Deck & Baffle
Parts (12)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 712-04222 | SQUARE NUT 1/4-20 Price: $4.77 |
| 2 | 731-07203 | TRAILSHIELD Price: $9.41 |
| 3 | 120-0404 | BRACKET-HIGH HOC (LH) Price: $71.73 |
| 3 | 631-04567A | REAR BAFFLE ASSEMBLY Price: $46.54 |
| 4 | 120-0405 | BRACKET-HIGH HOC (RH) Price: $71.73 |
| 5 | 119-0626 | SHIM-ROLLER Price: $3.23 |
| 6 | 106-9758 | SCREW-CARR Price: $2.99 |
| 7 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 8 | 112-7451 | SCREW-TAP Price: $2.17 |
| 9 | 48-9220 | WASHER-PLAIN Price: $0.87 |
| 10 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 11 | 322-16 | SCREW-HH Price: $3.39 |
