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 6 |
93-6912 |
DISCONTINUED Price: Call Us |
| 7 |
283-75 |
PIN-CLEVIS Price: $1.56 |
| 9 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 9 |
581952101 |
CABLE.DRIVE.RWD.WALK. Price: $29.99 |
| 10 |
532432790 |
BRACKET.DRIVE.CONTR.GEN2.BLACK Price: $3.99 |
| 10 |
92-1818-01 |
ARM-SPRING, TENSION This part replaces 92-1818. Price: $13.39 |
| 11 |
323-9 |
SCREW-HH Price: $1.29 |
| 11 |
817411312 |
SCREW.HX.13X.750 Price: $4.99 |
| 12 |
32144-109 |
SCREW-THD Price: $1.29 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 13 |
581680801 |
TRANSMISSION.22+AWD.WALK.MOWER Price: $129.99 |
| 14 |
532193443 |
PULLEY.1.PIECE Price: $13.99 |
| 14 |
93-6893 |
PIN-PIVOT, RAM Price: $49.13 |
| 15 |
532088348 |
WASHER.FLAT.1/2 Price: $3.99 |
| 15 |
92-1812 |
SHAFT-PIVOT, LIFT Price: $51.90 |
| 16 |
532430030 |
ROD.CONNECTING.RGD.22+.HW.BLAC Price: $17.99 |
| 17 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 17 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 18 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 18 |
532438536 |
KIT.SELECTOR.ASM.437869 This part replaces 532437869. Price: $41.99 |
| 19 |
94-5009 |
HOSE ASM Price: $102.32 |
| 20 |
580806901 |
COVER.REAR.DRIVE.22+2013 Price: $19.99 |
| 20 |
94-5008 |
HOSE ASM Price: $102.26 |
| 21 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 21 |
532435242 |
SCREW.PLASTIC.ANCHOR.5/16 Price: $4.99 |
| 22 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 23 |
532437870 |
ADJUSTER.ARM.ASM.AX.RT.SP.ZC Price: $24.99 |
| 23 |
93-6869 |
HYD CYLINDER ASM Price: $638.61 |
| 24 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 24 |
532433511 |
BRACKET.WHL.ADJ.9.POS.W/PAD Price: $9.99 |
| 25 |
532426065 |
BRACKET.DRIVE.COVER.RGD.BZP Price: $6.99 |
| 26 |
532442153 |
BRACKET.TRANS.BELTKEEP.22+RGD Price: $4.99 |
| 26 |
93-6696 |
DECAL-WARNING Price: $14.78 |
| 28 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 28 |
812000058 |
E-RING 7/16 RE Price: $2.99 |
| 29 |
581840401 |
COVER.DUST.WHEEL.INNER.WALK Price: $5.99 |
| 29 |
93-6926 |
PIN-CLEVIS Price: $33.72 |
| 30 |
322-4 |
SCREW-HH Price: $0.35 |
| 30 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 31 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 31 |
532404845 |
PAWL, DRIVE Price: $4.99 |
| 32 |
322-26 |
SCREW-HH Price: $2.36 |
| 32 |
581685101 |
WHEEL.8X1.75.3SPK.RAD3.GREY Price: $24.99 |
| 33 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 33 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532409148. Price: $3.99 |
| 34 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 34 |
532197480 |
O-RING..070X.487.NEOPRENE Price: $3.99 |
| 35 |
532430598 |
AXLE.REAR.RGD Price: $39.99 |
| 35 |
94-3635 |
CENTER LIFT ARM ASM Price: $280.94 |
| 36 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 36 |
532442207 |
AXLE.ASM.FRONT.RGD.CLEAR.ZINC Price: $49.99 |
| 37 |
532163409 |
SCREW Price: $3.99 |
| 37 |
99-2338 |
SHAFT-PIVOT Price: $101.09 |
| 38 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 38 |
532191730 |
NUT.HEX.FLANGE.1/4 Price: $3.99 |
| 39 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 39 |
532407059 |
SHOULDER BOLT SEMI GIMLET PT. Price: $3.99 |
| 40 |
237-78 |
O-RING Price: $3.85 |
| 40 |
532401273 |
WHEEL.8X1.75.H3SPK.RAD3.GY.BB1 This part replaces 532410831. Price: $29.99 |
| 41 |
237-21 |
O-RING Price: $0.70 |
| 41 |
532404835 |
PINIION.14.TOOTH.RGD Price: $5.99 |
| 42 |
98-3445 |
SPACER Price: $6.02 |
| 43 |
98-3446 |
PLATE-REINFORCEMENT Price: $11.38 |
| 44 |
323-4 |
SCREW-HH Price: $1.02 |
| 44 |
532437799 |
BELT.DRIVE.RGD.BBC Price: $19.99 |
| 47 |
532067725 |
WASHER FLUT Price: $5.99 |
| 48 |
532438489 |
KIT.WASH-OUT.PORT.ZINC.WALK Price: $14.99 |
| 49 |
532438489 |
KIT.WASH-OUT.PORT.ZINC.WALK This part replaces 532434994. Price: $14.99 |
| 50 |
532415585 |
WASHER.LOCK.INTERNAL.TOOTH Price: $2.99 |
| 51 |
532415586 |
LOCKNUT.HEX.WITH.O-RING Price: $4.99 |
| 55 |
532406558 |
SPRING Price: $6.99 |
| 58 |
532435241 |
SCREW.12-14X1.500 Price: $3.99 |
| 59 |
532442113 |
BRACKET.SUPPORT.22+RWGD.BZP Price: $3.99 |
| 61 |
532181698 |
SCREW, PHILLIPS HEAD 10 X 5/8 Price: $3.99 |
| 62 |
532197991 |
CLIP.CABLE.BLK Price: $3.99 |
| 63 |
532428124 |
FASTENER.PUSH.O.250X0.783 Price: $1.99 |
| 84 |
532416405 |
COUPLING.QUICK CONNECT Price: $8.99 |
| 85 |
532439077 |
BRACKET.FRT.AXLE.SUPPORT Price: $19.99 |
