| Ref | Part Number | Description |
|---|
| 1 |
161-1768 |
DECK SHELL ASM This part replaces 138-9026. Price: $2,183.59 |
| 2 |
139-3175 |
SPINDLE ASM-DOUBLE Price: $459.05 |
| 3 |
139-3176 |
SPINDLE ASM-HIGH Price: $443.23 |
| 4 |
139-3177 |
SPINDLE ASM-LOW Price: $427.37 |
| 5 |
137-5640 |
IDLER PIVOT ASM Price: $26.88 |
| 6 |
108-1926 |
WASHER Price: $5.30 |
| 7 |
161-1765 |
KIT, ROLLER ASM This part replaces 140-0016SP. Price: $1,695.98 |
| 8 |
137-3659-03 |
BLADE-LIFT, MEDIUM Price: $38.18 |
| 9 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 10 |
104-2444 |
BOLT-BLADE, LH THREAD Price: $27.94 |
| 11 |
161-1765 |
KIT, ROLLER ASM This part replaces 138-3083-01. Price: $1,695.98 |
| 12 |
161-1765 |
KIT, ROLLER ASM This part replaces 138-3084-01. Price: $1,695.98 |
| 13 |
140-7024 |
PLATE-SEAL, BEARING Price: $4.96 |
| 14 |
140-7090 |
DECAL-HOC This part replaces 138-3087. Price: $6.02 |
| 15 |
138-3098 |
INDICATOR-HOC Price: $5.90 |
| 16 |
140-7023 |
BEARING-FLANGE, 2 BOLT Price: $51.11 |
| 17 |
139-3181-01 |
PLATE-DOUBLER, LH Price: $48.42 |
| 18 |
139-3182-01 |
PLATE-DOUBLER, CENTER Price: $105.24 |
| 19 |
139-3183-01 |
PLATE-DOUBLER, RH Price: $48.42 |
| 20 |
138-5283 |
PULLEY-DRIVE Price: $66.29 |
| 21 |
140-7038 |
BLOCK-HOC This part replaces 138-3086. Price: $20.42 |
| 22 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 23 |
137-3648 |
SCREW-HHCS Price: $52.83 |
| 24 |
HDW17555 |
BOLT-CARRIAGE Price: $3.83 |
| 25 |
138-3092 |
NUT-HEX Price: $2.10 |
| 26 |
137-3644 |
BELT-V Price: $48.46 |
| 27 |
137-3645 |
BELT-V Price: $25.83 |
| 28 |
140-6180 |
IDLER ARM ASM This part replaces 137-3649. Price: $84.68 |
| 29 |
112-7395 |
SPRING-TORSION Price: $26.70 |
| 30 |
92-2651 |
WASHER Price: $1.83 |
| 31 |
121-5274 |
SPACER-IDLER Price: $35.01 |
| 32 |
1-613098 |
PULLEY-IDLER Price: $33.36 |
| 33 |
69-6970 |
SPACER-IDLER, FLAT Price: $13.54 |
| 34 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 35 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 36 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 37 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 38 |
3296-45 |
NUT-HEX Price: $3.79 |
| 39 |
324-5 |
SCREW-HH Price: $0.54 |
| 40 |
126-9780 |
NUT-LOCK Price: $0.96 |
| 41 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 42 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 43 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 44 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 45 |
115-9830 |
SCREW-HSBH Price: $0.42 |
| 46 |
140-7004 |
COVER-BEARING Price: $4.15 |
| 47 |
137-3660 |
BUSHING-TAPERLOCK, 32MM Price: $39.29 |
| 48 |
325-8 |
SCREW-HH Price: $3.52 |
| 49 |
132-9421 |
PULLEY-IDLER, FLAT Price: $41.10 |
