| Ref | Part Number | Description |
|---|
| 1 |
322-14 |
SCREW-HH Price: $1.01 |
| 1 |
603-04018 |
HI LO HANDLE LINK Not Available Price: |
| 2 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 2 |
603-0945 |
PEDAL SHAFT ASSEMBLY Not Available Price: |
| 3 |
256-219 |
BUSHING Price: $7.59 |
| 3 |
603-04273 |
BRAKE SHAFT ASSEMBLY Not Available Price: |
| 4 |
603-0947 |
REVERSE SHAFT ASSEMBLY Not Available Price: |
| 4 |
85-8960 |
SPACER Price: $11.44 |
| 5 |
603-0948A |
PARK BRAKE LINK Not Available Price: |
| 5 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 6 |
703-05039A |
HI LO PIVOT LINK Not Available This part replaces 703-05039. Price: |
| 6 |
92-2343-01 |
PEDAL ASM This part replaces 92-2343. Price: $59.71 |
| 7 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
703-05666 |
HANDLE-HI LO SHIFT Not Available Price: |
| 8 |
3272-16 |
PIN-COTTER Price: $0.31 |
| 8 |
703-05674-0637 |
SWITCH MOUNTING BRACKET (POWDER BLACK) This part replaces 703-05674. Price: Call Us |
| 9 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 9 |
703-4105 |
BRAKE LEVER Not Available Price: |
| 10 |
703-3012 |
Link, Pedal Mounting Price: $18.10 |
| 10 |
95-0584 |
ROD-CONTROL Price: $84.20 |
| 11 |
703-3152 |
REVERSE SWITCH BRACKET Not Available Price: |
| 11 |
92-2344 |
TRUNNION Price: $81.16 |
| 12 |
3218-5 |
NUT-JAM Price: $0.27 |
| 12 |
703-3156A |
BRAKE PEDAL LINK Not Available Price: |
| 13 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 13 |
703-3183 |
PEDAL BRACKET Not Available Price: |
| 14 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 14 |
710-0521 |
Screw, Hex Cap 3/8-16 x 3.0 GR8 Price: $4.54 |
| 15 |
710-0599 |
Screw, Hex Wash Hd Tapp 1/4-20 x .5 Price: $3.86 |
| 16 |
710-0623 |
Screw, Hex Wash Hd Tapp 3/8-16 x .75 Price: $3.93 |
| 17 |
710-0642 |
Screw, Hex Wash Hd Tapp 1/4-20 x .75 Price: $4.05 |
| 18 |
710-3005 |
Screw, Hex Cap 3/8-16 x 1.25GR5 Price: $3.61 |
| 19 |
710-3170 |
SCREW 5/16-18 x .56 Not Available Price: |
| 20 |
911-04038 |
BRAKE FERRULE This part replaces 711-04038. Price: $17.41 |
| 21 |
911-0701 |
Clevis Pin 1/4" Dia. x .53" Lg. This part replaces 711-0701. Price: $5.99 |
| 22 |
711-3397 |
FERRULE 3/8-24 Not Available Price: |
| 23 |
711-0679A |
Pin, Clevis, 3/8 x 2.015 Price: $12.40 |
| 24 |
911-0723A |
FERRULE 3/8-24 x .375 x 1.31 LG Not Available This part replaces 711-0723A. Price: |
| 25 |
711-1363 |
PIN 3/8-16 x 2.21 Not Available Price: |
| 26 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 27 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 28 |
912-3027 |
Nut, Hex Flange Lock 1/4-20 This part replaces 712-3027. Price: $3.85 |
| 29 |
712-0375 |
Nut, Hex Lock, 3/8-16 Price: $4.02 |
| 30 |
912-3058 |
Hex Lock Nut, 1/2-20 This part replaces 712-3058. Price: $4.92 |
| 31 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 32 |
714-0145 |
Pin, Internal Cotter Price: $4.42 |
| 33 |
714-0507 |
Pin, Cotter, 3/32 x .750 Price: $3.93 |
| 34 |
714-0147 |
Pin, Internal Cotter Price: $4.20 |
| 35 |
916-0104 |
E-Ring This part replaces 716-0104. Price: $3.37 |
| 36 |
725-04232 |
Switch, Plunger (Brake) Price: $46.03 |
| 37 |
925-3164A |
Switch, Interlock This part replaces 725-3164A. Price: $37.67 |
| 38 |
727-04004 |
Cylinder, Damper Price: $113.87 |
| 39 |
731-3247 |
Pedal, Forward Price: $71.80 |
| 40 |
731-3248 |
Pedal, Reverse Price: $83.46 |
| 41 |
731-3249A |
BRAKE PEDAL Not Available Price: |
| 42 |
731-3250 |
DIFF LOCK PEDAL Not Available Price: |
| 43 |
731-3321 |
Grip, Handle Price: $18.83 |
| 44 |
732-04009 |
COMPRESSION SPRING Not Available Price: |
| 45 |
925-3167 |
Switch, Snap Mount Normally Open (Black) This part replaces 725-3167. Price: $13.53 |
| 46 |
932-0384 |
EXTENSION SPRING Not Available This part replaces 732-0384. Price: |
| 47 |
732-0859A |
SPRING Not Available Price: |
| 48 |
732-3118 |
Spring, Extension, 3/8 x 1.44 Price: $8.78 |
| 49 |
712-0711 |
Nut, Hex Jam, 3/8-24 Price: $3.90 |
| 50 |
736-0173 |
Washer, Flat, .28 x .74 x .063 ... Price: $3.76 |
| 51 |
736-3019 |
Washer, Flat, .53 x .1.06 x .134 Price: $5.45 |
| 52 |
738-0140 |
Screw, Shoulder, .435 x 1.78 Price: $4.93 |
| 53 |
938-0255 |
Shoulder Screw, .375 Dia. x .181 This part replaces 738-0255. Price: $4.53 |
| 54 |
738-0533 |
SCREW:SHLDR:0.498X1.630:3/8-16 This part replaces 7380533. Price: $7.42 |
| 55 |
738-0982 |
Screw, Shoulder .498 x 3.245: 3/8-16 Price: $12.40 |
| 56 |
941-0598 |
Hex Flange Bearing, .752 This part replaces 741-0598. Price: $11.91 |
| 57 |
741-0491 |
Bearing, Nylon. .50 ID x .341 Price: $4.39 |
| 58 |
941-3073 |
Bearing, Flng., .375 x .580 x .250 This part replaces 741-3073. Price: $4.66 |
| 59 |
746-04017 |
Cable, Diff Lock Price: $69.80 |
| 60 |
747-04021 |
BRAKE ROD (LH) Not Available Price: |
| 61 |
747-04022 |
BRAKE ROD (RH) Not Available Price: |
| 62 |
747-3486 |
HYDRO CONTROL ROD Not Available Price: |
| 63 |
747-3324 |
FORWARD PED ROD Not Available Price: |
| 64 |
747-3353 |
CONNECTION ROD Not Available Price: |
| 65 |
747-3366 |
DIFFERENTIAL SHAFT Not Available Price: |
| 66 |
748-0190 |
Spacer, .508 x .75 x .68 Price: $5.48 |
| 67 |
948-0227A |
Bearing, hex Flange .629 Id This part replaces 748-0227A. Price: $7.61 |
| 68 |
736-0160 |
Washer, Flat, .53 ID x .93 x .05.. Price: $3.90 |
| 69 |
750-0668 |
SPACER Not Available Price: |
| 70 |
703-05665 |
HI LO HANDLE BRACKET Not Available Price: |
| 71 |
710-0703 |
Screw.Carriage, 1/4-20 x .75 GR5 Price: $3.66 |
| 503145101 |
503145101 |
CLUTCH SPRING Price: $7.99 |
| 503254601 |
503254601 |
NEEDLE BEARING Price: $11.99 |
| 503521204 |
503521204 |
WASHER Price: $4.99 |
| 503714003 |
503714003 |
CLUTCH Price: $49.99 |
| 503819371 |
503819371 |
CLUTCH DRUM .325 Price: $44.99 |
| 537079101 |
537079101 |
CLUTCH DRUM Price: $37.99 |
