SCHEMATIC
Parts (10)
| Ref | Part Number | Description |
|---|---|---|
| 010 | 131-6557 | ALTERNATOR ASM This part replaces 98-9474. Price: $443.05 |
| 020 | 112-7047 | STAY-DYNAMO This part replaces 98-9573. Price: $14.95 |
| 030 | 98-7697 | BOLT Price: $1.08 |
| 040 | 98-9360 | BOLT Price: $2.35 |
| 050 | 99-7526 | NUT This part replaces 98-7737. Price: $1.29 |
| 060 | 3256-24 | WASHER-FLAT Price: $0.28 |
| 070 | 98-7738 | WASHER-SPRING Price: $0.24 |
| 080 | 100-9233 | WASHER-PLAIN Price: $0.48 |
| 090 | 98-7692 | BOLT Price: $0.92 |
| 100 | 98-9473 | PULLEY-DRIVE, FAN Price: $319.19 |
