| Ref | Part Number | Description |
|---|
| 4 |
710-0347 |
HEX SCREW 3/8-16 x 1.75 GR5 Price: $4.39 |
| 5 |
710-04379A |
SCREW 7/16-20 x 3.5 GR5 Price: $5.35 |
| 6 |
710-06133 |
SCREW M6-1 x .625 Price: $3.08 |
| 7 |
710-06178 |
SCREW 3/8-16 x 2.0 Price: $5.52 |
| 8 |
710-06322 |
SCREW 5/16-18 x .875 Price: $4.55 |
| 9 |
710-07494 |
SCREW-FULL THREAD 5/16-18 GR5 Price: $3.91 |
| 10 |
710-0805A |
SCREW 5/16-18 x 1.5 LG Price: $3.75 |
| 11 |
710-3130 |
SCREW 3/8-16 x 3.25 GR8 Price: $8.85 |
| 12 |
712-0229 |
PUSH NUT Price: $3.14 |
| 13 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 14 |
712-04065 |
NUT Price: $3.68 |
| 15 |
712-04217 |
FLANGE LOCK NUT Price: $3.75 |
| 16 |
712-07050 |
HEX FLANGE NUT 5/8-18 GR5 Price: $5.16 |
| 17 |
712-3007 |
HEX NUT Price: $6.06 |
| 18 |
917-05209 |
ELECTRIC PTO CLUTCH Price: $478.71 |
| 19 |
720-05075 |
VINYL CAP Price: $3.66 |
| 20 |
728-05043 |
NUT RIVET 5/16-18 Price: $4.46 |
| 21 |
732-04927 |
EXTENSION SPRING Price: $19.91 |
| 22 |
734-06305A |
DECK WHEEL (5.0 DIA x 1.875) This part replaces 734-06305. Price: $14.82 |
| 23 |
736-0258 |
FLAT WASHER .385 x 1.00 x .135 Price: $3.93 |
| 24 |
736-0264 |
FLAT WASHER Price: $5.99 |
| 25 |
736-0322 |
FLAT WASHER .445 x 1.248 x .170 Price: $8.42 |
| 26 |
736-0344 |
FLAT WASHER Price: $4.13 |
| 27 |
738-05081 |
SHOULDER SPACER Price: $6.51 |
| 28 |
738-06694 |
SHOULDER BOLT (.50 X 2.0 x 3/8 -16) Price: $7.04 |
| 30 |
747-05608A |
DECK SPRING HOOK Price: $2.94 |
| 31 |
748-05029A |
SHOULDER SPACER Price: $4.19 |
| 32 |
750-06192A |
SPACER Price: $3.70 |
| 33 |
954-05078 |
V-BELT B SEC x 143.5 LG Price: $103.87 |
| 34 |
756-05034A |
IDLER PULLEY 4.50" DIA Price: $40.14 |
| 35 |
783-06464 |
DECK WASH PLUG Price: $3.70 |
| 36 |
783-08389 |
IDLER PULLEY CAP Price: $5.23 |
| 37 |
783Z08619A |
BELT KEEPER This part replaces 783E08619A. Price: $21.88 |
