| Ref | Part Number | Description |
|---|
| 1 |
114-3988 |
FAN DRIVE ASM This part replaces 74-5520. Price: $342.27 |
| 1 |
532142986 |
HOUSING, LOWER Price: $166.25 |
| 2 |
532142987 |
HOUSING.UPPER.70122.HYDRO-GEAR Price: $138.99 |
| 2 |
75-3780 |
FAN-ENGINE Price: $367.12 |
| 3 |
532142932 |
SEAL.LIP.H-G.(9008000-0128) Price: $9.99 |
| 3 |
75-6380 |
SHAFT-FAN Price: $141.82 |
| 4 |
32121-2 |
PIN-ROLL, SLOTTED Price: $0.25 |
| 4 |
532142928 |
RING RETAINING 2003016 Price: $4.99 |
| 5 |
532142933 |
RING.RETAINING.(2003052) Price: $4.99 |
| 5 |
98-9743 |
PULLEY-DRIVE, FAN Price: $104.17 |
| 6 |
47-0110 |
SPACER-SPINDLE Price: $1.42 |
| 6 |
532142934 |
BALL BEARING Price: $49.99 |
| 7 |
251-318 |
BEARING-BALL Price: $16.40 |
| 7 |
532142935 |
CRADLE BEARING Price: $17.99 |
| 8 |
532150771 |
BEARING, THRUST 50551 This part replaces 532142936. Price: $29.99 |
| 8 |
75-5310 |
SPACER-BEARING Price: $4.41 |
| 9 |
532142937 |
SWASHPLATE (2003087) Price: $163.99 |
| 9 |
75-4450 |
HUB Price: $205.03 |
| 10 |
302-10 |
FITTING-GREASE Price: $2.64 |
| 11 |
67-1630 |
SPACER Price: $28.84 |
| 12 |
323-6 |
SCREW-HH Price: $0.66 |
| 13 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 13 |
532169898 |
KIT CYLINDER #70331 This part replaces 532142938. Price: $119.99 |
| 14 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 14 |
532142939 |
TRUNNION ARM Price: $179.99 |
| 15 |
532142940 |
LIP SEAL Price: $4.99 |
| 15 |
98-9322 |
SCREW-HSH Price: $4.89 |
| 16 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 17 |
532142941 |
SLOT GUIDE Price: $7.99 |
| 17 |
98-4598 |
CABLE-BATTERY, NEGATIVE Price: $69.78 |
| 18 |
110-0035 |
KIT-ENGINE, KUBOTA DSL This part replaces 98-9300. Price: $8,164.44 |
| 18 |
532150772 |
SHAFT, MOTOR This part replaces 532142988. Price: $182.99 |
| 19 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 19 |
532142943 |
THRUST BEARING Price: $129.99 |
| 20 |
3256-78 |
WASHER-FLAT Price: $1.21 |
| 21 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 22 |
48-7890 |
NUT-HEX Price: $0.25 |
| 23 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 23 |
532142944 |
BLOCK, CYL ASSY Price: $168.73 |
| 24 |
532142945 |
LIP SEAL Price: $3.57 |
| 24 |
57-6390 |
NUT-JAM Price: $0.89 |
| 25 |
532142946 |
BYPASS ACTUATOR Price: $18.99 |
| 25 |
98-4515-03 |
BRACKET-REAR ENGINE, LH This part replaces 98-4515. Price: $62.07 |
| 26 |
532142947 |
CENTER SECTION ASSY KIT Price: $283.99 |
| 26 |
94-4514 |
PIN-LOCK, TILT Price: $35.83 |
| 27 |
323-12 |
SCREW-HH Price: $1.14 |
| 27 |
532142948 |
LIP SEAL Price: $7.99 |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
532142949 |
RETAINING RING Price: $4.99 |
| 29 |
532142950 |
WASHER Price: $3.99 |
| 29 |
87-5100 |
WASHER-SNUBBING Price: $3.46 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 31 |
43-0090 |
SCREW-HH Price: $8.05 |
| 32 |
48-9590 |
WASHER-LOCK This part replaces 42-9600. Price: $0.25 |
| 33 |
323-10 |
SCREW-HH Price: $0.89 |
| 34 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 34 |
532169893 |
FILTER. 50990 This part replaces 532142951. Price: $109.99 |
| 35 |
33114-016 |
SCREW-HH Price: $0.27 |
| 35 |
532142952 |
BYPASS ARM Price: $20.99 |
| 36 |
532142953 |
RETAINING RING 44870 Price: $4.99 |
| 36 |
98-4596 |
WASHER-MOUNT, ENGINE Price: $20.72 |
| 37 |
121-9076 |
MOUNT-ENGINE This part replaces 83-1030. Price: $37.76 |
| 37 |
532122660 |
ARM BRAKE ACTUATO This part replaces 532142954. Price: $12.99 |
| 38 |
322-6 |
SCREW-HH Price: $0.45 |
| 38 |
532142955 |
ACTUATING PIN 44891 Price: $8.99 |
| 39 |
532142956 |
BOLT Price: $4.99 |
| 39 |
98-4539-03 |
BRACKET-ENGINE MOUNT, LH This part replaces 98-4539. Price: $179.96 |
| 40 |
532142957 |
NUT.LOCK.HX.(H-G PART 50108) Price: $5.99 |
| 40 |
98-4543-03 |
BRACKET-ENGINE MOUNT, RH This part replaces 98-4543. Price: $180.69 |
| 41 |
532142958 |
BRAKE ROTOR 70135 HYDRO-GEAR Price: $84.99 |
| 41 |
98-4530-03 |
SUPPORT-FAN This part replaces 98-4530. Price: $349.24 |
| 42 |
98-4575-03 |
LEVER-IDLER, FAN This part replaces 98-4575. Price: $43.57 |
| 43 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 43 |
532142884 |
WASHER .34X.88X.06.44130 Price: $4.99 |
| 44 |
532142990 |
DIFFERENTIAL ASSEMBLY Price: $274.75 |
| 44 |
98-9744 |
BELT-FAN Price: $35.29 |
| 45 |
323-8 |
SCREW-HH Price: $1.20 |
| 46 |
63-8140 |
PULLEY-IDLER Price: $47.94 |
| 47 |
98-9749 |
PLATE-THROTTLE Price: $29.11 |
| 48 |
98-9740 |
BRACKET-FAN, SUPPORT Price: $42.56 |
| 49 |
322-2 |
SCREW-HH Price: $0.69 |
| 50 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 51 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 52 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 52 |
532142991 |
WASHER.HYDRO-GEAR 44875 Price: $5.99 |
| 53 |
322-4 |
SCREW-HH Price: $0.35 |
| 53 |
532142961 |
SEAL.HYDRO.53901 Price: $8.99 |
| 54 |
532142962 |
O-RING Price: $2.87 |
| 54 |
98-4547 |
PLATE-MOUNT, FAN Price: $20.17 |
| 55 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 56 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 56 |
532142963 |
SHAFT.INPUT.50005 Price: $129.99 |
| 57 |
98-9741 |
BRACKET-MOUNT, FAN Price: $44.53 |
| 58 |
532142964 |
BOLT #44876 Price: $4.99 |
| 58 |
98-4513-03 |
BRACKET-ENGINE, REAR This part replaces 98-4513. Price: $78.69 |
| 59 |
532142965 |
PIN Price: $8.99 |
| 59 |
93-0095-03 |
BRACKET-ENGINE, FRONT This part replaces 93-0095. Price: $111.93 |
| 60 |
3213-2 |
SCREW-HH Price: $1.90 |
| 61 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 62 |
3256-40 |
WASHER-FLAT Price: $2.10 |
| 62 |
532142966 |
CONTROL ARM 50254 Price: $27.99 |
| 63 |
532142967 |
DAMPENER PUCK Price: $5.99 |
| 63 |
98-4561-03 |
SHIELD-ALTERNATOR This part replaces 98-4561. Price: $56.98 |
| 64 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 64 |
532142920 |
SCREW.SET.50018 Price: $5.99 |
| 65 |
532142968 |
BOLT Price: $3.85 |
| 65 |
98-4509 |
HOSE-CLEANER, AIR Price: $97.00 |
| 66 |
98-4594 |
CLAMP-RETAINER Price: $15.98 |
| 68 |
532142969 |
SPRING HELICAL COMP 50277 Price: $6.99 |
| 69 |
532144610 |
STUD 5/16-24 50284 Price: $7.99 |
| 92 |
532142977 |
SPRING 2003014 Price: $3.99 |
| 93 |
532142978 |
WASHER Price: $5.99 |
| 98 |
532142993 |
BEARING SLV 50137 Price: $11.99 |
| 99 |
532169054 |
SEAL LIP.75X1X.158 50941 This part replaces 532142976. Price: $17.99 |
| 113 |
532142578 |
VENT CAP 70109 This part replaces 532142917. Price: $37.99 |
| 114 |
532142918 |
O-RING KIT 70110 Price: $22.99 |
| 119 |
584282801 |
SPACER .32X.59X.50 50278 This part replaces 532142980. Price: $5.99 |
| 134 |
584281701 |
NUT CASTLE 5/16-24 PL 44142 This part replaces 532144607. Price: $4.99 |
