Baffles & Shroud
Parts (38)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 58-6320 | WIPER Price: $10.93 |
| 1 | KH-47-063-09 | Baffle, Head Price: Call Us |
| 2 | 58-6450 | O-RING Price: $2.48 |
| 2 | KH-47-063-10 | BAFFLE-CYL Not Available Price: |
| 3 | KH-X-25-53 | WASHER Not Available Price: |
| 4 | KH-47-086-08 | SCREW Not Available Price: |
| 5 | 58-6400 | BUSHING Price: $37.39 |
| 5 | KH-47-027-40 | BLOWER HOUSING Not Available Price: |
| 6 | 65-2770 | WASHER Price: $2.17 |
| 6 | KH-47-126-23 | Bracket, Duct Price: Call Us |
| 7 | 65-2950 | SPRING Price: $5.13 |
| 8 | 58-6420 | CAP Price: $42.88 |
| 8 | KH-47-063-06 | BAFFLE-SID Not Available Price: |
| 9 | 58-6460 | RING-RETAINING Price: $1.22 |
| 9 | KH-47-063-07 | BAFFLE-INN Not Available Price: |
| 10 | 65-2740 | SPACER Price: $11.31 |
| 10 | KH-52-086-11 | SCREW Not Available Price: |
| 11 | 65-2750 | PLUNGER Price: $8.76 |
| 11 | KH-X-67-64 | SCREW Not Available Price: |
| 12 | 65-2760 | SPRING Price: $4.05 |
| 12 | KH-X-25-20 | Washer, Plain, 1/4 Price: Call Us |
| 13 | 65-2930 | PLUG ASM Price: $12.27 |
| 14 | 353-508 | PLUG-HH Price: $7.96 |
| 535075501 | 535075501 | HUB CUTTING DISC Price: $8.99 |
| 535075701 | 535075702 | SPACER This part replaces 535075701. Price: $11.99 |
| 535075901 | 535075901 | PLATE SKID Price: $17.99 |
| 535076001 | 535076001 | SCREW Price: $3.99 |
| 535081501 | 535081501 | COVER SKID PLATE Price: $5.99 |
| 535082501 | 535082501 | GASKET Price: $2.99 |
| 535122001 | 535122001 | HOLDER Price: $37.99 |
| 535122301 | 535122301 | BELLOWS Price: $49.99 |
| 535123601 | 535123601 | MOTOR Price: $109.99 |
| 535126301 | 535126301 | BLADE DISC Price: $17.99 |
| 535126401 | 535126401 | BEARING Price: $7.99 |
| 535130310 | 535130310 | SCREW Price: $2.99 |
| 535130501 | 535130502 | SCREW TORX M4X8 8.8 NYLON PATC This part replaces 535130501. Price: $2.99 |
| 535130710 | 535130710 | SCREW Price: $0.54 |
| 535138501 | 535126301 | BLADE DISC This part replaces 535138501. Price: $17.99 |
