| Ref | Part Number | Description |
|---|
| 1 |
481599 |
Grip, Handle Bar Price: Call Us |
| 3 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 4 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 5 |
04041-07 |
Flatwasher, 3/8" (.391 x .938 x .105) Price: Call Us |
| 6 |
422372 |
Bar, Control Lever Price: Call Us |
| 7 |
45915 |
Control Lever Price: Call Us |
| 8 |
04001-17 |
Bolt, Hex Head 5/16-18 x 2" Price: Call Us |
| 9 |
04021-10 |
Nut, Hex Elastic Stop 5/16-18 Price: Call Us |
| 10 |
04001-45 |
Bolt, Hex Head 3/8-16 x 2" Price: Call Us |
| 11 |
04021-09 |
Nut, Hex Elastic Stop Price: Call Us |
| 13 |
48224 |
Ball Bearings, Neutral Return Price: Call Us |
| 14 |
04001-10 |
Bolt, Hex Head 5/16-18 x 1-1/4" Price: Call Us |
| 15 |
04069-01 |
Pin, Rue Cotter 3/8 Dia. Price: Call Us |
| 16 |
04110-02 |
U-Nut, 5/16-18 Price: Call Us |
| 17 |
04021-13 |
Nut, Hex Elastic Stop 5/8-11 Price: Call Us |
| 18 |
45973 |
Bracket, Control Lever LH Price: Call Us |
| 19 |
04003-04 |
Bolt, Carriage 5/16-18 x 1" Price: Call Us |
| 20 |
43465 |
Spacer, Bearing Price: Call Us |
| 21 |
04003-12 |
Bolt, Carriage 5/16-18 x 3/4" Price: Call Us |
| 22 |
04019-03 |
Nut, Hex Serrated Flange 5/16-18 Price: Call Us |
| 23 |
04050-01 |
Ring, Retaining 5/8" External "E" Price: Call Us |
| 25 |
45918 |
Bracket, Neutral Return Price: Call Us |
| 26 |
04003-02 |
Bolt, Carriage 1/4-20 x 3/4" Price: Call Us |
| 27 |
04040-14 |
Flatwasher, 1/4" (.312 x .750 x .065) Price: Call Us |
| 28 |
04021-08 |
Nut, Hex Elastic Stop 1/4-20 Price: Call Us |
| 29 |
43477 |
Pin, Retaining Spring Price: Call Us |
| 30 |
481389 |
Spring Price: Call Us |
| 31 |
04060-01 |
Roll Pin, Spring 5/32 x 3/4" Price: Call Us |
| 32 |
04061-06 |
Pin, Cotter 9/16 x 1-1/2" Price: Call Us |
| 33 |
482586 |
Rod End, Male 3/8-24 RH Thread This part replaces 481539. Price: Call Us |
| 34 |
04020-25 |
Nut, 3/8-24 RH Thread Price: Call Us |
| 35 |
43463 |
Tube, Control Link Price: Call Us |
| 36 |
04020-26 |
Nut, Hex 3/8-24 LH Thread Price: Call Us |
| 37 |
482585 |
Rod End, Male 3/8-24 LH Thread This part replaces 481538. Price: Call Us |
| 38 |
451073 |
Brake Linkage Weldment LH Price: Call Us |
| 39 |
451074 |
Brake Linkage Weldment RH Price: Call Us |
| 40 |
04001-09 |
Bolt, Hex Head 5/16-18 x 1" Price: Call Us |
| 41 |
48114-04 |
Grease Fitting Price: Call Us |
| 43 |
481548 |
Grip, Parking Brake Price: Call Us |
| 44 |
04001-22 |
Bolt, Hex Head 3/8-16 x 2-3/4" Price: Call Us |
| 45 |
04019-04 |
Nut, Hex Serrated Flange 3/8-16 Price: Call Us |
| 46 |
48343-04 |
Clevis, 3/8-24 This part replaces 48343-02. Price: Call Us |
| 47 |
04064-02 |
Pin, Clevis 3/8-16 x 1-1/16" Price: Call Us |
| 48 |
04061-02 |
Pin, Cotter 3/32 x .75 Price: Call Us |
| 49 |
04004-34 |
Rod, Parking Brake Price: Call Us |
| 50 |
48544 |
Rod End, LH Thread Price: Call Us |
| 51 |
48796 |
Bushing, Self Align Price: Call Us |
| 52 |
04001-08 |
Bolt, Hex Head 5/16-18 x 3/4" Price: Call Us |
| 53 |
04001-147 |
Bolt, Hex Head 3/8-24 x 5-1/4", 2-3/4" Thread Price: Call Us |
| 54 |
481637 |
Switch Price: Call Us |
| 55 |
04010-12 |
Screw, Hex SLTD WSHR Head #10-32 x 3/4" Price: Call Us |
| 56 |
461471 |
Brake Linkage LH This part replaces 45978. Price: Call Us |
| 57 |
45953 |
Bellcrank, Brake Actuator Price: Call Us |
| 58 |
48807 |
Spring Price: Call Us |
| 59 |
04001-145 |
Bolt, Hex Head 1/2-13 x 3-1/2" Price: Call Us |
| 60 |
04021-19 |
Locknut, Hex 1/2-13 Center Lock Price: Call Us |
| 61 |
04001-52 |
Bolt, Hex Head 1/2-13 x 2-1/2" Price: Call Us |
| 62 |
482639 |
Wheel Motor, Ross This part replaces 481529. Price: Call Us |
| 63 |
46929 |
Wheel Hub Assembly Price: Call Us |
| 64 |
481601 |
Brake Band Assembly Price: Call Us |
| 65 |
04064-03 |
Pin, Clevis 3/8" Dia. x 2" Price: Call Us |
| 66 |
43063 |
Spacer Price: Call Us |
| 67 |
48513 |
Brake Drum Price: Call Us |
| 68 |
422487 |
Spacer, Wheel Price: Call Us |
| 69 |
481850 |
Wheel Assembly 24 x 12-12 Turf Master Price: Call Us |
| 70 |
04028-01 |
Lug Nut, 1/2 20 Price: Call Us |
| 71 |
48680 |
Nut, Hex Castle Price: Call Us |
| 72 |
422373 |
Plate, Threaded Price: Call Us |
| 73 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 74 |
422494 |
Bracket, Switch Mounting Price: Call Us |
| 75 |
423057 |
Bracket, Switch Actuator This part replaces 422493. Price: Call Us |
| 76 |
04017-16 |
Bolt, Hex Serrated Flange 5/16-18 x 3/4" Price: Call Us |
| 422362 |
Bracket, |
Control Lever RH Price: Call Us 422362 |
| 461472 |
Brake |
Linkage RH This part replaces 45979. Price: Call Us 461472 |
