| Ref | Part Number | Description |
|---|
| 1 |
117-8470 |
LH TRAILING ARM ASM Price: $808.58 |
| 4 |
119-6200-03 |
HANDLE-LIFT Price: $228.52 |
| 5 |
119-2994 |
CRANK-LIFTING, RAKE Price: $81.90 |
| 6 |
117-8490-03 |
HANDLE-TRIP Price: $36.41 |
| 7 |
117-8503-03 |
CRANK-BELL, LIFTING LH Price: $74.36 |
| 8 |
105-3450 |
GRIP-LEVER, LIFT Price: $6.25 |
| 9 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 10 |
3233-2 |
SCREW-CARR Price: $1.49 |
| 11 |
119-6188 |
TUBE-PIVOT Price: $4.23 |
| 12 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 13 |
13-0100 |
PIVOT-LINK, RAKE LIFT Price: $61.98 |
| 14 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 15 |
1-633131 |
YOKE-LINKAGE, BRAKE Price: $14.99 |
| 16 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 17 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 18 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 19 |
95-8603 |
SPACER Price: $8.43 |
| 24 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
117-8506-03 |
MOUNT-GUARD Price: $49.01 |
| 28 |
3232-3 |
BOLT-CARR Price: $2.14 |
| 29 |
114-8417 |
NUT-HF, NI Price: $0.87 |
| 30 |
13-0480 |
SPRING Price: $30.51 |
| 33 |
3231-29 |
SCREW-CARR Price: $0.68 |
| 34 |
119-6217-03 |
SUPPORT-ARM, TRAILING Price: $12.33 |
| 35 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 36 |
3256-28 |
WASHER-FLAT Price: $0.48 |
