| Ref | Part Number | Description |
|---|
| 2 |
631-04501A |
Bearing Assembly This part replaces 631-04501. Price: $5.78 |
| 3 |
710-04995A |
SCREW 5/16-14 x .750 This part replaces 710-04995. Price: $3.61 |
| 4 |
712-04222 |
Nut, Sq., 1/4-20 Price: $4.77 |
| 5 |
749-07298-0637 |
LOWER HANDLE (POWDER BLACK) This part replaces 749-04608A-0637. Price: $8.76 |
| 6 |
710-04998 |
Carriage Screw ,5/16-18 Price: $4.89 |
| 7 |
710-0654A |
Screw, 3/8-16 x 1.00 Price: $3.75 |
| 8 |
687-02220 |
Blade Adapter Price: $33.78 |
| 9 |
942-0741A |
Mulching Blade Price: $27.55 |
| 10 |
736-0524B-1 |
BLADE BELL SUPPORT This part replaces 736-0524B. Price: $5.34 |
| 11 |
710-1044 |
Screw, 3/8-24 x 1.50 Price: $3.48 |
| 12 |
731-07203 |
Trailing Shield Price: $9.41 |
| 13 |
749-04705-0637 |
LINK TUBE (POWDER BLACK) Not Available Price: |
| 14 |
747-05362A |
Grass Bag Frame This part replaces 747-05362-0637. Price: $38.39 |
| 15 |
964-04141B |
Grass Bag This part replaces 964-04141. Price: $45.56 |
| 16 |
631-04514A |
Rear Discharge Door Assembly This part replaces 631-04514. Price: $73.50 |
| 17 |
732-05061B |
TORSION SPRING (RH) This part replaces 732-04673. Price: $4.64 |
| 18 |
732-04674A |
Torsion Spring - LH This part replaces 732-04674. Price: $3.76 |
| 19 |
720-04113 |
Adjustment Lever Knob Price: $9.09 |
| 20 |
710-04374 |
Screw, Hex Washer, .159 x .43 Price: $3.24 |
| 21 |
710-04774 |
Screw, 1/4-15 x 1.25 Price: $4.02 |
| 22 |
731-07819 |
FRONT AXLE COVER Not Available Price: |
| 23 |
731-07799 |
Transmission Cover Price: $10.05 |
| 24 |
712-04064 |
Nut, Flange Lock, 1/4-20 Price: $3.64 |
| 25 |
720-04124 |
Wing Knob Price: $4.37 |
| 26 |
911-04191B |
FRONT AXLE ASSEMBLY This part replaces 911-04191. Price: $47.82 |
| 27 |
631-04512D |
ENGINE BAFFLE ASSEMBLY This part replaces 631-04512. Price: $18.62 |
| 28 |
611-04192A |
AXLE ADJUSTMENT (REAR) This part replaces 911-04192. Price: $50.34 |
| 29 |
917-04849 |
Spur Gear, 9T Price: $3.95 |
| 30 |
732-04826A |
Exten. Spring, 2.405 This part replaces 732-04826. Price: $3.49 |
| 31 |
918-04971A |
TRANSMISSION Not Available This part replaces 918-04971. Price: |
| 32 |
712-04217 |
Flange Lock Nut, 3/8-16 Price: $3.75 |
| 33 |
753-08089 |
WHEEL KIT IDLE 8 x 2 This part replaces 734-04564. Price: $40.81 |
| 34 |
934-04699 |
Rear Wheel, 11 x 2 This part replaces 634-04666. Price: $39.25 |
| 35 |
787-01868B-0637 |
TRANSMISSION BRACKET (POWDER BLACK) This part replaces 787-01868-0637. Price: $7.69 |
| 36 |
732-04903 |
Spring Price: $3.49 |
| 37 |
749-04701A-0637 |
Upper Handle This part replaces 749-04701-0637. Price: $39.63 |
| 38 |
710-0895 |
Screw, 1/4-15 x .750 Price: $5.82 |
| 39 |
720-0279 |
Knob Price: $3.93 |
| 40 |
725-0157 |
Cable Tie Price: $3.46 |
| 41 |
710-1205 |
Rope Guide Price: $3.53 |
| 42 |
946-04726 |
Drive Cable Price: $26.19 |
| 43 |
946-04661A |
CONTROL CABLE 37.58" This part replaces 946-04661. Price: $11.88 |
| 44 |
747-05463A |
OPERATOR BAIL This part replaces 747-05463-0637. Price: $20.30 |
| 45 |
720-05067A |
Wing Nut, Red This part replaces 720-04127A. Price: $5.01 |
| 46 |
738-04419A |
Sldr. Screw, .375 x .126 x 1/4-20 Price: $3.61 |
| 47 |
731-07731C |
Wheel Dust Cover This part replaces 731-07731. Price: $8.69 |
| 48 |
731-07766 |
Control Lever LH Price: $5.78 |
| 49 |
787-01915C |
REAR CLIP SUPPORT BRACKET This part replaces 787-01915. Price: $16.76 |
| 50 |
738-04278 |
Screw, Shldr., 1/4-20 x .50 Price: $5.99 |
| 51 |
946-04729 |
Speed Adjustment Cable Price: $26.19 |
| 52 |
954-04282 |
V-Belt Price: $26.49 |
| 53 |
921-04041 |
Water Nozzle Adapter Price: $20.19 |
| 54 |
731-07487 |
Water Nozzle Price: $3.86 |
| 55 |
710-05204 |
Scr., Shldr, 1/4-15 x .970 Price: $3.42 |
| 56 |
731-07131 |
Side Discharge Chute Price: $13.83 |
| 58 |
732-1014C |
TORSION SPRING This part replaces 732-1014. Price: $7.40 |
| 59 |
747-0710A |
Hinge Pin Price: $3.86 |
| 60 |
787-01779 |
Chute Deflector Bracket Price: $4.13 |
| 61 |
710-05073 |
Screw, 1/4-20 x .500 Price: $3.52 |
| 62 |
710-0895 |
Screw, 1/4-15 x 1.000 Price: $5.82 |
| 63 |
736-04413 |
Wash., Wave, .385 ID x .598 OD Price: $3.33 |
| 64 |
741-0492A |
Bushing, Lock, .505 Dia. X .62 Price: $5.41 |
| 65 |
787-01851 |
Cable Adjust Plate Price: $11.49 |
| 66 |
731-07763 |
Upper Housing Price: $18.85 |
| 67 |
731-07764A |
Lower Housing This part replaces 731-07764. Price: $15.89 |
| 68 |
731-07804 |
Speed Adjust Actuator Price: $5.95 |
| 69 |
731-07852 |
Drive Cable Actuator Not Available Price: |
| 70 |
731-07767A |
Speed Select Lever This part replaces 731-07767. Price: $5.94 |
| 71 |
731-07765 |
CONTROL LEVER (RH) Not Available Price: |
