CARBURETOR DETAILS
Parts (41)
| Ref | Part Number | Description |
|---|---|---|
| 2 | 117-3238 | GAUGE-FUEL Price: $86.50 |
| 3 | 46-6560 | BUSHING Price: $2.94 |
| 3 | 522517201 | COVER Price: $5.99 |
| 4 | 117-3370 | PIPE-STAND Price: $47.06 |
| 4 | 522517401 | DIAPHRAGM Price: $17.99 |
| 5 | 46-6550 | FITTING-ELBOW, 90 DEG Price: $37.39 |
| 5 | 522517501 | GASKET Price: $4.99 |
| 6 | 503479701 | INLET NEEDLE Price: $8.99 |
| 7 | 503665901 | LEVER Price: $3.99 |
| 8 | 537383401 | SPRING Price: $3.99 |
| 9 | 537020801 | PIN This part replaces 503480001. Price: $2.99 |
| 10 | 503480101 | SCREW Price: $2.99 |
| 12 | 576414201 | MAIN NOZZLE Price: $14.99 |
| 14 | 522518701 | SPRING Price: $3.99 |
| 15 | 522517701 | LEVER Price: $7.99 |
| 17 | 503481801 | SCREW Price: $2.99 |
| 18 | 504627701 | CHOKE VALVE Price: $7.99 |
| 19 | 522518301 | SHAFT ASSY Price: $19.99 |
| 20 | 502078401 | SCREW Price: $2.99 |
| 21 | 522517801 | THROTTLE LEVER Price: $5.99 |
| 23 | 522518501 | THROTTLE SHAFT Price: $14.99 |
| 24 | 502078701 | SPRING Price: $3.99 |
| 25 | 502079801 | COLLAR Price: $5.99 |
| 26 | 503535701 | STRAINER Price: $3.99 |
| 27 | 537383101 | PUMP DIAPHRAGM Price: $11.99 |
| 28 | 537403301 | DIAPHRAGM Price: $9.99 |
| 29 | 537020101 | GASKET Price: $3.99 |
| 30 | 575544301 | COVER Price: $14.99 |
| 31 | 504026701 | E RING Price: $2.99 |
| 32 | 503479001 | SCREW Price: $2.99 |
| 33 | 522517601 | CHOKE LEVER Price: $17.99 |
| 38 | 506396601 | SCREW Price: $1.51 |
| 39 | 522518101 | SCREW Price: $2.99 |
| 41 | 537385201 | CLIP Price: $2.99 |
| 42 | 522518001 | SCREW Price: $2.99 |
| 43 | 575544401 | INLET Price: $12.99 |
| 44 | 522518601 | SPRING Price: $3.99 |
| 46 | 537177001 | THROTTLE FLAP Price: $14.99 |
| 47 | 522517901 | ROD Price: $3.99 |
| 48 | 522518201 | SHAFT ASSY Price: $17.99 |
| 49 | 578227801 | THROTTLE VALVE ASSY Price: $27.99 |
